Hangcha Forklift CBD20-AEC1 CBD20-AEC1S Operation Maintenance Manual 2015
Size: 8.87 MB
Format: PDF
Language: English
Brand: Hangcha
Type of Machine: Electric Pallet Truck
Type of Document: Operation Manual, Maintenance Manual, Electrical and Hydraulic Diagram
Model: Hangcha A Series 2.0t CBD20-AEC1, CBD20-AEC1S
Date: 2015
Number of Pages: 96 Pages
10 USD
- Description
Description
Contents:
Part I : Operation and maintenance
1 Truck Introduction
1.1 General
1.2 Use occasion and condition
1.3 Main part name
1.4 Display and control
1.4.1 Display
1.4.2 Control
1.4.3 Others
1.5 Standard technical data
1.6 Product plates and warning labels location
2 Safety Rules
3 Transport
3.1 Lifting by crane
3.2 Securing the truck during transport
3.3 How to remove a broken truck
4 Battery
4.1 Attention for using battery
4.2 Dimension/Service Weight
4.3 Charging the battery
4.4 Replacing the battery
5 Truck breaking-in
6 Operation
6.1 Check before operation
6.2 Start up
6.3 Travelling
6.4 Braking
6.5 Steering
6.6 Stopping
6.7 Loading
6.8 Unloading
6.9 Parking
7 Deposit the truck
7.1 Deposit the truck for long time
7.2 Start running after deposit for a long time
8 Maintenance
8.1 Maintenance general
8.2 Periodic maintenance schedule
8.3 Truck used oil and lubrication
8.4 Replace hydraulic oil
8.5 Replace wheels
8.5.1 Replace drive wheel
8.5.2 Replace load wheels
8.5.3 Replace Auxiliary Wheels
8.6 Replace the key safe parts periodically
9 Relevant safety directive or standard (CE)
Part II : Structure, Priciple and Maintenance
1 Drive Unit
1.1 Drive unit structure and principle
1.2 Assemble and use notice
1.3 Fault and troubleshooting
1.4 Drive motor
1.5 Electromagnetic brake
1.5.1 Electromagnetic brake working principle
1.5.2 Electromagnetic brake installation
1.5.3 Maintenance
1.5.4 Adjust the Air Gap of the Brake
1.5.5 Common fault and troubleshooting
2 Hydraulic system
2.1 Hydraulic system working principle
2.2 Hydraulic unit
2.3 Hydraulic unit dismantle
2.4 Dismantle the lifting cylinder from the truck or replace
2.5 Hydraulic system fault diagnosis and correction
3 Electric system
3.1 Electrical schematic diagram
3.2 AC motor controller
3.2.1 Maintenance
3.2.2 Diagnosis and troubleshooting
3.2.3 LED Status Indicator
3.2.4 Fault code table
Attachment： Table for bolt’s tightening torque
