Grove Crane YB4415XT 320264 Parts Manual 2021

Description

Contents:
Boom
Boom Assembly –
52′ Long
Cylinder Assembly –
5″ Telescope
Shaft Installation –
Boom Pivot
Nose Installation – Auxiliary Boom
Boom
Extension Installation – Boom
Socket, Open Wedge
(5/8” Rope)
(Complete Assembly)
Indicator Installation –
Boom Angle
Pointer Assembly
Hook Block Assembly – 15 Ton
Boom Installation – Main
Extension Installation – Boom
Boom Kit Installation
Sensor Assembly
Box, Junction
Kit Installation – Fixed
Single Axis Boom Extension
Box, Junction
Boom Kit Installation
Superstructure
Turntable Installation
Cylinder Installation – Lift
Cylinder Assembly – 5 1/2″
Lift
(Complete Assembly)
Cylinder Assembly – 5 1/2″
Lift
(Complete Assembly)
Hoist Installation
Hoist Assembly- Model Hp12
(Complete Assembly)
Counterweight Installation
Limiter Installation –
Rated Capacity
Binder Installation
Swivel Installation –
Electric And Hydraulic
Elec & Hyd Swivel Assy
Swivel Assy-7 Port Hyd
Slip Ring Assembly – 10
Conductor
Hydraulic Components Instl W/S
Valve Assembly – Hoist Control
Valve Assembly – Control
(Lift/Tele/Swing)
Switch Assembly – Pressure
(Normally Closed)
(Complete Assembly)
Unit Assembly –
Steering Control
Cylinder Assembly – Master
Steer Selector Valve
O/R Selector Valve
Valve Assembly – Solenoid
Valve Assembly – Park Brake
(Complete Assembly)
Hydraulic Lines Installation –
Supply, Pressure And Return
Hydraulic Lines Installation –
Outrigger
Steer Hyd Lines Instl-4 Wheel
Hydraulic Lines Installation –
Swing
Hydraulic Lines Installation –
Hoist
Hydraulic Lines Installation –
Telescope
Hydraulic Lines Installation –
Lift
Superstructure Cab
Electrical System Installation
Harness Assy, Outrigger Cab To Board
System Installation –
Electric
Harness Assy, Outrigger Cab To Board
Panel Installation –
Fuse And Relay
Panel Assembly –
Fuse And Relay
Harness Assembly – Fuse Panel
Cover Installation –
(Enclosed Cab)
Fan Assembly – 12 Volt Cab
(Complete Assembly)
Door Assembly
Handle Assembly – Paddle Lock
Window Assembly – Right Front
Harness Assy, Outrigger Cab To Board
Cab Installation – Lower Area
Panel Assembly –
Instruments And Lights
(With Rated Capacity Limiter Panel)
(Complete Assembly)
Harness Assembly – Console
(Complete Assembly)
Console Assembly –
Rated Capacity Limiter
(Complete Assembly)
Heater Installation – Cummins
Heater Assembly – 12 Volt
Throttle Installation
Accelerator Pedal Assy
Accelerator Pedal Design “B”
Accelerator Pedal Design “A”
Seat Installation
Light Installation – Flasher
Light Assembly – Strobe
Harness Assy, Outrigger Cab To Board
Q00, Mini-Binder Instl
Carrier/Lowerworks
Frame Ass’y (W/Rotek Bearing)
Frame Section
Stud Installation – Weld
(Not Available As Assembly)
Drive Assembly – Swing
Gear Assembly – Worm
Speed Reducer
Motor Assembly – Orbit
Cover Installation – Deck
Mirror Installation
Hookblock Tie-Down
Installation
Outrigger Installation
Cylinder Assembly-3″ Outrigger Extension
(Complete Assembly)
Tire And Wheel Installation
Tire And Wheel Assembly
Kit, Hardware
Engine Installation – Cummins
Engine Assembly
Transmission Assembly
(Complete Assembly)
Transmission Assembly
Convertor Housing Group
Transmission Assembly
Transmission Case And
Plate Group
Transmission Assembly
Torque Converter Group
Transmission Assembly
Gear Group
Transmission Assembly
Pump Drive Group
Transmission Assembly
Charging Pump Group
Transmission Assembly
Reverse Idler Group
Transmission Assembly
Forward And Reverse
Shaft Group
Transmission Assembly
Third Shaft Group
Transmission Assembly
First And Second Shaft Group
Transmission Assembly
Output Shaft Group
Transmission Assembly
Disc Brake Group
Transmission Assembly
Caliper Assembly Group
Transmission Assembly
Electric Control Group
Transmission Assembly
Drive Plate Group
Pump Assembly – P350
(Complete Assembly)
Actuator Assembly –
Hydraulic Spring Brake
(Complete Assembly)
Electrical System Installation –
Engine,Diesel
(Not Available As Assembly)
Harness Assembly – Diesel
Receptacle Assembly
Battery Installation
Heater Installation – Block
Start Installation – Ether
(Cummins)
Radiator Installation
Radiator Assembly
Radiator And Oil Cooler
Assembly
Exhaust And Air Cleaner
Installation
Cleaner Assembly – Air
(Complete Assembly)
Hood Installation – Engine
Drive Line Installation –
4 X 4
Slip Assembly – Driveline
Axle Installation – Front
Drive/Steer
Axle Assembly – Front
Drive/Steer
Axle Assembly – Drive/Steer
Axle Assembly – Drive/Steer
Drive Steer Assembly
Axle Assembly – Drive/Steer
Axle Assembly – Drive/Steer
Hub And Components, Steer Axle
Axle Assembly – Drive/Steer
Differential Assembly
Axle Assembly – Drive/Steer
Crown Wheel And Pinion
Axle Assembly – Drive/Steer
Brake Parts, Steering Axle
Cylinder Assembly – 2 1/2″ Steer
(Complete Assembly)
Switch Assembly
Axle Installation – Rear
Axle Assembly – Rear Steer
Cylinder Assembly – 2 1/2″ Steer
(Complete Assembly)
Lh Hub/Swivel Assy
Rh Hub/Swivel Assy
Tanks
Installation –
Diesel
Filter Assembly – Return
Hydraulic Lines Installation –
Pressure Check
Hydraulic Lines Installation –
Service Brakes
Lights Installation – Exterior
Box Installation –
Tool And Battery
Counter Weight Instl
Pinion And Bearing Guard Instl
Loose Ship Items
Ball Assembly – Overhaul
(125 Lbs)
(Complete Assembly)
Specs/Schematics
Hydraulic Sys Schem
Decals
Miscellaneous Decals
Decal Installation – Yb4415
(Standard)
Decal Installation – Yb4415
(Standard)
Decal Installation – Yb4415
(Standard)
Decal Installation
Decal – Diesel
