Hyster Forklift A935 J30XN J35XN J40XN Parts Catalog 4011253 03-2024

Description

Contents:
Frame
HOOD AND COUNTERWEIGHT COVER
HOOD AND COUNTERWEIGHT COVER
HOOD AND COUNTERWEIGHT COVER WITH RAPID CHARGE OPTION (→ 11/2014)
HOOD AND COUNTERWEIGHT COVER WITH RAPID CHARGE (11/2014 →)
SIDE PANELS
FLOOR PLATES
DASH AND STEERING COLUMN COVERS FIXED COLUMN
DASH AND STEERING COLUMN COVERS TELESCOPIC COLUMN
NON SUSPENSION SEAT WITHOUT ELECTRONIC CONTROLS – WITH BOLT IN SENSOR
NON SUSPENSION SEAT WITHOUT ELECTRONIC CONTROLS – WITH SNAP IN SENSOR
NON SUSPENSION SEAT WITHOUT ELECTRONIC CONTROLS – WITH SNAP IN SENSOR
NON SUSPENSION SEAT ASSEMBLY
SEATS FULL SUSPENSION – SHEET 1 0F 2
SEAT FULL SUSPENSION – SHEET 2 OF 2
ARMREST SLIDER ASSEMBLY
ARMREST SLIDER ASSEMBLY
COWL AND MOUNTING
COWL AND MOUNTING
COUNTERWEIGHT
COUNTERWEIGHT
OVERHEAD GUARD
OVERHEAD GUARD
OVERHEAD GUARD
OVERHEAD GUARD DRIVE-IN RACK (→ S/N A935N01686K)
OVERHEAD GUARD DRIVE-IN RACK (S/N A935N01687K →)
OVERHEAD GUARD WITH INBOARD TAIL LIGHTS (→ 10/2013)
BATTERY TRAY OPTIONS SIDE-REMOVAL
BATTERY TRAY OPTIONS DROP-IN
HORIZONTAL BATTERY TRAY
LABELS EXTERIOR
LABELS INTERIOR
LABELS HYDRAULIC CONTROL FUNCTIONS
FORKS
FORKS OPTIONAL
STATIC STRAP
LOAD BACKREST EXTENSION
SEAT SCISSORS HEAVY DUTY – SWIVEL AND NON-SWIVEL SEATS
ELECTRICAL SYSTEM
ELECTRICAL ARRANGEMENT
ELECTRICAL ARRANGEMENT
CONTROLLERS
CONTROLLER HOIST AND FAN ASSEMBLY (→ 10/2013)
CONTROLLER HOIST AND FAN ASSEMBLY (10/2013 →)
CONTROLLER TRACTION AND FAN ASSEMBLY (→ 10/2013)
CONTROLLER TRACTION AND FAN ASSEMBLY (10/2013 →)
BATTERY CONNECTOR AND CABLE ASSEMBLY WITHOUT RAPID CHARGE OPTION
BATTERY CONNECTOR AND CABLE ASSEMBLY WITH RAPID CHARGE OPTION
DISPLAY
AUXILIARY KEY SWITCH ASSEMBLY
FUSE PANEL ASSEMBLY
CONTACTOR E
CONTACTOR EE (→ 10/2015)
CONTACTOR SEALED (10/2015 →)
MINI-LEVER CONTROLS 3 FUNCTION (→ 2/2019)
MINI-LEVER CONTROLS 3 FUNCTION – WITHOUT RTST (2/2019 →)
MINI-LEVER CONTROLS 3 FUNCTION – WITH RTST (2/2019 →)
MINI-LEVER CONTROLS 4 FUNCTION (→ 2/2019)
MINI-LEVER CONTROLS 4 FUNCTION – WITHOUT RTST (2/2019 →)
MINI-LEVER CONTROLS 4 FUNCTION – WITH RTST (2/2019 →)
TILT SENSOR GROUP
LIGHTS WITH STANDARD OVERHEAD GUARD
LIGHTS WITH DRIVE-IN RACK OVERHEAD GUARD
WIRE HARNESS RH LIGHT WITH STANDARD DISPLAY – WITH HIGH MOUNT WITHOUT TURN SIGNALS (→ 10/2013)
WIRE HARNESS RH LIGHT WITH STANDARD DISPLAY – WITH HIGH MOUNT WITHOUT TURN SIGNALS (10/2013 →)
WIRE HARNESS RH LIGHT WITH STANDARD DISPLAY – LOW MOUNT WITHOUT TURN SIGNALS (→ 10/2013)
WIRE HARNESS RH LIGHT WITH STANDARD DISPLAY – LOW MOUNT WITHOUT TURN SIGNALS (10/2013 →)
WIRE HARNESS RH LIGHT WITH FREEZER DISPLAY – HIGH MOUNT WITH TURN SIGNALS (→ 10/2013)
WIRE HARNESS RH LIGHT WITH FREEZER DISPLAY – HIGH MOUNT WITH TURN SIGNALS (10/2013 →)
WIRE HARNESS RH LIGHT WITH FREEZER DISPLAY – LOW MOUNT WITH TURN SIGNALS (→ 10/2013)
WIRE HARNESS RH LIGHT WITH FREEZER DISPLAY – LOW MOUNT WITH TURN SIGNALS (10/2013 →)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 1 OF 2 (→ 10/2013)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 2 OF 2 (→ 10/2013)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – SHEET 1 OF 2 (10/2013 ↔ 11/2014)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – SHEET 2 OF 2 (10/2013 ↔ 11/2014)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – SHEET 1 OF 2 (11/2014 ↔ 11/2015)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – SHEET 2 OF 2 (11/2014 ↔ 11/2015)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – SHEET 1 OF 2 (11/2015 →)
WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – SHEET 2 OF 2 (11/2015 →)
WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – PAGE 1 OF 2 (→ 10/2013)
WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – PAGE 2 OF 2 (→ 10/2013)
WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – SHEET 1 OF 2 (10/2013 ↔ 11/2015)
WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – SHEET 2 OF 2 (10/2013 ↔ 11/2015)
WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – SHEET 1 OF 2 (11/2015 →)
WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – SHEET 2 OF 2 (11/2015 →)
WIRE HARNESS MANUAL INTERLOCK
WIRE HARNESS MANUAL HYDRAULICS
WIRE HARNESS SYNCHRONOUS STEERING
WIRE HARNESS STEER COLUMN
WIRE HARNESS 12 VOLT OUTLET (→ 9/2013)
WIRE HARNESS 12 VOLT OUTLET (9/2013 →)
WIRE HARNESS DC/DC CONVERTER
WIRE HARNESS AUXILIARY PLUG
WIRE HARNESS HYDRAULIC FLUID LEVEL AND PRESSURE
WIRE HARNESS LIGHTS WITH OVERHEAD GUARD (→ 10/2013)
WIRE HARNESS LIGHTS WITH OVERHEAD GUARD (10/2013 →)
WIRE HARNESS LIGHTS WITH DRIVE-IN RACK OVERHEAD GUARD (→ 10/2013)
WIRE HARNESS LIGHTS WITH DRIVE-IN RACK OVERHEAD GUARD (10/2013 →)
WIRE HARNESS ENERGY STORAGE SYSTEM INTERFACE
DRIVE UNIT
DRIVE UNIT ASSEMBLY
TRANSMISSION COVER AND BRAKE DISCS
TRANSMISSION HOUSING
TRACTION MOTOR ASSEMBLY
TRANSMISSION INPUT
TRANSMISSION OUTPUT
DRIVE TIRE AND WHEEL ASSEMBLY CUSHION
DRIVE TIRE AND WHEEL ASSEMBLY PNEUMATIC – WATTS
DRIVE TIRE AND WHEEL ASSEMBLY PNEUMATIC – MONARCH
STEERING SYSTEM
STEER AXLE MOUNTING
STEER AXLE ASSEMBLY
STEER TIRE AND WHEEL ASSEMBLY CUSHION
STEER TIRE AND WHEEL ASSEMBLY PNEUMATIC
STEERING WHEEL AND COLUMN FIXED
STEERING WHEEL AND COLUMN TELESCOPIC
STEERING COLUMN ASSEMBLY FIXED (→ 10/2013)
STEERING COLUMN ASSEMBLY FIXED (10/2013 →)
STEERING COLUMN ASSEMBLY TELESCOPIC (→ 10/2013)
STEERING COLUMN ASSEMBLY TELESCOPIC (10/2013 →)
STEERING HAND PUMP ASSEMBLY
STEERING HAND PUMP ASSEMBLY
STEERING ACCUMULATOR
BRAKE/ACCELERATOR SYSTEM
BRAKE ASSEMBLY
MASTER CYLINDER
PARKING BRAKE RELEASE
ACCELERATOR PEDAL STANDARD
ACCELERATOR PEDAL MONOTROL
HYDRAULIC SYSTEM
HYDRAULIC POWER UNIT INSTALLATION
HYDRAULIC SUPPLY AND RETURN
HYDRAULIC SUPPLY AND RETURN AND POWER UNIT INSTALLATION (11/2014 ↔ 3/2017)
HYDRAULIC SUPPLY AND RETURN AND POWER UNIT INSTALLATION (3/2017 →)
HYDRAULIC PUMP AND MOTOR MOUNTING
HYDRAULIC MOTOR ASSEMBLY
HYDRAULIC PUMP ASSEMBLY
HYDRAULIC TANK ASSEMBLY
HYDRAULIC FILTER HOUSING
HYDRAULIC HOSES AND FITTINGS STEERING (→ 11/2014)
HYDRAULIC HOSES AND FITTINGS STEERING (11/2014 →)
HYDRAULIC HOSES AND FITTINGS AUXILIARY HOSES
HYDRAULIC HOSE MAST
RETURN TO SET TILT
HYDRAULIC CONTROLS ELECTRO-HYDRAULIC
HYDRAULIC CONTROL VALVE ELECTRO-HYDRAULIC – 3 AND 4 FUNCTION
INLET SECTION ELECTRO-HYDRAULIC CONTROL VALVE
LIFT/TILT SECTION ELECTRO-HYDRAULIC CONTROL VALVE
TIE RODS ELECTRO-HYDRAULIC CONTROL VALVE
HYDRAULIC CONTROLS MANUAL
MANUAL CONTROL LEVERS
HYDRAULIC CONTROL VALVE MANUAL – 3 AND 4 FUNCTION (→ 10/2011)
HYDRAULIC CONTROL VALVE MANUAL – 3 AND 4 FUNCTION (10/2011 →)
INLET SECTION MANUAL HYDRAULIC CONTROL VALVE
LIFT/TILT/AUXILIARY SECTION MANUAL HYDRAULIC CONTROL VALVE
OUTLET SECTION MANUAL HYDRAULIC CONTROL VALVE
TIE RODS MANUAL HYDRAULIC CONTROL VALVE
POSITIONER SENSOR MANUAL HYDRAULIC CONTROL VALVE
MAST/TILT CYLINDER INSTALLATION
TILT CYLINDER ASSEMBLY
Mast-Two Stage Limited Free-Lift
MAST ASSEMBLY TWO STAGE LIMITED FREE LIFT – C661
LIFT CYLINDER ASSEMBLY TWO STAGE LIMITED FREE LIFT – C661
CARRIAGE ASSEMBLY TWO STAGE LIMITED FREE LIFT – C661
HEADER HOSE ASSEMBLY TWO STAGE LMITED FREE-LIFT – C661
Mast-Three Stage Full Free-Lift
MAST ASSEMBLY THREE STAGE FULL FREE LIFT – C662 – INNER, INTERMEDIATE AND OUTER
MAIN LIFT ASSEMBLY THREE STAGE FULL FREE LIFT – C662
FREE LIFT ASSEMBLY THREE STAGE FULL FREE LIFT – C662
MAIN LIFT CYLINDER ASSEMBLY THREE STAGE FULL FREE LIFT – C662
FREE LIFT CYLINDER ASSEMBLY THREE STAGE FULL FREE LIFT – C662
CARRIAGE ASSEMBLY THREE STAGE FULL FREE LIFT – C662
HEADER HOSE ASSEMBLY THREE STAGE FULL FREE-LIFT – C662 (→ 12/2012)
HEADER HOSE ASSEMBLY THREE STAGE FULL FREE-LIFT – C662 (12/2012 →)
Mast-Two Stage Full Free-Lift
MAST ASSEMBLY TWO STAGE FULL FREE LIFT – C663
MAIN LIFT ASSEMBLY TWO STAGE FULL FREE LIFT – C663
FREE LIFT ASSEMBLY TWO STAGE FULL FREE LIFT – C663
MAIN LIFT CYLINDER LH TWO STAGE FULL FREE LIFT – C663
MAIN LIFT CYLINDER RH TWO STAGE FULL FREE- LIFT – C663
FREE LIFT CYLINDER ASSEMBLY TWO STAGE FULL FREE LIFT – C663
CARRIAGE ASSEMBLY TWO STAGE FULL FREE- LIFT
HEADER HOSE ASSEMBLY TWO-STAGE FULL FREE-LIFT – C663
MAST-FOUR STAGE FULL FREE-LIFT
OUTER MAST FOUR STAGE FULL FREE-LIFT
OUTER INTERMEDIATE MAST MAIN LIFT – FOUR STAGE FULL FREE-LIFT
INNER INTERMEDIATE MAST FOUR STAGE FULL FREE-LIFT
INNER MAST FREE-LIFT – FOUR STAGE FULL FREE-LIFT
MAIN LIFT CYLINDER RIGHT HAND – FOUR STAGE FULL FREE-LIFT
MAIN LIFT CYLINDER LEFT HAND – FOUR STAGE FULL FREE-LIFT
FREE-LIFT CYLINDER FOUR STAGE FULL FREE-LIFT
LIFT CHAINS FOUR STAGE FULL FREE-LIFT
FREE-LIFT HOSE FOUR STAGE FULL FREE-LIFT
HOSE ATTACHING PARTS THREE FUNCTION – FOUR STAGE FULL FREE-LIFT (→ 4/2015)
HOSE ATTACHING PARTS THREE FUNCTION – FOUR STAGE FULL FREE-LIFT (4/2015 →)
HOSE ATTACHING PARTS FOUR FUNCTION – FOUR STAGE FULL FREE-LIFT (→ 4/2015)
HOSE ATTACHING PARTS FOUR FUNCTION – FOUR STAGE FULL FREE-LIFT (4/2015 →)
HEADER HOSES THREE AND FOUR FUNCTION (→ 4/2015)
HEADER HOSES THREE AND FOUR FUNCTION (4/2015 →)
INTEGRAL SIDE-SHIFT CARRIAGE FOUR STAGE FULL FREE-LIFT
INTEGRAL SIDE-SHIFT HYDRAULIC HOSE FOUR STAGE FULL FREE-LIFT
LOWERING CONTROL VALVE FOUR STAGE FULL FREE-LIFT
CARRIAGE SIX ROLLER – FOUR STAGE FULL FREE-LIFT
OPTIONS
AUDIBLE ALARM
DC/DC CONVERTER WITHOUT AUXILIARY PLUG HARNESS
DC/DC CONVERTER WITH AUXILIARY PLUG HARNESS
FRONT WORK AND MARKER LIGHTS
REAR REFLECTORS
STROBE LIGHT ASSEMBLY AND REAR WORK LIGHT
INBOARD REAR LIGHTS
DOME LIGHT
WIRE HARNESS AUTO LIGHT ACTIVATION
DUAL MIRRORS REAR VIEW
DUAL MIRRORS REAR VIEW – WITH DRIVE-IN RACK
MIRROR PANORAMIC – WITH STANDARD OVERHEAD GUARD
MIRROR PANORAMIC – WITH LOW-PROFILE OVERHEAD GUARD
REVERSE HANDLE
TRACTION SPEED LIMITER
TRACTION SPEED LIMITER
INTEGRAL SIDE-SHIFT TWO STAGE LIMITED FREE LIFT – C661 – CARRIAGE ASSEMBLY (→ 12/2016)
INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE LIMITED FREE- LIFT – 977MM 38.5 IN (12/2016 →)
INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE LIMITED FREE-LIFT – 907 MM 35.7 IN (12/2016 →)
INTEGRAL SIDE-SHIFT THREE STAGE FULL FREE LIFT – C662 – CARRIAGE ASSEMBLY (→ 12/2016)
INTEGRAL SIDE-SHIFT CARRIAGE THREE STAGE FULL FREE- LIFT – 977 MM 38.5 IN (12/2016 →)
INTEGRAL SIDE-SHIFT CARRIAGE THREE STAGE FULL FREE-LIFT – 907 MM 35.7 IN (12/2016 →)
INTEGRAL SIDE-SHIFT TWO STAGE FULL FREE LIFT – C663 – CARRIAGE ASSEMBLY (→ 12/2016)
LOWER BEARING KIT INTEGRAL SIDE-SHIFT CARRIAGE – SERVICE OPTION
KIT ISS CARRIAGE – SOLID LINK KIT
INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE FULL FREE- LIFT – 977 MM 38.5 IN (12/2016 →)
INTEGRAL SIDE-SHIFT FORK POSITIONER – THREE STAGE FULL FREE-LIFT
INTEGRAL SIDE-SHIFT FORK POSITIONER (977 MM) – TWO AND THREE STAGE FFL CLASS II (12/2016 →)
FORK POSITIONER ASSEMBLY
INTEGRAL SIDE-SHIFT CYLINDER
INTEGRAL SIDE-SHIFT CYLINDER ROD ASSEMBLY (12/2016 →)
AUXILIARY TUBE EXTENSIONS TWO-STAGE LIMITED FREE-LIFT
AUXILIARY TUBE EXTENSIONS TWO AND THREE STAGE FULL FREE-LIFT
AUXILIARY TUBE EXTENSIONS ISS ONLY FOUR FUNCTION, TWO STAGE LIMITED FREE-LIFT – WITHOUT QUICK DISCONNECT FITTINGS, HEAVY DUTY (12/2016 →)
AUXILIARY TUBE EXTENSIONS ISS ONLY FOUR FUNCTION, TWO STAGE LIMITED FREE-LIFT – W/ 1 PAIR QD FITTINGS (12/2016 →)
AUXILIARY TUBE EXTENSIONS ISS ONLY FOUR FUNCTION, TWO STAGE LIMITED FREE-LIFT – MEDIUM DUTY (12/2016 →)
AUXILIARY TUBE EXTENSIONS ISS ONLY FOUR FUNCTION TWO AND THREE STAGE FULL FREE-LIFT – MEDIUM DUTY
AUXILIARY TUBE EXTENSIONS ISS ONLY FOUR FUNCTION, THREE STAGE FULL FREE-LIFT – HEAVY DUTY
FIRE EXTINGUISHER
FIELD CONVERSION KITS
HEADER HOSE CONVERSION KITS THREE STAGE FULL FREE-LIFT (→ 4/2010)
HEADER HOSE CONVERSION KITS THREE STAGE FULL FREE LIFT (4/2010 →)
HEADER HOSE CONVERSION KITS TWO STAGE FULL FREE- LIFT (→ 4/2010)
HEADER HOSE CONVERSTION KITS TWO STAGE FULL FREE LIFT (4/2010 →)
REPAIR KIT
ADD ON OPTIONS FORK POSITIONER
ADD ON TELEMETRY KITS
ADD-ON OPTION KITS
AUXILIARY TUBE EXTENSION KIT TWO AND THREE STAGE FULL FREE-LIFT
AUXILIARY TUBE EXTENSION KIT TWO STAGE LIMITED FREE-LIFT
ACCELERATOR PEDAL
AUXILIARY EXTENSION TUBES ISS CARRIAGE
NUMERICAL INDEX
