Haulotte Scissor Lift HS15E to HS5390E PRO Operators Manual 4001074390 02.2025 EN

Size: 22.71 MB
Format: PDF
Language: English
Brand: Haulotte
Type of Machine: Electric Scissor Lift
Type of Manual: Operators Manual
Model: Haulotte HS15E, HS4390E, HS15E PRO, HS4390E PRO, HS18E, HS5390E, HS18E PRO, HS5390E PRO Scissor Lift
Part Number: 4001074390
Publication Date: 02.2025
Number of Pages: 192 Pages

15 USD

Tags: , , ,
  • Description

Description

Contents:
A – Foreword
1 – User Responsibility
1.1 – Owner’s Responsibility
1.2 – Employer’s Responsibility
1.3 – Trainer’s Responsibility
1.4 – Operator’s Responsibility
2 – Safety
2.1 – Safety Instructions
2.1.1 – Incorrect Use
2.1.2 – Falling Hazards
2.1.3 – Overturning – Tip-Over Hazards
2.1.4 – Risk Of Electric Shock (Electrocution)
2.1.5 – Explosion – Fire Hazards
2.1.6 – Crushing – Collision Hazards
2.1.7 – Risk Of Involuntary Movements
3 – Safety Inquiries
4 – Incident Notification
5 – Compliance
5.1 – Product Modification
5.1.1 – Implementing Manufacturer Safety Campaigns
5.2 – Product Specifications
5.3 – Change Of Ownership Notification
5.4 – Declaration Of Conformity
B – Familiarization
1 – General Safety
1.1 – Intended Use
1.2 – Decal Content
1.3 – Symbols And Colors
1.4 – Level Of Severity
1.5 – Symbols Legend And Definitions
2 – Models Description
3 – Primary Machine Components
3.1 – Layout
3.2 – Maintenance Support
3.3 – Ground Control Box
3.3.1 – Layout
3.3.1.1 – Haulotte Activ’screen 2
3.3.1.2 – Maintenance Counter Reset
3.4 – Platform Control Box
3.4.1 – Layout
4 – Performance Specifications
4.1 – Technical Characteristics
4.2 – Working Area – Range Of Motion
5 – Decals And Markings Locations
C – Pre-Operation Inspection
1 – Recommendations
2 – Working Area Assessment
3 – Inspection And Functional Test
3.1 – Daily Inspection
4 – Safety Functional Checks
4.1 – E-Stop Button Check
4.2 – Activation Of Controls
4.3 – Fault Detector
4.3.1 – Indicators-Led’s Test
4.3.2 – Buzzers Test
4.4 – Automatic Engine Cut-Out (If Machine Equipped With The Option Range Extender)
4.5 – Oscillating Axles (If Equipped)
4.6 – Slope Warning Device
4.7 – Travel Speed Limitation
4.8 – On-Board Electronics
D – Operation Instructions
1 – Operation
1.1 – Introduction
1.2 – Major Description
1.3 – Operation From The Ground Control Box
1.4 – Operation From The Platform Control Box
1.5 – Mode Operation
1.5.1 – Full Electric Mode (If Machine Equipped With The Option Range Extender)
1.5.2 – Auto Mode (If Machine Equipped With The Option Range Extender)
1.5.3 – Forced Engine Mode (If Machine Equipped With The Option Range Extender)
1.5.4 – Overview Of Mode Operation
2 – Ground Control Box
2.1 – To Start And Stop The Machine
2.2 – Movement Control
2.3 – Additional Controls
3 – Platform Control Box
3.1 – To Start And Stop The Machine
3.1.1 – To Start The Machine
3.1.2 – To Stop The Engine
3.2 – Drive And Steer Control
3.3 – Movement Control
3.4 – Additional Controls
3.4.1 – Activ’ Lighting System
H – Intervention Register
1 – Intervention Register
