Name: Kubota Backhoe BH77 Australia Parts Catalog
SKU: 561156
Availability: InStock

Kubota Backhoe BH77 Australia Parts Catalog (1)

Kubota Backhoe BH77 Australia Parts Catalog (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

Kubota Backhoe BH77 Australia Parts Catalog

Size: 86.7 MB

Format: PDF

Language: English

Brand: Kubota

Type of Machine: Backhoe

Type of Manual: Parts Catalog

Model: Kubota BH77 Backhoe

Region: Australia

Number of Pages: 121 Pages

10 USD

Tags: BH77, Kubota Backhoe Manual, Kubota Parts Catalog

Description

Description

Contents:
Frame _ B04100 Main Frame
Frame _ B04500 Swing Frame
Front Attachments _ B05000 Swing Cylinder
Front Attachments _ B10000 Boom
Front Attachments _ B11000 Dipperstick
Front Attachments _ B12000 Bucket Link
Front Attachments _ B15001 Bucket ## [BT1950A]
Front Attachments _ B15002 Bucket ## [BT1951A]
Front Attachments _ B15003 Bucket ## [BT1952A]
Front Attachments _ B15004 Bucket ## [BT1953A]
Front Attachments _ B16000 Stabilizer Arm
Control Valve _ B20000 Control Valve
Control Valve _ B21000 Control Valve [Component Parts]
Hydraulic System _ B22000 Hydraulic Hose(Inlet_Outlet)
Hydraulic System _ B23000 Hydraulic Hose(Swing)
Hydraulic System _ B24000 Hydraulic Hose(Boom_Dipper)
Hydraulic System _ B25000 Hydraulic Hose(Bucket)
Hydraulic System _ B26000 Hydraulic Hose(Stabilizer)
Hydraulic Cylinder _ B31000 Cylinder(Swing) [Component Parts] ## S.No._=D1101 S.No.;_=D1101
Hydraulic Cylinder _ B31001 Cylinder(Swing) [Component Parts] ## S.No._=D1102 S.No.;_=D1102
Hydraulic Cylinder _ B32000 Cylinder(Boom) [Component Parts] ## S.No._=D1244 S.No.;_=D1244
Hydraulic Cylinder _ B32001 Cylinder(Boom) [Component Parts] ## S.No._=D1245 S.No.;_=D1245
Hydraulic Cylinder _ B33000 Cylinder(Dipper) [Component Parts] ## S.No._=D1643 S.No.;_=D1643
Hydraulic Cylinder _ B33001 Cylinder(Dipper) [Component Parts] ## S.No._=D1644 S.No.;_=D1644
Hydraulic Cylinder _ B34000 Cylinder(Bucket) [Component Parts] ## S.No._=D0750 S.No.;_=D0750
Hydraulic Cylinder _ B34001 Cylinder(Bucket) [Component Parts] ## S.No._=D0751 S.No.;_=D0751
Hydraulic Cylinder _ B35100 Cylinder(Stabilizer LH) [Component Parts] ## S.No._=C9927 S.No.;_=C9927
Hydraulic Cylinder _ B35101 Cylinder(Stabilizer LH) [Component Parts] ## S.No._=C9928 S.No.;_=C9928
Hydraulic Cylinder _ B35200 Cylinder(Stabilizer RH) [Component Parts] ## S.No._=C9927 S.No.;_=C9927
Hydraulic Cylinder _ B35201 Cylinder(Stabilizer RH) [Component Parts] ## S.No._=C9928 S.No.;_=C9928
Operator’s Platform _ B40000 Step (B3150 Rops,B3150su Rops) ## [BH4962(D26r),BH4963(D26s)]
Operator’s Platform _ B41000 Seat ## [BH4988,BH4986 Not Include Ref.No.180]
Operator’s Platform _ B41501 Seat Support (B3150 Rops) ## [BH4962(D26r)]
Operator’s Platform _ B41502 Seat Support (B3150su Rops) ## [BH4963(D26s)]
Operator’s Platform _ B42000 Seat Support [Component Parts-1] (B3150 Rops,B3150su Rops) ## [BH4962(D2
Operator’s Platform _ B42100 Seat Support [Component Parts-2] (B3150 Rops,B3150su Rops) ## [BH4962(D2
Operator’s Platform _ B45000 Control Cover
Control Lever _ B51001 Control Lever (L3200,L3800,L3240-3,L3800)
Control Lever _ B51002 Control Lever (B3150 Rops,B3150su Rops) ## [BH4962(D26r),BH4963(D26s)]
Control Lever _ B51100 Control Rod
Control Lever _ B52000 Stabilizer Control Lever
Labels _ B71000 Labels
Option _ B81101 Mount Kit-1 (L3200,L3800) ## [BH4988]
Option _ B81102 Mount Kit-2 (L3200,L3800) ## [BH4988 Not Include Ref.No.120 To 160]
Option _ B81201 Mount Kit-1 (L3240-3,L3540-3) ## [BH4986]
Option _ B81202 Mount Kit-2 (L3240-3,L3540-3) ## [BH4986]
Option _ B81203 Mount Kit-3 (L3240-3,L3540-3) ## [BH4986]
Option _ B81301 Mount Kit-1 (B3150 Rops,B3150su Rops) ## [BH4962(D26r),BH4963(D26s)]
Option _ B81302 Mount Kit-2 (B3150 Rops,B3150su Rops) ## [BH4962(D26r),BH4963(D26s)]
Option _ B89000 Thumb Arm Kit [Option] ## [BH1976]
