Krupp Crane KMK 4070 Spare Parts List 10.1990 DE EN

Description

Contents:
Chassis
Attaching Parts For Frame
Engine Suspension, Assembly
Covering, Assembly
Axle Attachment
Axle Drive
Wheel Drive Left
Brake
Wheel Drive Right
Axle Drive
Wheel Hub, Left
Wheel Hub, Right
Wheel Cpl. (Selection)
Axle Attachment
Wheel Cpl. (Selection)
Steering
Steering Rod
Hydr. Pipe Diagram, Steering
Assembly
Pump, Oil-Tank, Accessories
Pumps And Oil-tank—Mounting
Hose Assemblies, Steering
Chassis (Pump Oil Tank)
Hydraulic Steering, Chassis
Hose Assemblies, Steering
Chassis
Hydr. Pipe Diagram For All-
Wheel Steering
Hose Assemblies, Ail—Wheel
Steering
Control
Driver’s Cab, Assembly
Door Left
Door Right
Windscreen Washer System
Windscreen Wiper
Ball Bearing Slewing Gear
Heating System, Chassis
Warm Water Heating Appliance
Supporting Cpl.
Supporting Front
Supporting Behind
Engine- And Gear Assembly
Engine Assembly, Driving Head
Diesel Engine
Radiator Mounting
Pump Distributor Gear
Gear Mounting 5 Hp 600
Gear 5 Hp 600
Distributor Gear Mounting
Accessories Engine
(Exhaust, Air Filter, Fuel Tank)
Compressed Air System, Chassis
(Page 1)
Compressed Air System, Chassis
Axle Area)
Hydr. Pipe Diagram, Chassis
Pumps, Slewing Gear And
Accessories
Hose Assemblies, Chassis
(Pumps, Slewing Gear And
Accessories)
Pump Mounting
Hydr. Plant, Support
Hose Assemblies, Chassis
(Support)
Hydr.—Pneum. Springing
Shock Absorbing Strut
Hose Assemblies, Chassis
(Springing)
Fan Drive
Hose Assemblies, Chassis
(Fan Drive)
Hydr. Pipe Diagram, Driver’s
Cab Tipping Device
Electr. Construction, Chassis
Headlight
Control Units For Support
Feeler-Integral Parts For
Support, Left
Driver’s Cab Switching
Electr. Parts, Chassis
Level-Regulation
Peeler—Integral Parts For
Support, Right
Electr. Contruct. Driver’s Cab
Slideein Unit. 1 A
Slide—In Unit 2.1a
Slide—In Unit 3.4a
Slide—In Unit 6.La
Slide«In Unit 7.2a
Slide-In Unit 9 A
Slide-In Unit 10.2a
Electr. Parts Driver’s Cab
Electr. Parts, Car Radio Recei-
Ver, Two Man Cabin
Slide—In Unit, Level Regulation
Slide—In Unit, Separate Steering
Slide«In Unit Drive
Accessories Chassis
Hydr. Steering Turntable
Steering
Attaching Parts For Turntable
Counterweight
Counterweight
Crane Cabin
Sliding Door
Heating System, Crane Cabin
Air Heating Appliance
Main Hoisting Gear
Hoisting Gear
Slewing Gear
Electr. Construct. Lmb (Turnt.)
Central—Unit
Measured Valvue Transmitter
Compressed Air System, Turnt.
Hydr. Pipe Diagram, Turntable
Uil Tank Mounting
Hose Assemblies
(Mounting Oil Tank)
Valve Unit
Hose Assemblies
(Valve Unit)
Crane Control
Main Hoisting Gear
Hose Assemblies
(Main Hoisting Gear)
Luffing Gear
(Luffing Gear)
Slewing Gear- And Counterweight
Hoisting Gear
Long-Distance Anticipat. Contr.
Hose Assemblies Turntable L
(Slewing Gear) I
Electr. Construction Turntable
Feeler—Integral Counterweight
Electr. Constr. Crane Cabine
Slideein Unit 3 A
Slide—In Unit 5.2a
Slide—In Unit 6 A
Slide-In Unit 7.8a
Slide~In Unit 9.5a
Slide—In Unit 10 A
Slide—In Unit 18.3a
Slide-In Unit 19.2a
Slide-In Unit 20.1a
Electr. Parts Crane Cabin
Wire Ropes And Accessories
Accessories Turntable
Jib
Jib Component Parts
Component Parts (Luffing Cyl.)
Electr. Construction Lmb (Jib)
(Page 2)
Jib Unit
Cable Drum 2.
Cable Drum 3
Hydr. Pipe Diagram, Telescopic
Gear
Electr. Parts Jib
Equipment
Set Of Completion
Tools
Toolbox, Cpl.
Plates And Symbols (Chassis)
Plates And Symbols (Turntable)
Wheel, Cpl. (Selection)
Hooks Blocks
Bolton Book Block 70 T With
Double Hook
Bottom Book Block 45 T With
Double Hook
Bottom Book Block 45 T
Bottom Book Block 18 T
Swivel Hook 12 T
Swivel Book 8 T
Auxiliary Hoisting Gag;
Auxiliary Hoisting Gear Cpl.
Auxiliary Hoisting Gear
Hoisting Gar
Hydr. Pipe Diagram, Auxiliary
Rebuilding Set For Auxiliary
Wire Ropes And Accessories
.[I’ Jib Folded
Hinged Jib 10—16 M
Hinged Jib, Mounting Parts
Hearing Block
Hinged Jib, 30′ Mounting
Electr. Construction, Hinged
Auxiliary Heater Driver’s Cab
Heating
Heating
Oil Cooler
Oil Cooler Mounting
Hydr. Pipe Diagram, Oil Cooling
Electr. Parts For Oil Radiator
Marking
Plates, (Chassis)
Plates, (Turntable)
Trailer Coupling
Trailer Coupling, Cpl.
Compressed Air System Chassis
Compressed Air System Axle Area
Compressed Air System Trailer
Control
Reserve Wheel Holder
