Krupp Crane KMK 4070 Spare Parts List 8.1989 DE EN

Description

Contents:
Chassis
Attaching Parts For Frame
Covering
Engine Suspension, Assembly
Axle Attachment
Axle Drive
Wheel Drive Left
Wheel Drive Right
Brake
Wheel Cpl. (Selection)
Steering
Steering Rod
Hydr. Pipe Diagram, Steering
Assembly
Pump, Oil—Tank, Accessories
Pumps And Oil-Tank—Mounting
Hydraulic Steering, Chassis Fr.
Hose Assemblies, Steering
Chassis (Pump Oil Tank)
Hose Assemblies, Steering
Chassis
Hydr. Pipe Diagram For All—
Wheel Steering
Hose Assemblies, All—Wheel
Steering
Control
Driver’s Cab, Assembly
Door Left
Door Right
Windscreen Washer System
Windscreen Wiper
Ball Bearing Slewing Gear
Heating System, Chassis Frame
Warm Water Heating Appliance
Warm Water Heating Appliance
Supporting Cpl.
Supporting Front
Supporting Behind
Engine— And Gear Assembly
Engine Assembly , Driving Head
Diesel Engine
Radiator Mounting
Pump Distributor Gear
Gear Mounting 5 Hp 600
Gear 5 Hp 600
Distributor Gear Mounting
Accessories Engine
(Exhaust, Air Filter, Fuel Tank
Compressed Air System, Chassis
(Page 1)
Compressed Air System, Chassis
(Axle Area)
Hydr. Pipe Diagram, Chassis Fr.
Pumps, Slewing Gear And
Accessories
Hose Assemblies, Chassis Frame
(Pumps, Slewing Gear And
Accessories)
Pump Mounting
Hydr. Plant, Support
Hose Assemblies, Chassis Frame
(Support)
Hydr.-Pneum. Springing
Shock-Absorbing Strut
Hose Assemblies, Chassis Frame
(Springing)
Fan Drive
Hose Assemblies, Chassis Frame
(Fan Drive)
Hydr. Pipe Diagram, Driver’s
Cab Tipping Device
Electr. Construction, Chassis
Frame
Headlight
Control Units For Support
Feeler-Integral Parts For
Support, Left
Driver‘s Cab Switching
Electr. Parts, Chassis
Level—Regulation
Laced Wiring Harness Terminal
Peeler—Integral Parts For
Support, Right
Electr. Contruct. Driver’s Cab
Slide—In Unit 1 A
Slide—In Unit 2 A
Slide—In Unit 3.4a
Slide—In Unit 6.La
Slide—In Unit 7.2a
Slide-In Unit 9 A
Slide—In Unit 10.2a
Electr. Parts Driver’s Cab
Electr. Parts, Car Radio Receiver, Two Man Cabin
Slide—In Unit, Level Regulation
Slide-In Unit, Separate Steering
Slide—In Unit Drive
Accessories Chassis
Hydr. Steering Turntable
Steering
Attaching Parts For Turntable
Counterweight
Counterweight
Crane Cabin .
Sliding Door
Heating System, Crane Cabin
Air Heating Appliance
Main Hoisting Gear
Hoisting Gear
Slewing Gear
Electr. Construct. Lmb (Turntab)
Central Unit
Measured Valvue Transmitter
Compressed Air System, Turnt.
Hydr. Pipe Diagram, Turntable
Oil Tank Mounting
Hose Assemblies
(Mounting Oil Tank)
Valve Unit
Hose Assemblies
(Valve Units)
Crane Control
Main Hoisting Gear
Hose Assemblies
(Main Hoisting Gear)
Luffing Gear
Hose Assemblies
(Luffing Gear)
Slewing Gear— And Counterweight
Hoisting Gear .
Hose Assemblies
(Slewing Gear And Counterweight
Hoisting Gear)
Long—Distance Anticipat. Contr.
Hose Assemblies Turntable
(Slewing Gear)
Electr. Construction Turntable
Peeler-Integral Counterweight
Electr. Constr. Crane Cabins
Slide—In Unit 3 A
Slide—In Unit 5.2a
Slide~In Unit 6 A
Slide—In Unit 7.5a
Slide—In Unit 9.5a ‘
Slide-In Unit 10 A
Slide-In Unit 18.3a
Slide—In Unit L9.2a
Slide—In Unit 20.1a
Electr. Parts Crane Cabin
Wire Ropes And Accessories 1
Accessories Turntable
Jib
Jib Component Parts
Component Parts (Luffing Cyl.)
Electr. Construction Lmb (Jib)
Jib Unit
Cable Drum 2
Cable Drum 3
Hydr. Pipe Diagram, Telescopic
Gear
Electr. Parts Jib
Equipment
Set Of Completion
Tools
Toolbox, Cpl.
Plates And Symbols (Chassis)
Plates And Symbols (Turntable)
Wheel, Cpl. (Selection)
Hooks Blocks
Bottom Hook Block 70 T
Bottom Hook Block 45 T With
Double Hook
Bottom Hook Block 45 T
Bottom Hook Block L8 T
Swivel Hook 12 T
Swivel Hook 8 T
Auxiliary Hoisting Gear
Auxiliary Hoisting Gear Cpl.
Auxiliary Hoisting Gear
Hoisting Gear
Hydr. Pipe Diagram, Auxiliary
Rebuilding Set For Auxiliary
Hoisting Gear
Wire Ropes And Accessories
Fly Jib Folded
Hinged Jib L0-L6 M
Hinged Jib, Mounting Parts
Bearing Block
Electr. Construction, Hinged
Jib
Auxiliary Heater Driver’s Cab
Heating
Oil Cooler
Oil Cooler Mounting
Hydr. Pipe Diagram, Oil Cooling
Electr. Parts For Oil Radiator
Marking
Plates, (Chassis)
Plates, (Turntable)
