Name: Liebherr Wheel Loader L507S L509S L514 Stereo Service Manual 10288197
SKU: 444951
Availability: InStock

Liebherr Wheel Loader L507S L509S L514 Stereo Service Manual 10288197 1

Liebherr Wheel Loader L507S L509S L514 Stereo Service Manual 10288197 2

Liebherr Wheel Loader L507S L509S L514 Stereo Service Manual 10288197 3

✓

Expert Support

✓

Full Speed

✓

100% Working

Liebherr Wheel Loader L507S L509S L514 Stereo Service Manual 10288197

Size: 19.94 MB

Format: PDF

Language: English

Brand: Liebherr

Type of Machine: Wheel Loader

Type of Manual: Service Manual, Electric and Hydraulic Diagrams

Model: Liebherr

L507S S/N 9099

L509S S/N 9099

L514 Stereo S/N 14000

Engine: D404T-01, D405T-00, D504T-03 (Tier 2 – Stage II)

Order Number: 10288197

Number of Pages: 600 Pages

100 USD

Tag: Liebherr Heavy Equipment Manual

Description

Description

Contents:
1 General information
1.1 Safety regulations
1.2 Special tools for maintenance and repair work
2 Product description
2.1 Technical data
3 Maintenance
3.1 Maintenance and inspection schedule
3.2 Testing and adjustment plan
3.3 Testing and adjustment checklists
3.4 Lubrication chart and filling quantities
3.5 Maintenance tasks
3.6 Testing and adjustment tasks
3.7 Lubricants and fuels
4 Diesel engine
4.1 Diesel engine
4.2 Fuel system
4.3 Pre-glow system
4.4 Air filter system
4.5 Coupling
5 Cooling system
5.0 Cooling system
5.1 Gear pump
5.2 Gear motor
5.3 Temperature sensor
6 Travel Hydraulics
6.0 Travel Hydraulics
6.1 Variable displacement pump
6.2 Variable diplacement motor
7 Working hydraulics
7.0 Working hydraulics
7.1 Working hydraulics pump
7.2 Control block
7.3 L507 and L509 pilot control (ser. no. 9099 – 12753)
7.4 L507 and L509 pilot control (from ser. no. 12754)
7.5 L514 pilot control device
7.6 Lift and tilt cylinders
7.7 Hydraulic tank
8 Steering system
8.0 Steering system
8.1 Servostat
8.2 Steering cylinder
8.3 Emergency steering
9 Brake system
9.1 Service brake
9.2 Parking brake
10 Electrical system
Electrical diagrams, ser.no. 9099 – 11357
Electrical diagrams, from ser.no. 11358
Electrical diagrams, with electrical drive interlock, from ser.no. 11358
10.0.1 Electrical system with circuit diagrams
10.1 Right-side control panel
10.2 UEC3 Universal Earth Moving Controller 3
10.3 Battery installation
11 Transfer gear
11.1 Transfer gear, speeder
11.2 Transfer gear, L514 stereo
12 Axles and cardan shaft
12.1 Front axle
12.2 Rear axle
12.3 Cardan shaft
13 Machine frame and ballast weight
13.1 Machine frame
13.2 Articulation bearing
13.3 Articulation lock
13.4 Ballast weight
14 Central lubrication system
14.1 Manual central lubrication
14.2 Automatic central lubrication
15 Covering, Cap access
15.1 Covering
15.2 Cab access
16 Cab, Heating and Air-conditioning
16.0.1 Cab, heating and air-conditioning
16.1 Instrument panel
16.2 Heating and ventilation
16.3 Air conditioning system
17 Lift arms and Quick-change device
17.1 Lift arms, L507s/L509s
17.2 Lift arms, L514 Stereo
17.3 Pin bearing
17.4 Quick-change device, L507s/L509s
17.5 Quick-change device, L514 Stereo
18 Equipment, Accessories
18.1 Connection sizes, L507s/L509s
18.2 Connection sizes, L514 Stereo
Equipment handbook
19 Repair work, Troubleshooting
19.0 Malfunctions
19.1 Connection / diagnosis – Old software version:V1.001 – V1.029
19.2 Diagnostics
20 Options
20.1 Assembly set, single – button control system
20.2 Ride control
