Fiat Allis Wheel Loader 545 545H 645 Brakes and Air System Service Manual 73058626

Description

Contents:
73047530-Brakes and Air Systems
Supplement No 2 Service Manual Form 73047530 ( Same as 3047530-5) Brakes and Air System 545, 545H, 645 Wheel Loaders
Topic I – Brakes
Topic II – Wheel Brakes
Topic III – Master Brake Cylinder
Topic IV – Bleeding of Hydraulic System
Topic V – Parking Brake
Topic VI – Vacuum Pump
Topic VII – Compressor/ Governor
Topic VIII – Governor
Topic IX – Hydrovac (545 Models Only)
Topic X – Air Reservoir Tank (TL645 Only)
Topic XI – Air Pak (TL645 Only)
Topic XII – Air Cleaner and Check Valve – Vacuum (TL545’s)
Topic XIII – Troubleshooting and Test Procedures
73053547-Axles
Supplement No 9 Service Manual Form 73053547 – Axles 545, 545-B, 545H, 605-B, 645, 645-B, 745, 745-B, 745H, 745H-B Wheel Loaders
Supplement No 8 Service Manual Form 73053547 – Axles 545, 545H, 605, 745, 745H Wheel Loaders (Incl Series B)
Supplement No 7 Service Manual Form 3053547-0 – Axles 545, 545H, 605, 645, 745, 745H, Wheel Loaders (Including Series B)
Supplement No 6 Service Manual Form 3053547-0 – Axles 545, 545H, 605, 645, 745, 745H, Wheel Loaders (Including Series B)
Supplement No 5 Service Manual Form 3053547-0 – Axles 545, 545H, 605, 645, 745, 745H, Wheel Loaders (Including Series B)
Supplement No 4 Service Manual Form 3053547-0 – Axles 545, 545H, 605, 645, 745, 745H, Wheel Loaders (Including Series B)
Supplement No 3 Service Manual Form 3053547-0 – Axles 545, 545H, 605, 645, 745, 745H, Wheel Loaders (Including Series B)
Supplement No 2 Service Manual Form 3053547-0 – Axles 545, 545H, 605, 645, 745, 745H, Wheel Loaders
Supplement No 1 Service Manual Form 3053547-0 – Axles 545, 545H, 645, 745, Wheel Loaders
Topic 1 – General Information and Description
Topic 2 – Trouble Shooting
Topic 3 – Removal and Installation of Axles
Topic 4 – Differential Removal and Disassembly
Topic 5 – Cleaning and Inspection
Topic 6 – Assemble Components
Topic 7 – Planetary Hubs
Topic 8 – Cleaning and Inspection
Topic 9 – Assembly and Installation
Topic 10 – Drive Shafts
Topic 11 – Torque Specifications
Topic 12 – Wheels and Tires
Topic 13 – No Spin Differential Removal and Disassembly (Special Equipment)
73055458-Bucket and Chassis
Supplement No 4 – Service Manual Form 73055458 Bucket and Chassis 545, 545H, 545-B, 605-B, 645, 645-B, 745, 745H, 745-B, 745-C Wheel Loaders
Supplement No 3 – Service Manual Form 73055458 Bucket and Chassis 545, 545H, 545-B, 605-B, 645, 645-B, 745, 745H, 745-B, 745-C Wheel Loaders
Supplement No 2 – Service Manual Form 3055458 -8 Bucket and Chassis 545, 545H, 605, 645, 745, & 745H (Including Series B) Wheel Loaders
Supplement No 1 – Service Manual Form 3055458-8 Bucket and Chassis 545, 545H, 645, 745, Wheel Loaders
General Description
Bucket and Linkage
Fenders, Ladder, Hood, Bonnet, and Hand Rail
Platform and Seat Assembly
Fuel Tank
Main Frame and Pivot Pins
Torque Specifications
Linkage Wear Limits
ROPS Cab
Index
Conversion Tables
73068993-Power Steering
Supplement No 1 Service Manual Form 73068993 – Power Steering 545,545-H, 545-B, 605-B, 645, 645-B, Wheel Loaders
Topic 1 – Description and Operation
Topic 1A – Emergency Steering (Special Equipment)
Topic 2 – Service and Maintenance
Topic 3 – Troubleshooting
Topic 4 – Power Steering Cylinders
Topic 5 – Power Steering Pump
Topic 6 – Power Steering Gear Assembly
Topic 7 – Hydraulic Pump
Topic 8 – Demand Valve
Topic 9 – Test and Adjustment Procedures
Topic 10 – Pressure Line, Fittings, Hoses and Tubing
Topic 11 – Torque Values
Alphabetical Index
73124400-Bucket Hydraulic Systems
Supplement No 1 Service Manual Form 73124400 Bucket Hydraulic Systems 545 thru 745-C Wheel Loaders
Safety Rules
General
Hydraulic System Specifications
Description and Operation
Troubleshooting and Testing
Hydraulic Pump Repair
Hydraulic Control Valve Repair
Hydraulic Cylinder Repair
Hydraulic Fittings, Hoses and Tubing
Service Tools
Torque Values
73146366-Electrical Systems
Safety Rules
General Description
Troubleshooting
Changing Circuit
Starting Circuit
Ignition Circuit
Accessory Ciruits
Batteries
Electrical System Schematics
73158517-Quick Reference Service Specifications
Table of Contents
Machine List, FI Pump Type and Pump Part No, Engine Timing, And Machine Specification Page Numbers
Fuel Specifications, Diesel/ Engine Lubricant Specifications
Machine Lubricant/ Viscosity Specification Table
Table of Lubricants
Viscosity Charts
Conversion Factors
Definitions and Abbreviations
Model Specifications
Fuel Consumption
Fiat Engines Common to Fiatallis
Interchangeability of Components in Crawlers
Tires Sizes
Interchangeability of Components in Excavators
Crawler Tractor Weights
Machine Dimensions
