Grove Crane YB5515 321772 Parts Manual 2012

Description

Contents:
Boom
Boom Group – 3 Section Boom
(For Reference Only)
Boom Assembly – 1st And 2nd Section
5540f
(Complete Assembly)
Cylinder Assembly Group – Telescope
(3 Section Boom)
5540f
Cylinder Assembly – Telescope Upper
(Complete Assembly)
Cylinder Assembly – Telescope Lower
(Complete Assembly)
Manifold Check Valve Assembly
(Complete Assembly)
Boom Assembly – 3rd Section
5540f
(Complete Assembly)
1114010011 Boom Yb5515/Cd5540f
Anti Two Block Group
Load Sense Indicator Installation
15 Ton
Socket Assembly, Wedge
Jib Group – Offsettable
Work Lights Group – Boom 5560b
Wired A2b Installation
Reel Assembly – Cable Anti Two Block
Winch Assembly,5540f,5560b
Swivel Hook Up Group – 5540f
Hoist Group – Standard 5540f
Hookblock Tie-Down Installation
(All Industrial Cranes)
Swivel Installation And Connectors –
2 Pass
Superstructure
Hydraulic Supply And Return Group
5540f
Steering Circuit Group – 4 Wheel Drive
(Standard Steering)
5540f
Valve Assembly – Solenoid 12 Volt
(Complete Assembly)
Mast & Attaching Parts Group
Lift Cylinder Assembly – 8.00″
Swivel Assembly – Hydraulic
(7 Circuit)
Valve Bank Group – 5540f
Valve Assembly – Combination
(Complete Assembly)
Lowerworks/Carrier
5540f Frame Kit – T3 Diesel
Engine Hood Assembly
Brake Circuit Group – 5540f
Valve Assembly – Solenoid
(Complete Assembly)
Tire&Wheel Group – 385/65r22.5 Tubeless
Tire&Wheel – 385/65r22.5 Tubeless
Engine Group – Cummins Qsb3.3-99
(Tier 3 Diesel)
5540f
Engine Assembly – Cummins Qsb3.3-99
(Tier 3 Diesel)
Filter Assy. Fuel/Water Separ.
Element,Filter Fuel/Water Sep
Air Filter Assy.
Pump Assembly – Hydraulic Gear
(Complete Assembly)
Outrigger Group – Non Independent
5540f
Valve, Control – Standard O/Rs
(Complete Assembly)
Cylinder Assembly – Outrigger
(Complete Assembly)
Alarm Installation
Seat Installation-Adjustable
Seat, Adjustable Cushioned Optional
Dome Light Installation
Kit – Windshield Washer
Cd3330
Swing Gear And Mast Mounting Group
15 Ton Industrial
Gearcase, Swing- B Model
Electrical Group – 5540f
Harness Group – Main Frame
(Tier 3 Diesel)
5540f
Harness Assembly – Main Frame
(Complete Assembly)
Drive Train Group – 4wheel
(Tier 3 Diesel)
5540f
Transmission Group – 4wheel Drive
Transmission Assembly – 4 Wheel Drive
(Complete Assembly)
4wd Trans-Housing Group
4wd Trans-Internal Compo.Group
4wd Trans-Reverser Assy. Group
4wd Trans-Clutch Assy. Group
4wd Trans-Pump Drive Group
4wd Trans-Gear Change Group
Battery Group-T3 Diesel 5540f
Exhaust Group – Tier 3 Diesel
5540f
Axle Mounting Group – Front
(4 Wheel Drive)
5540f
Brake Assembly – Parking
(Complete Assembly)
Shaft Drive – Front 1480 Series
5540f
Axle Drive Assembly – Pad Mounted
(Complete Assembly)
Drive Head Group
Wheel Hubs Group
Hub Swivels And Track Rod Group
Axle Mounting Group – Rear
(4 Wheel Drive)
5540f
Axle Assembly – Rear Drive
(Complete Assembly)
Axle Housing Group – Rear Drive
(4 Wheel Drive Units Only)
Differential Carrier Group
(4 Wheel Drive Units Only)
Hub And Track Group
(4 Wheel Drive Units Only)
Planetary Hub Group
(4 Wheel Drive Units Only)
Brake Group – Wheel Brakes
(4 Wheel Drive Units Only)
Shaft Group – Drive
(4 Wheel Drive Units Only)
Cylinder Group – Steer
(4 Wheel Drive Units Only)
Cylinder Assembly – Steering
(Complete Assembly)
Shaft Drive – Rear 1480 Series
5540f
Cooling System – Tier 3 Diesel
5540f
Radiator/Charge Air Cooler/
Transmission Oil Cooler Assembly
(Complete Assembly)
Air Cleaner Assembly – Tier 3 Diesel
5540f
Cab Component Installation-T3
Control Assembly –
Electronic Throttle
Valve – Brake Modulating
Hydraulic Tank Arrangement Assembly –
Tier 3 Diesel
5540f
Tank Assembly – Fuel
Tank Assembly – Hydraulic Oil
Heater/Defrstr Engine Parts-T3
Harness And Electrial Group – Engine
(Tier 3 Diesel)
5540f/5515
Harness Assembly – Engine
(Complete Assembly)
Charge Air Cooler Kit – Tier 3 Diesel
5540f
Fan Guard – Installation
Without Air Conditioner
Yb4409
Kit-90amp Alternator Retrofit
Operator Compartment Electric
With Outrigger Monitor
Harness Assembly – Dash
Outrigger Monitoring System Supplemental
Ind 15ton
Outrigger Monitoring System
Harness Installation
Ind 15ton
Harness – Outrigger Monitoring System
Supplemental Monitoring, Ind 15ton
Outrigger Monitoring System
Proximity Switch Installation
Proximity Switch Assembly – 30mm
Carrier/Frame Cab
Cab Mounting & Component Installation
Orbitrol, Steering
Fire Extinguisher Assembly – 2.5 Pounds
Heater/Defroster Installation
Heater Assembly
(Complete Assembly)
Cab Shell & Top Glass (Non-Ce)
Electrical Group – Operator Compartment
(Tier 3 Diesel)
Harness Assembly – Dash 5560b
(Complete Assembly)
Split Door Installation W/O Strobe 15ton
Cab Split Door Assembly With Cup Holder
Window Assembly – Half Door
Cab Installation – Enclosed
Door Strap Installation
Loose Ship Items
Downhaul Weight Assembly – 105lbs
Hookblock Assembly –
20ton Working Load Limit
(1/2″ Wire Rope)
1114010012 Lshp Yb5515/Cd5540f
Rope, Wire 1/2″ 6×19 240ft
Yb5515 Wylie I3500 Comn Prts
Specs/Schematics
Wiring Diagram, 5540f T3 Dsl
Schematic,Hyd,5540f Std O/R
1114010013specs Yb5515/Cd5540f
Wiring Diagram, 5540f T3 Dsl
Decals
Kit – Decals Universal
(English)
(For Reference Only)
Decal Installation – 7755
Decal Installation – 7755
Decal Installation – Yb5515
(Nomenclature)
Decal – Capacity Chart – Yb5515
(3 Section Boom)
80003611 Decals Yb5515
