Landini Tractor REX 4-080GE to REX 4-120GT Service Manual 6705558A1 EN

Size: 430.17 MB

Format: PDF

Language: English

Brand: Landini

Type of Machine: Tractor

Type of Manual: Service Manual, Hydraulic and Electrical Diagrams

Model: Landini Tractor

Rex 4GE Series: Rex 4-080GE, Rex 4-090GE, Rex 4-100GE, Rex 4-110GE, Rex 4-120GE

Rex 4GB Series: Rex 4-080GB, Rex 4-090GB, Rex 4-100GB, Rex 4-110GB, Rex 4-120GB

Rex 4F Series: Rex 4-080F, Rex 4-090F, Rex 4-100F, Rex 4-110F, Rex 4-120F

Rex 4GT Series: Rex 4-080GT, Rex 4-090GT, Rex 4-100GT, Rex 4-110GT, Rex 4-120GT

Part Number: 6705558A1

Publication Date: 2022

Number of Pages: 2976 Pages

150 USD

Tag: Landini Manual

Description

Description

Contents:
– Rex 4 Ge-Gb-F-Gt
Introduction
Liability
Purpose Of The Manual
Copyright
Table Of Contents
– 1001 – Safety
Introduction
Technical Notes
Maintain The Tractor In A Safe Way
Danger Signs
Tightening Torques
– 1002 – Specific Equipment Catalogue
Specific Equipment
– 2000 – Engine
Technical Specifications
Annexes
– 2002 – Exhaust Gas Treatment System
Technical Specifications
Safety
Ats System
AdblueÂ®
– 3005 – Tanks And Reservoirs
Technical Specifications
Safety
Procedures
– 4001 – Electric System
Technical Specifications
Safety
Fuses And Relays
Overview Of Controls
Sockets Overview
Lights Overview
Component Sheets
Wiring Harnesses Locations
Information On Wiring Diagrams
Wiring Diagrams
– 4002 – Instrument Cluster Control Unit Setup And Calibrations
General Instrument Cluster Specifications
Calibration From The Instrument Cluster
Calibrations With The Diagnostic Tool
– 5000 – Steering System – Operation
Steering System
– 5001 – Steering Column And Power Steering System
Sections And Perspective Views
Safety
Steering Column And Power Steering System
– 6000 – Transmission – Operation
Transmission
Transmission With Mechanical Shuttle
Transmission With Hydraulic Shuttle
Gearbox
Speed Ranges
Four-Wheel Drive
â€œPark Lockâ€
Bevel Gear Pair And Differential
Rear Final Drives
Rear Pto
Front Axle With Four Driving Wheels
Front Axle With Two Driving Wheels
– 6001 – Engine – Transmission Coupling
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6002 – Engine-Transmission Assembly (Version With Mechanical Shuttle)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6002 – Engine-Transmission Assembly (Version With Hydraulic Shuttle Without Hml)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6002 – Engine-Transmission Assembly (Version With Hydraulic Shuttle With Hml)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6006 – Synchronized Gearbox And Ranges
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6012 – Rear Differential
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6018 – Side Final Drives
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6019 – Rear Pto (2-Speeds Version With Mechanical Engagement)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6019 – Rear Pto (Version With 2 Speeds With Electro-Hydraulic Engagement Without Hml)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6019 – Rear Pto (Version With 2 Speeds With Electro-Hydraulic Engagement With Hml)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6019 – Rear Pto (4-Speeds Version With Mechanical Engagement)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6019 – Rear Pto (Version With 4 Speeds With Electro-Hydraulic Engagement Without Hml)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6019 – Rear Pto (Version With 4 Speeds With Electro-Hydraulic Engagement With Hml)
Technical Specifications
Sections And Perspective Views
Safety
Procedures
– 6021 – Front Axle
Technical Specifications
Safety
Procedures
– 6025 – Front Hitch And Pto
Technical Specifications
Sections And Perspective Views
Safety
Front Hitch Maintenance
Front Pto Maintenance
– 7000 – Brakes – Operation
Description
On-Off Valve
Hydraulic Trailer Brake
Trailer Brake System, Italy â€œCunaâ€ Type
Trailer Brake System Type (Eu) 2015/68
– 7003 – Brakes – Adjustments And Inspections
Safety
Procedures
– 8000 – Hydraulic Circuit – Operation
Hydraulic Circuit
Iso And Functional Diagrams
Pumps
Solenoid Valves Packs
Suspended Axle
Front Hitch
Rear Hitch
Rear Auxiliary Hydraulic Control Valves
Midmount Control Valves
– 8001 – Hydraulic Components Inspections And Adjustments
Technical Specifications
Troubleshooting
Operating Pressure Tests
– 8007 – Rear Hitch
Safety
Procedures
– 10000 – Control Units Alarms Diagnostics
Can Bus System
Error Handling Via Can
Instrument Cluster Control Unit Ec1
Transmission Control Unit Ec4
Engine Control Unit Ec6
Hitch And/Or Auxiliary Control Valves Control Unit Ec9
Suspended Axle Control Unit Ec43
– Annexes
Engine Manual
