Komatsu Hydraulic Excavator PC400-8 Parts Book YEPB204000-00 V2 2025

Description

Contents:
ENGINE CYLINDER HEAD AND ITS RELATED PARTS
Cylinder Head
RockerAnn Housing Cover
(For China 2nd EX-Gas Regulation Arrangement)
Rocker Arm Housing Cover Accessory
(Oil Filler)
Exhaust Muffler and Mounting Bracket
Air Intake Manifold and Connection
Air Cleaner
Aftercooler
Exhaust Manifold
Turbocharger
Inner Parts
Mounting
Exhaust Gas Recirculation (EGR) Valve
EGR Valve and Cooler Mounting (112)
Inner Parts, Pump
EGR Valve and Cooler Mounting (212)
EGR Cooler Piping and Air Vent
EGR Valve Lubricating Oil Piping
Heat Shield
ENGINE CYLINDER BLOCK AND ITS RELATED PARTS
Cylinder Block
Cylinder Block Accessory
Front Cover
Front Cover Accessory
Idle Gears
Cam Follower Cover
(With Breather)
Engine Oil Pan
(For Extreme Cold Area Specification (-40 deg C))
Flywheel Housing
Flywheel
Crankshaft
\fibration Damper
Piston and Connecting Rod
Crank Pulley
(Non Hardening Type)
(Sandy and Dusty Tenain Spec.)
Camshaft
ENGINE LUBRICATION SYSTEM
Engine Oil Pump
Engine Oil Filter
Engine Oil Cooler
Engine Oil Cooler Related Parts
Water Drain Valve
ENGINE FUEL SYSTEM
Fuel Supply Pump
Inner Parts, Pump (112)
Inner Parts, Pump (212)
Pump Mounting
Common Rail
Common Rail Mounting Parts
Fuel Supply Pump Piping
Fuel Supply Pump Drive
Fuel Filter
Fuel Filter Piping
(Poor Fuel Arrangement Spec.)
Fuel Injector
(With Spill Tube)
Prefilter
Fuel Prefilter (1-1/4)
Fuel Prefilter (1-1/4) (For China 2nd EX-Gas Regulation Arrangement)
Fuel Prefilter (1-1/4) (For Poor Fuel Specification, Water,China 2nd EX—Gas Regulation
Arrangement)
Fuel Prefilter (1-1/4) (With Extra Bed Fuel and Poor Fuel Specification, Water+Dust, Additional
Filter)
Priming Pump and Piping (For China 2nd EX-Gas Regulation Arrangement)
Priming Pump and Piping (For Poor Fuel Specification, Water,China 2nd EX-Gas Regulation
Priming Pump and Piping (Vifith Extra Bad Fuel and Poor Fuel Specification, Water+Dust,
Additional Filter)
Priming Pump and Piping
Fuel Prefilter and Piping
Fuel Prefilter (1-1/4) (For China 2nd EX-Gas Regulation Arrangement,Bad Fuel and Poor Fuel
Specification, Water+Dust)
Priming Pump and Piping (For China 2nd EX-Gas Regulation Anangement,Bad Fuel and Poor
Fuel Specification, Water+Dust)
ENGINE COOLING SYSTEM
Thermostat and Thermostat Housing
Water Temperature Sensor
Cooling Fan
Cooling Fan Pulley and Drive Belt
(For High Speed Cooling Fan)
(For High Speed Cooling Fan,Sandy and Dusty Terrain Arrangement)
(For Sandy and Dusty Terrain Arrangement,China 3rd EX-Gas Regulation Arrangement)
(Sandy and Dusty Terrain Spec.)
Cooling Fan Drive
(For Extreme Cold Area Specification (—40 deg C))
Corrosion Resistor
Water Pump Mounting and Air Vent
Corrosion Resistor Related Parts
ENGINE ELECTRICAL SYSTEM
AItemator
Inner Parts (50Amp.)
Inner Parts (50Amp.,Sandy and Dusty Terrain Spec.)
Inner Parts (60Amp.)
Inner Parts (60Amp.,For Sandy and Dusty Tenain Arrangement)
Mounting Parts (50Amp.)
Mounting Parts (50Amp.,Sandy and Dusty Terrain Spec.)
Mounting Parts (60Amp.)
Mounting Parts (60Amp.,For Sandy and Dusty Terrain Arrangement)
Starting Motor
Inner Parts (11KW,With Protect Cover)
Inner Parts (7.5KW,With Protect Cover)
Mounting (11KW,With Protect Cover)
Mounting (7.5KW,With Protect Cover)
Wiring Harness
(112) (For China 2nd EX-Gas Regulation Arrangement)
Engine Wiring Harness (For China 2nd EX-Gas Regulation Arrangement,Poor Fuel Specification,
Water,Bad Fuel and Poor Fuel Specification, Water+Dust)
(212) (For China 2nd EX-Gas Regulation Arrangement)
Wiring Harness Support (For China 2nd EX-Gas Regulation Arrangement,Poor Fuel Specification
ENGINE ACCESSORIES AND OTHERS
Engine Controller
(For China 2nd EX-Gas Regulation Arrangement,Poor Fuel Specification, Water,Bad Fuel and
Poor Fuel Specification, Water+Dust)
ENGINE MARKS AND PLATES
Name Plate and Caution Plate
(English Instruction)
20
(For BRAZIL Noise Regulation)
(For Canada Exhaust Gas TPEM)
(For China 3rd EX-Gas Regulation Arrangement)
(For EPA Regulations TPEM)
(For EU Exhaust Emissions 3rd Regulations)
(For EU Exhaust Emissions 3rd Regulations,EU Safety Regulation)
(For EU Safety Regulation)
(For EU Safety Regulation,Turkey Exhaust Emissions 3rd Regulations)
(For Except Japan)
(For Turkey 3A UNECER96 Certified)
(North America EPA 3rd Regulations)
ENGINE RELATED PARTS
Damper
Engine Mounting
(Extreme Cold Area Specification (-40 deg C))
(With Refueling Pump)
Coolant Filter
Mounting (Extreme Cold Area Specification (-40 deg C))
Inner Parts (Extreme Cold Area Specification (—40 deg C))
Related Parts (Extreme Cold Area Specification (-40 deg C))
COOLING SYSTEM
Cooling System
Radiator
Radiator (Extreme Cold Area Specification (~40 deg C))
Oil Cooler
Oil Cooler (Extreme Cold Area Specification (—40 deg C))
Aftercooler and Condenser
Aftercooler and Condenser (For EU Safety Regulation)
Net and Shroud
Radiator Piping (For EU Safety Regulation)
Radiator Piping
Cover
Shroud
Radiator Piping and Reservoir Tank
Radiator Piping and Reservoir Tank (With EU Safety Regulation)
Radiator Piping (112) (Extreme Cold Area Specification (-40 deg C))
Cover (Extreme Cold Area Specification (-40 deg C))
Sheet
Radiator Piping (212) (Extreme Cold Area Specification (-40 deg C))
Reservoir Tank (Extreme Cold Area Specification (-40 deg C))
Sheet (Extreme Cold Area Specification (-40 deg C))
Cooling Fan Guard
FUEL SYSTEM
Fuel Tank
(Extreme Cold Area Specification (-40 deg C),For Water Separator)
(For Water Separator)
(For Water Separator,Refueling Pump)
(For Refueling Pump)
Fuel Piping
(112) (For Bad Fuel and Poor Fuel Specification, Water+Dust, Turkey)
(114) (For Water Separator)
(212) (For Bad Fuel and Poor Fuel Specification, Water+Dust, Turkey)
(214) (For Water Separator)
(314) (For Water Separator)
Inner Parts, Water Separator
(414) (For Water Separator)
Fuel Supply Piping
(114) (Extreme Cold Area Specification (-40 deg C),For Water Separator)
(214) (Extreme CoId Area Specification (-40 deg C),For Water Separator)
(314) (Extreme CoId Area Specification (-40 deg C),For Water Separator)
(414) (Large Capacity Battery,For Water Separator)
ELECTRICAL SYSTEM
Battery
(Large Capacity,Large Capacity Battery)
(Large Capacity)
(Without Battery)
Electric Wiring Harness
Starting Wiring Harness Clamp (Extreme Cold Area Specification (-40 deg C))
Starting Wiring Harness Clamp (For EU Arrangement)
Starting Wiring Harness Clamp
Main Wiring Harness Clamp (114)
Main Wiring Harness Clamp (115) (Extreme CoId Area Specification (-40 deg C))
Main Wiring Harness Clamp (114) (For EU Arrangement)
Main Wiring Harness Clamp (215) (Extreme CoId Area Specification (-40 deg C))
Main Wiring Harness Clamp (214)
Main Wiring Harness Clamp (314)
Main Wiring Harness Clamp (315) (Extreme CoId Area Specification (-40 deg C))
Main Wiring Harness Clamp (415) (Extreme Cold Area Specification (-40 deg C))
Main Wiring Harness Clamp (414)
Main Wiring Harness Clamp (515) (Extreme CoId Area Specification (-40 deg C))
Working Lamp
Working Lamp (For EU Arrangement)
Working Lamp (Extreme Cold Area Specification (-40 deg C))
Additional Working Lamp
(Front, Cab Top)
(Front, Cab Top,With Cab Front Full Guard LV1)
(Front, Cab Top,With Cab Front Full Guard LV1, Top Guard LV2)
Additional Rear Working Lamp
(Cab Top)
Beacon Lamp
Horn
Travel Alarm
Rearview Camera
(1-Camera)
(Without Rearview Camera)
(2-Camera)
HYDRAULIC SYSTEM
Hydraulic Tank
Tank (Extreme Cold Area Specification (-40 deg C))
Tank
Tank (For EN iSO Access 2011)
Tank (With Boom Anti-drop Valve)
Breather Mounting
Breather Mounting (Extreme Cold Area Specification (~40 deg C))
Breather Mounting (For EN iSO Access 2011)
Breather Mounting (With Boom Anti-drop Valve)
Control Valve
7-Spool (1120)
7~Spool (1120) (Extreme Cold Area Specification (~40 deg C))
7~Spool (1119)
7-Spool (2120) (Extreme Cold Area Specification (~40 deg C))
7~Spool (2119)
7-Spool (3120) (Extreme Cold Area Specification (~40 deg C))
7~Spoo| (3119)
7-Spool (4120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (5120)
7~Spool (5120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (5119)
7~Spool (6120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (7120)
7-Spool (7120) (Extreme Cold Area Specification (-40 deg C))
7~Spool (7119)
7-Spool (8120) (Extreme Cold Area Specification (-40 deg C))
7~Spool (8119)
7-Spool (9120) (Extreme Cold Area Specification (-40 deg C))
7~Spool (9119)
7~Spool (1 0120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (1 0119)
7~Spool (11120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (11119)
7~Spool (12120) (Extreme Cold Area Specification (~40 deg C))
7~Spool (12119)
7-Spool (1 3120)
7~Spool (1 3120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (1 3119)
7-Spool (14/20)
7-Spool (1 4120) (Extreme Cold Area Specification (-40 deg C))
7-Spool (14/19)
7-Spool (1 5120) (Extreme Cold Area Specification (-40 deg C))
7-Spool (1 5119)
7-Spool (1 6120) (Extreme Cold Area Specification (-40 deg C))
7-Spool (1 6119)
7-Spool (17120)
7-Spool (17120) (Extreme Cold Area Specification (-40 deg C))
7-Spool (18120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (19120) (Extreme Cold Area Specification (~40 deg C))
7-Spool (20120) (Extreme Cold Area Specification (~40 deg C))
8-Spool (1121) (For Loading Shovel, Bottom Dump Type)
8-Spool (1123) (Extreme Cold Area Specification (-40 deg C))
8-Spool (2121) (For Loading Shovel, Bottom Dump Type)
Inner Parts (117)
8-Spool (2123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (3121) (For Loading Shovel, Bottom Dump Type)
Inner Parts (217)
8-Spool (3123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (4121) (For Loading Shovel, Bottom Dump Type)
Inner Parts (317)
8-Spool (4123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (5121) (For Loading Shovel, Bottom Dump Type)
8-Spool (5123) (Extreme Cold Area Specification (-40 deg C))
8-Spool (6121) (For Loading Shovel, Bottom Dump Type)
Inner Parts (417)
8-Spool (6123) (Extreme Cold Area Specification (-40 deg C))
8-Spool (7121) (For Loading Shovel, Bottom Dump Type)
8-Spool (7123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (8121) (For Loading Shovel, Bottom Dump Type)
8-Spool (8123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (9121) (For Loading Shovel, Bottom Dump Type)
8-Spool (9123) (Extreme Cold Area Specification (-40 deg C))
8-Spool (10/21) (For Loading Shovel, Bottom Dump Type)
8-Spool (10/23) (Extreme Cold Area Specification (~40 deg C))
8-Spool (11121) (For Loading Shovel, Bottom Dump Type)
8-Spool (11123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (12121) (For Loading Shovel, Bottom Dump Type)
8-Spool (12123) (Extreme Cold Area Specification (~40 deg C))
8-Spool (13/23) (Extreme Cold Area Specification (~40 deg C))
8-Spool (14/21) (For Loading Shovel, Bottom Dump Type)
8-Spool (14/23) (Extreme Cold Area Specification (~40 deg C))
8-Spool (15/21) (For Loading Shovel, Bottom Dump Type)
Inner Parts (517)
8-Spool (15/23) (Extreme Cold Area Specification (~40 deg C))
Inner Parts (112) (For Loading Shovel, Bottom Dump Type)
Inner Parts (617)
8-Spool (16/23) (Extreme Cold Area Specification (~40 deg C))
8-Spool (16/21) (For Loading Shovel, Bottom Dump Type)
8-Spool (17123) (Extreme Cold Area Specification (~40 deg C))
Valve Bracket and Sensor (8-Spool)
Valve Bracket and Sensor (9-Spool)
Valve Bracket and Sensor (7-Spool,For China)
Valve Bracket and Sensor (7-SpooI,Extreme Cold Area Specification (~40 deg C))
Valve Bracket and Sensor (8-Spool,Extreme Cold Area Specification (-40 deg C))
Blind Parts
Blind Parts (Cold Area Specification B (~30 deg C))
Hydraulic Pump Related Parts
(Extreme Cold Area Specification (~40 deg C))
Hydraulic Pump
Piston Pump (1112)
Piston Pump (1112) (Extreme Cold Area Specification (-40 deg C))
Piston Pump (2112)
Piston Pump (2112) (Extreme Cold Area Specification (-40 deg C))
Piston Pump (3112)
Piston Pump (3112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (4112)
Piston Pump (4112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (5112)
Piston Pump (5112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (6112)
Piston Pump (6112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (7112)
Piston Pump (7112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (8112)
Piston Pump (8112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (9112)
Piston Pump (9112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (10/12)
Piston Pump (10/12) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (11112)
Piston Pump (11112) (Extreme Cold Area Specification (~40 deg C))
Piston Pump (12112)
Piston Pump (12112) (Extreme Cold Area Specification (~40 deg C))
Suction Piping
Delivery Piping
(With InIine Filter)
Oil Cooler Piping
Return Piping
(Extreme Cold Area Specification (~40 deg C),With 1-Additional Actuator Piping, Accumulator)
(For Loading Shovel)
(With Additional Actuator Piping, Accumulator)
Drain Piping
Boom Piping
(112) (Extreme Cold Area Specifimtion (-40 deg C))
26
(112) (With Boom Anti-drop Valve)
(212) (Extreme Cold Area Specification (~40 deg C))
Arm and Bucket Piping
(Arm Hydraulic Drift Prevention Valve)
Arm Hydraulic Drift Prevention Valve
Anti-drop Valve Piping
Cylinder Piping Group
Anti—drop Valve Chassis Group
Boom Anti-drop Valve (112)
Boom Anti-drop Valve (212)
Actuator Piping
Main Piping, L.H.
Main Piping, L.H. (Extreme Cold Area Specification (~40 deg C))
Selector Valve
Selector Valve (Extreme CoId Area Specification (~40 deg C))
Main Piping, RH.
Main Piping, RH. (Extreme Cold Area Specification (~40 deg C))
Filter
Return Piping (Extreme Cold Area Specification (-40 deg C))
Pilot Filter (Extreme Cold Area Specification (~40 deg C))
Accumulator
Accumulator Mounting
Filter Bracket
Pilot Filter
Pilot Filter Mounting
Relief Valve
Valve (Pressure Regulator Valve, 250kg/cm2)
2-Additional Actuator Piping
(Loading Shovel, Bottom Dump Type)
Travel Piping
(Extreme Cold Area Specification (~40 deg C),With 1-Additionai Actuator Piping, Accumulator)
(For China)
Solenoid Valve
Inner Parts (Extreme Cold Area Specification (~40 deg C))
Inner Parts (Extreme Cold Area Specification (~40 deg C),With 1-Additional Actuator Piping,
Accumulator)
Inner Parts (With Additional Actuator Piping, Accumulator)
Solenoid Valve Related Parts
Solenoid Valve Related Parts (Extreme Cold Area Specification (~40 deg C))
Solenoid Valve Related Parts (Extreme Cold Area Specification (~40 deg C),With 1-Additional
Actuator Piping, Accumulator)
Solenoid Valve Related Parts (For China)
Solenoid Valve Related Parts (With 1-Additional Actuator Piping, Accumulator)
Solenoid Valve Related Parts (With 1-Service Valve)
Solenoid Valve Related Parts (With Additional Actuator Piping, Accumulator)
Bracket
Bracket (Extreme Cold Area Specification (~40 deg C))
Bracket (Extreme Cold Area Specification (~40 deg C),With 1~Additionai Actuator Piping,
Bracket (For China)
Bracket (With 1~Additional Actuator Piping, Accumulator)
Bracket (With 1-Service Valve)
Bracket (With Additional Actuator Piping, Accumulator)
Accumulator (Extreme Cold Area Specification (-40 deg C))
Accumulator (Extreme Cold Area Specification (-40 deg C),With 1~Additional Actuator Piping,
(112) (For Loading Shovel, Bottom Dump Type)
(212) (For Loading Shovel, Bottom Dump Type)
Pressure Switch Block
Proportional Pressure Control (PPC) Valve Piping
FRAME AND ITS RELATED PARTS
Revolving Frame
Frame and Cover (Extreme Cold Area Specification (~40 deg C))
Frame and Cover (For China)
Frame and Cover
Frame and Cover (For EN ISO Access 2011)
Frame and Cover (With Deck Guard)
Sheet (Extreme Cold Area Specification (~40 deg C))
Boom Foot Pin
(100 Hours Lubrication Interval)
(500 Hours Lubrication Interval)
OPERATOR‘S COMPARTMENT AND CONTROL SYSTEM
Operator’s Seat
(112) (Rigid Type, Reclining)
(112) (Rigid Type, Reclining, Tilt)
(112) (With Heated)
(212) (Rigid Type, Reclining)
(212) (Rigid Type, Reclining, Tilt)
(212) (With Heated)
Seat Belt
(50mm, 2—Point Type, Rigid Type Operator’s Seat)
(78mm, 2~Point Type, Rigid Type Operator‘s Seat)
Luggage Box Net
Floor Frame Cover
Top Guard
Front Guard
(Full Guard LV1)
(Full Guard LV2)
(Half Guard)
Floor Mat
(1 -Additional Actuator Piping, Accumulator)
(2-Additional Actuator Piping, Accumulator)
Rain Visor
Sunvisor
Window Washer Tank
Air Conditioner Unit
Compressor
Compressor Mounting
Compressor Mounting (Auto, Big Wind Quantity)
Piping (Auto, Big Wind Quantity)
Blower and Duct (Auto, Big Wind Quantity)
Heater Piping
(113) (Extreme Cold Area Specification (~40 deg C))
(213) (Extreme Cold Area Specification (~40 deg C))
(313) (Extreme Cold Area Specification (~40 deg C))
High-efficiency Air Conditioner Recirculation Air Filter
(112) (High-efficiency Air Conditioner Recirculation Air Filter)
(212) (High-efficiency Air Conditioner Recirculation Air Filter)
Fire Extinguisher
(English, Text Type)
(Persian-English)
First Aid Box
Thermos Bottle
Cab
Cab Body and Window (Front Fixed Window)
Cab Body and Window (RH. and Rear Fixed Window,With KOMTRAX, 3G or KOMTRAX, GPRS)
Cab Body and Window (RH. and Rear Fixed Window,With KOMTRAX, ORBCOMM)
Cab Body and Window (Vandalism Protection,Extreme Cold Area Specification (~40 deg C))
Cab Body and Window (Vandalism Protection,With KOMTRAX, ORBCOMM)
Cab Body and Window (RH. and Rear Fixed Window)
Cab Body and Window (RH. and Rear Fixed Window,For China)
Front Window (Extreme Cold Area Specification (~40 deg C))
Front Window (Front Fixed Window)
Front Window
Front Lower Window
Roof Window (ROPS Cab, Front Fixed Window)
Roof Window (With KOMTRAX, IRIDIUM, Russia)
Roof Window
Door (With KOMTRAX, IRIDIUM, Russia)
Door (With KOMTRAX, ORBCOMM)
Door Lock
Open Lock and Door Catch
Open Lock and Door Catd’i
Open Lock and Door Catch (Extreme Cold Area Specification (~40 deg C))
Wiper and Room Lamp
Rubber Antenna
Speaker and Window Washer
Speaker and Window Washer (Extreme Cold Area Specification (~40 deg C))
Roof Cover and Air Intake (Front Fixed Window)
Roof Cover and Air Intake (Extreme Cold Area Specification (-40 deg C))
Roof Cover and Air Intake
Roof Cover and Air Intake (For China)
Roof Cover and Air Intake (For Loading Shovel)
Pressure Valve and Grip
KOMTRAX Antenna (With KOMTRAX, ORBCOMM,2~AdditionaI Actuator Piping, Accum uiator)
Cab in Parts, Monitor and Cover
KOMTRAX Antenna
KOMTRAX Antenna (With Auto Air Conditioner, Big Wind Quantity)
KOMTRAX Antenna (With KOMTRAX, 3G or KOMTRAX, GPRS)
KOMTRAX Antenna (With KOMTRAX, iRIDIUM, Russia)
KOMTRAX Antenna (With KOMTRAX, ORBCOMM,For China)
Plug and Outside Seal
Cab In Parts, Rear Cover
Cab In Parts, Rear Cover (With KOMTRAX, ORBCOMM)
Cab In Parts, Rear Cover (Vlfith KOMTRAX, ORBCOMM)
Cab In Parts, Rear Cover, With 12v Converter
Cab In Parts, Rear Cover (Vlfith KOMTRAX, 3G or KOMTRAX, GPRS)
Cab In Parts, Rear Cover, With 12v Converter (Extreme Cold Area Specification (~40 deg 0))
Floor, Frame
Floor, PPC Valve for Travel (112)
Floor, Frame (Extreme Cold Area Specification (~40 deg C))
PPC Valve for Travel (112)
Floor, PPC Valve for Travel (212)
Floor, Travel Control
PPC Valve for Travel (212)
PPC Valve (114) (Extreme Cold Area Specification (~40 deg C))
Floor, PPC Valve for 2-Attachment
PPC Valve (214) (Extreme Cold Area Specification (~40 deg C))
Floor, 2nd Attachment Control
Floor, Footrest, L.H.
Floor, Travel Control (Extreme Cold Area Specification (-40 deg C))
Floor, Footrest, RH.
PPC Valve for 1-Attachment
PPC Valve for 1~Attachment
Floor, 1st Attachment Control
Floor, 1st Attachment Control (With 2-Additional Actuator Piping, Accumulator)
Floor, Base
PPC Valve (315) (Extreme Cold Area Specification (~40 deg C))
Floor, 1st Attachment Control (Extreme Cold Area Specification (~40 deg C))
Floor, Base (Extreme Cold Area Specification (~40 deg C))
Floor, Wiring Harness (For EU Arrangement)
Floor, Wiring Harness
Floor, Wiring Harness (For Loading Shovel)
Floor, Wiring Harness (With Auto Air Conditioner, Big Wind Quantity)
Floor, Wiring Harness Clamp and Ground
Floor, Wiring Harness (With Heater and Defroster, Fuel Combustion Type)
Floor, Window Washer Hose
Floor, Wiring Harness Clamp and Ground (Extreme Cold Area Specification (~40 deg C))
Floor, Lever, LH. (With Short Lever, For Turkey)
Floor, PPC Valve for Work Equipment, L.H. (For Loading Shovel)
Floor, Window Washer Hose (Extreme Cold Area Specification (-40 deg C))
Floor, Work Equipment Control Lever, L.H.
Floor, Lever, L.H. (Extreme Cold Area Specification (-40 deg C))
Floor, PPC Valve for Work Equipment, L.H.
PPC Valve for Work Equipment, L.H.
PPC Valve for Work Equipment, L.H. (With Short Lever, For Turkey)
Work Equipment Lever L.H. (For Loading Shovel)
Floor, Valve, L.H.
Floor, Valve, L.H. (With Short Lever, For Turkey)
PPC Valve (314) (Extreme Cold Area Specification (~40 deg C)) (L.H.)
Floor, Console, L.H.
Floor, Console, L.H. (EU Arrangement)
Floor, Console, L.H. (For Loading Shovel)
Floor, Valve, L.H. (Extreme Cold Area Specification (~40 deg C))
Floor, PPC Lock Lever and Radio (AM-FM Radio for Asia,For Loading Shovel)
Floor, PPC Lock Lever
Floor, PPC Lock Lever and Radio (AM-FM Radio for Asia)
Floor, Armrest, L.H.
Floor, PPC Lock Lever and Radio (AM~FM Radio for Asia)
Floor, Armrest, L.H. (For Loading Shovel)
Floor, PPC Lock Lever and Radio (With AM-FM Radio for North America)
Floor, Lever, RH. (With Short Lever, For Turkey)
Floor, PPC Valve for Work Equipment, RH. (For Loading Shovel)
Floor, Work Equipment Control Lever, RH.
Floor, Lever, R.H. (Extreme Cold Area Specification (~40 deg C))
Floor, PPC Valve for Work Equipment, RH.
PPC Valve for Work Equipment, RH.
PPC Valve for Work Equipment, RH. (With Short Lever, For Turkey)
Work Equipment Lever RH. (For Loading Shovel)
Floor, Valve, RH.
Floor, Valve, RH. (With Short Lever, For Turkey)
PPC Valve (414) (Extreme Cold Area Specification (-40 deg C)) (R.H.)
Floor, Console, RH.
Floor, Console, RH. (For China)
Floor, Console, RH. (For Loading Shovel)
Floor, Console, RH. (With Amber Color Warning Beacon)
Floor, Console, RH. (With Auto Air Conditioner, Big Wind Quantity)
Floor, Console, RH. (With Short Lever, For Turkey)
Floor, Valve, RH. (Extreme Cold Area Specification (~40 deg C))
Floor, Armrest, RH.
Floor, Armrest, RH. (For Loading Shovel)
Floor, Console, RH. (With Heater and Defroster, Fuel Combustion Type)
Floor, Air Conditioner
Floor, Switch (Extreme Coid Area Specification (~40 deg C))
Floor, Air Conditioner Unit
Floor, Air Conditioner Piping
Floor, Heater Unit
Floor, Heater Piping
Floor, Heater Piping (With Heater and Defroster, Fuel Combustion Type)
Floor, PPC Piping for Travel Valve
Floor, PPC Piping for Travel Valve (Extreme Cold Area Specification (~40 deg C))
Floor, PPC Piping for Travel Valve (For China)
Floor, PPC Piping for Pilot Valve
Floor, PPC Piping for Pilot Valve (Extreme Cold Area Specification (-40 deg C))
Floor, PPC Piping for Pilot Valve (For China)
Floor, PPC Piping Clamp (Extreme Cold Area Specification (-40 deg C))
Floor, PPC Piping Clamp
Floor, P, T Block and Seal
Floor, P, T Block and Seal (Extreme Cold Area Specification (~40 deg C))
Floor, P, T Block and Seal (Extreme Cold Area Specification (~40 deg C),\Mth 1-Additional
Floor, P, T Block and Seal (With 1-Additional Actuator Piping, Accumulator)
Floor, P, T Block and Seal (With 2-Additionai Actuator Piping, Accumulator)
Rear Camera
Floor Mounting
Proportional Pressure Control (PPC) Piping
(Additional Actuator Piping, Accumulator)
(With 1-Service Valve)
Mode Selection Connectors
GUARDS AND COVERS
Engine Hood
Catcher and Stay
Catcher and Stay (Extreme Cold Area Specification (~40 deg C))
Frame (Dust-proof Net, Intake Gas and Exhaust Gas)
Frame (Extreme Cold Area Specification (-40 deg C))
Frame
Frame (EU New Noise Arrangement 2)
Louver
Louver (Dust-proof Net, Intake Gas and Exhaust Gas)
Louver (EU New Noise Arrangement 2)
Louver (Extreme Cold Area Specification (~40 deg C))
Sheet (Dust-proof Net, Intake Gas and Exhaust Gas)
Sheet (EU New Noise Arrangement 2)
Hood, Net (Dust-proof Net, Intake Gas and Exhaust Gas)
(For EN ISO Access 2011)
Side Cover L.H.
(113) (For EN ISO Access 2011)
Partition
(112) (Extreme Cold Area Specification (~40 deg C))
(22) (Extreme Cold Area Specification (~40 deg C))
Machine Cab Cover
Cover and Duct
Inner Parts, Pre-cleaner
Upper Cover
(112) (Pre-cleaner)
(212) (Pre-cieaner)
Battery Case
(EU Arrangement)
Handrail
Rearview Mirror L.H.
Rearview Mirror RH.
Rearview Mirror
(AdditionaI,R.H.)
(EU Safety Regulation,Rearview Mirror, RH.)
Counterweight
Counterweight Mounting
Under Cover
(113) (Heavy Duty Type)
(113) (Heavy Duty Type,With Refueling Pump)
(113) (With Refueling Pump)
(213) (Extreme Cold Area Specification (-40 deg C))
(213) (Heavy Duty Type)
(213) (Heavy Duty Type,With Refueling Pump)
(313) (Extreme Cold Area Specification (-40 deg C))
(313) (Heavy Duty Type)
(313) (Heavy Duty Type,With Refueling Pump)
(313) (With Refueling Pump)
SWING CIRCLE AND ITS RELATED PARTS
Swing Circle
Swing Machinery and Motor
Inner Parts, Swing Motor (113)
Inner Parts, Swing Motor (113) (Extreme Cold Area Specification (~40 deg C))
Inner Parts, Swing Motor (113) (For China)
Inner Parts, Swing Motor (213)
Inner Parts, Swing Motor (213) (Extreme Cold Area Specification (~40 deg C))
Inner Parts, Swing Motor (313)
Inner Parts, Swing Motor (313) (Extreme Cold Area Specification (-40 deg C))
Swing Motor Connecting Parts
Swivel Joint
Inner Parts, Swivel Joint (Extreme Cold Area Specification (~40 deg C))
Related Parts
Related Parts (Extreme Cold Area Specification (~40 deg C))
TRAVEL SYSTEM AND ITS RELATED PARTS
(Track Frame, Variable Gauge Type)
Travel Motor and Final Drive
Inner Parts, Travel Motor (113) (Extreme Cold Area Specification (~40 deg C))
Travel Motor, L.H. (113)
Inner Parts, Travel Motor (213) (Extreme Cold Area Specification (~40 deg C))
Travel Motor, L.H. (213)
Inner Parts, Travel Motor (313) (Extreme Cold Area Specification (~40 deg C))
Travel Motor, L.H. (313)
Final Drive L.H.
Final Drive (Extreme Cold Area Specification (~40 deg C))
Travel Motor, RH. (113)
Travel Motor, RH. (213)
Travel Motor, RH. (313)
Final Drive RH.
UNDERCARRIAGE
Front Idler and Idler Cushion
(212) (Rustproof Spring LV2)
Track Roller
Carrier Roller
Track Shoe Assembly
(Holed Triple Grouser Shoe, Heavy Duty Type, 700mm Width, Grease Sealed Type, 92 Set)
(Oblong Hoied Triple Grouser Shoe, 600mm Width, Grease Sealed Type, 92 Set)
(Oblong Hoied Triple Grouser Shoe, 700mm Width, Grease Sealed Type, 92 Set)
(Oblong Hoied Triple Grouser Shoe, 800mm Width, Grease Sealed Type, 92 Set)
(Oblong Hoied Triple Grouser Shoe, Heavy Duty Type, 600mm Width, Grease Sealed Type, 92
Set)
(Oblong Hoied Triple Grouser Shoe, Heavy Duty Type, 800mm Width, Grease Sealed Type, 92
(Single Grouser Shoe, 660mm Width, Grease Sealed Type, 92 Set)
Track Link Assembly
(Supply Only, 92 Set,Grease Sealed Type)
Track Frame
Frame (Extreme Cold Area Specification (~40 deg C))
Frame (Extreme Cold Area Specification (~40 deg C),With Under Cover)
Frame (Under Cover)
Frame (Under Cover,EN 180 Access 2011)
Frame (Variable Gauge Type)
Frame (Variable Gauge Type,Under Cover)
Grease Bath and Mounting Parts
Grease Bath and Mounting Parts (Extreme Cold Area Specification (~40 deg C))
Grease Bath and Mounting Parts (Under Cover,EN ISO Access 2011)
Grease Bath and Mounting Parts (Variable Gauge Type)
Track Frame Under Cover
Travel Motor Guard
Track Roller Guard
(Full Length)
Center Guard
WORK EQUIPMENT
Boom
Boom and Bushing (6670mm)
Boom and Bushing (6700mm)
Boom and Bushing (7000mm Heavy Duty Type, 1-Attachment, Extremely Cold Area Specification
(~50 deg C))
Boom and Bushing (7000mm Heavy Duty Type, Extremely Cold Area Specification (~40 deg C)) ..
Boom and Bushing (7000mm, 100 Hours Lubrication interval)
Boom and Bushing (7000mm, 500 Hours Lubrication Interval)
Boom and Bushing (7000mm, KUK)
Boom and Bushing (Loading Shovel)
Boom and Bushing (Loading Shovel,Extreme Cold Area Specification (-50 deg C))
Boom and Bushing (7000mm Heavy Duty Type)
Boom and Bushing (7000mm Heavy Duty Type, 100 Hours Lubrication Interval)
Arm Cylinder Piping G.oading Shovel)
Arm Cylinder Piping G_oading Shovel,Extreme Cold Area Specification (~50 deg C))
Top Pin and Bottom Pin (100 Hours Lubrication Interval)
Top Pin and Bottom Pin (500 Hours Lubrication Interval)
Bucket Cylinder Piping (6670mm)
Bucket Cylinder Piping (6700mm)
Bucket Cylinder Piping (7000mm Heavy Duty Type)
Bucket Cylinder Piping (7000mm Heavy Duty Type, 1-Attachment)
Bucket Cylinder Piping (7000mm Heavy Duty Type, 1-Attachment, Extremely Cold Area
Specification (~50 deg C))
Bucket Cylinder Piping (7000mm Heavy Duty Type, Extremely Cold Area Specification (-40 deg
Bucket Cylinder Piping (7000mm)
Bucket Cylinder Piping (7000mm, KUK)
Bucket Cylinder Piping (Loading Shovel)
Bucket Cylinder Piping (Loading Shovel,Extreme Cold Area Specification (~50 deg C))
Arm Cylinder Piping (7000mm Heavy Duty Type, 1-Attachment, Extremely Coid Area
Specification (-50 deg C))
Arm Cylinder Piping (7000mm Heavy Duty Type, Extremely Cold Area Specification (~40 deg C))
Bucket Cylinder Bottom Piping (112) (Loading Shovel)
Bucket Cylinder Bottom Piping (112) (Loading Shovel,Extreme Cold Area Specification (-50 deg
Arm Cylinder Piping (6670mm)
Arm Cylinder Piping (6700mm)
Arm Cylinder Piping (7000mm Heavy Duty Type)
Arm Cylinder Piping (7000mm, 100 Hours Lubrication Interval)
Arm Cylinder Piping (7000mm, 500 Hours Lubrication Interval)
Arm Cylinder Piping (7000mm, KUK)
Blind Parts (6670mm)
Blind Parts (6700mm)
Blind Parts (7000mm Heavy Duty Type)
Blind Parts (112) (7000mm Heavy Duty Type, 1-Attadiment, Extremely Cold Area Specification (-
50 deg C))
Blind Parts (7000mm Heavy Duty Type, Extremely Cold Area Specification (~40 deg C))
Blind Parts (7000mm)
Bucket Cylinder Bottom Piping (212) (Loading Shovel)
Bucket Cylinder Bottom Piping (212) (Loading Shovel,Extreme Cold Area Specification (~50 deg
Lubrication Piping (6670mm)
Lubrication Piping (7000mm Heavy Duty Type)
Lubrication Piping (7000mm)
Lubrication Piping (Loading Shovel)
Lubrication Piping (Loading Shovel,Extreme Cold Area Specification (~50 deg C))
Working Lamp Wiring Harness (Loading Shovel)
Working Lamp Wiring Harness (Loading Shovel,Extreme Cold Area Specification (~50 deg C))
Working Lamp and Spacer (7000mm Heavy Duty Type, Extremely Cold Area Specification (-40
deg C))
Working Lamp and Spacer
Working Lamp and Spacer (7000mm Heavy Duty Type, 1-Attachment, Extremely Cold Area
Working Lamp and Spacer (7000mm, 500 Hours Lubrication Interval)
For Additional Piping
For Additional Piping (Extremely Cold Area Specification)
Pin (Loading Shovel)
Bucket Cylinder Piping, Hose (Loading Shovel)
Bucket Cylinder Piping, Hose (Loading Shovel,Extreme Cold Area Specification (~50 deg C))
Clamp
Clamp (7000mm Heavy Duty Type, 1-Attachment, Extremely Cold Area Specification (-40 deg C))
Clamp (Extremely Cold Area Specification)
Blind Parts (212)
Blind Parts (212) (7000mm Heavy Duty Type, 1-Attachment, Extremely Cold Area Specification (-
Lubrication Piping, Hose (Loading Shovel)
Working Lamp and Seal (Loading Shovel)
Working Lamp (Loading Shovel,Extreme Cold Area Specification (~50 deg C))
Boom Cylinder
Inner Parts, Boom Cylinder, L.H. (Extreme Cold Area Specification (-40 deg C))
L.H. (Anti-drop Valve)
L.H. (Loading Shovel)
Inner Parts, Boom Cylinder, RH. (Extreme Cold Area Specification (~40 deg C))
RH. (7000mm Boom)
RH. (Anti-drop Valve)
RH. (Loading Shovel)
Boom Cylinder Head Pin
Arm Cylinder
(7000mm Heavy Duty Type, 1-Attachment)
(7000mm Heavy Duty Type, 100 Hours Lubrication Interval)
(7000mm, 1-Attachment, 500 Hours Lubrication Interval)
(7000mm, 100 Hours Lubrication Interval)
(7000mm, 500 Hours Lubrication Interval)
(Spanish,With Additional Actuator Piping, Accumulator,For Montabert Breaker Kit,Nippon
Pneumatic Breaker Kit)
Caution Plates, Backward
(English, Text Type,With Rearview Camera)
(Pictorial Type,With Rearview Camera)
Caution Plates
(Engiish,With Power Supply, 12voit)
(For Montabert Breaker Kit,Nippon Pneumatic Breaker Kit)
(With Power Supply, 12volt,For EU Safety Regulation)
(With Power Supply, 12volt,For Montabert Breaker Kit,Nippon Pneumatic Breaker Kit)
Freon Regulation Plate
AUXILIARY PARTS AND TOOL
Spare Parts
(Extreme Cold Area Specification (-50 deg C))
Cap and Overall
General Tool Set
(EU Safety Regulation)
(Extreme Cold Area Specification (~40 deg C),With Coolant Filter)
OTHER EQUIPMENT
Preventive Maintenance Service Connectors
Preheater
Heater and Mounting (112)
Heater and Mounting (112) (Extreme Cold Area Specification (~40 deg C))
Heater and Mounting (212)
Heater and Mounting (212) (Extreme Cold Area Specification (-40 deg C))
Duct (Extreme Cold Area Specification (~40 deg C))
Water Pump
Sub-tank (Extreme Cold Area Specification (~40 deg C))
Switch Panel
Sub-tank
Refueling Pump
Grease Pump
Flushing Parts and Engine Drain Hose
FIELD REPAIR SERVICE PARTS
Service Kit Parts
