Name: Liebherr Excavator A 900 C - ZW Litronic Service Manual 10323502
SKU: 444767
Availability: InStock

Liebherr Excavator A 900 C ZW Litronic Service Manual 10323502 1

Liebherr Excavator A 900 C ZW Litronic Service Manual 10323502 2

Liebherr Excavator A 900 C ZW Litronic Service Manual 10323502 3

✓

Expert Support

✓

Full Speed

✓

100% Working

Liebherr Excavator A 900 C – ZW Litronic Service Manual 10323502

Size: 52.00 MB

Format: PDF

Language: English

Brand: Liebherr

Type of Machine: Excavator

Type of Manual: Service Manual, Electric and Hydraulic Diagrams

Model: Liebherr A 900 C – ZW Litronic Excavator

Engine: D 924 TI E A2 (Tier 2 – Stage II and before)

Order Number: 10323502

Publication Date: 2010

Number of Pages: 1391 Pages

100 USD

Tag: Liebherr Heavy Equipment Manual

Description

Description

Contents:
1 General
1.01 Standards and regulations
1.10 Safety instructions
1.11 Safety instructions
1.50 Lubricants and process chemicals
1.55 TE_ML05 lubricant list
1.56 TE_ML07 lubricant list
2 Tools
2.01 Special tools – general
2.02 Special tools for diesel engines
2.03 Special tools for ZW equipment
2.05 Special tools for hydraulic system
2.06 Special tools for electrical equipment
2.07 Special tools for gears
2.08 Special tools for axles (ZF)
2.09 Special tools for axles (Kessler)
2.12 Assembly tools for hydraulic cylinders
2.13 Mounting device for piston rod bearings
2.14 Slotted nut wrench for slewing gear mechanism
2.15 Mounting device for multi-disk brake
3 Technical data / Maintenance instructions
3.05 Type overview of A 900 C ZW Litronic
3.10 Technical data
3.20 Maintenance and inspection schedule
3.30 Lubricating charts
3.35 Adjustment of ZW rail guide system
3.40 Adjustment protocol
3.41 Adjustment protocol
3.46 Testing and adjusting tasks
3.50 Scheduled inspection
3.60 Warning and information signs on A 900 C ZW
4 Drive motor
4.11 Technical data of diesel engines
4.30 Adjustment of diesel engine speed
5 Coupling / Pump distributor gear
5.10 Coupling
5.20 Pump distributor gear
6 Hydraulic system
6.01 LSC system
6.30 Layout of hydraulic system
6.40 Hydraulic system – A 900 C-ZW 21034-
6.41 Hydraulic system – A 900 C-ZW 28567-
6.60 Function of ZW rail guide system
6.70 Switching modes – rail chassis
7 Hydraulic components
7.01 Hydraulic pumps – dismantling, installation and initial operation
7.03 Variable-displacement pump DPVP 90
7.05 Variable-displacement pump DPVP 90
7.10 Variable-displacement pump A10V0
7.20 FMF hydraulic fixed displacement motor
7.25 LMV regulating motor
7.30 Hydraulic cylinder
7.31 Extension and retraction times of hydraulic cylinders
7.32 Hydraulic double plunger cylinder
7.40 Control oil and regulating unit
7.42 Pilot control unit 1x (travelling foot pedal)
7.44 Pilot control valve 2 x
7.48 Pilot control valve 4 x
7.50 Control block LSC
7.68 Leak oil check at control valve blocks
7.70 Rotary connection 6 x
7.75 Rotary connection 7x
7.80 Axle control block of the rail guide
8 Electrical system
8.01 Overview of electrical symbols
8.10 Component arrangement
8.30 Electical system with installation kits and wiring harnesses
8.44 Operating symbols on the operator’s platform
8.79 Control panel
8.80 Error code list
8.82 Slip ring rotary connection
8.99 Self-holding mechanism for quick-change adapter locking
8.100 Directory of electric kits
9 Slewing gear mechanism
9.10 Slewing gear mechanism
9.20 Slewing gear brake
10 Slewing ring
10.10 Slewing ring
11 Transmission
11.10 2 HL 100 transmission
11.15 Speed sensor in 2 HL 100 transmission
11.30 HBGV block for 2 HL 100 transmission
12 Axles / Rail guide system
12.20 APL – B 765 steering axle with multi-disc brake
12.22 AP – B 765 rigid axle with multi-disc brake
12.24 Differential for AP / APL – B 765 axles
12.35 Tyres
12.40 ZW rail guide
12.70 Conversion of rail gear for narrow gauge
12.90 Measuring of the wheel flange of the rail chassis
12.91 Measuring of tyre track width
12.95 Wear limits
13 Steering
13.10 Hydraulic steering system
13.25 Steering valve
13.32 Steering cylinder
14 Oscillating axle support
14.10 Oscillating axle support with automatic control
14.20 Support cylinder
15 Brake system / Air pressure system
15.05 Operating pressures of the brake system
15.10 Hydraulic brake system
15.20 Compact brake block
15.50 Compressed air – wagon brake system
16 Special equipment / Accessory kits
16.01 Pipe fracture safety valve for hoist cylinder
16.02 Pipe fracture safety valve for stick cylinder
16.15 Hydraulic quick-change adapter
16.18 LIKUFIX hydraulic coupling system
16.20 Pressure and flow reduction
16.22 Hydraulic hammer
16.30 Attachment function
16.32 Function of closing cylinder
16.34 Function of regulating cylinder
16.40 Accessory kit AS1
16.50 Stroke and boom limitation
16.52 Adjustment of the stroke and boom limitation parameters
16.54 Inclination sensor
16.57 Emergency hydraulics
16.60 Refuelling pump
16.62 Individual control
16.65 Bypass filter
16.69 LIEBHERR bypass filter
17 Operator’s cab / Heating and air-conditioning
17.30 Auxiliary heater
17.50 Heating and air-conditioning system
18 Rail roader installations / Attachments
18.50 Repair instructions for lubrication hoses
18.51 Central lubrication system
18.53 Semi-automatic central lubrication system
18.56 Central lubrication pump
18.58 SX-E progressive distributor
18.59 MX-F progressive distributor
19 Tank arrangement
