LS Tractor KAI Series K5047 Parts Catalog

Description

Contents:
01. ENGINE
Q065S01-01 OVERHAUL GASKET KIT (43,47,50)
Q110S01-01 CRANKCASE ASSY (43,47,50)
Q110S02-01 CRANKCASE (S4QL)
Q115S01-01 ROCKER COVER & CAMSHAFT (43,47,50)
Q116S01-01 CYLINDER HEAD (43,47,50)
Q120S01-01 MAIN MOVING PARTS (S4QL)
Q121S01-01 VALVE MECHANISM (43,47,50)
Q125S01-01 FUEL SYSTEM (43,47,50)
Q125S02-01 FUEL FILTER (S4QL,S4QT)
Q130S01-01 TIMING GEAR & CASE (43,47,50)
Q135S01-01 COOLING SYSTEM (43,47,50)
Q140S01-01 OIL SYSTEM (S4QL)
Q145S01-01 OIL PAN (43,47,50)
Q146S01-01 BALANCER (43,47,50)
Q160S01-01 INLET & OUTLET MANIFOLD (43,47,50)
Q180S01-01 ELECTRIC PARTS (43,47,50)
Q180S01-02 ELECTRIC PARTS (52,60)
02. ENGINE APPLICATION
G040S01-01 FUEL TANK
G040S01-02 FUEL TANK (DIA KIT)
G100S01-02 THROTTLE PEDAL (S4QL)
G100S01-03 THROTTLE LEVER
G150S01-03 MUFFLER (S4Q)
G170S01-03 RADIATOR (S4Q)
G190S01-02 AIR CLEANER (DRY,S4QL)
G210S01-02 ENGINE FRAME (S4Q)
03. TRANSMISSION
G250S01-02 CLUTCH (S4QL,S4S)
G250S02-04 CLUTCH HOUSING (S4QL)
G260S01-01 CLUTCH PEDAL
G280S01-01 TRANSMISSION CASE
G281S02-01 MAIN GEAR SHAFT (MEC)
G285S01-01 RANGE GEAR SHAFT
G310S01-01 REAR DIFFERENTIAL
04. PTO DRIVE
G280S02-01 PTO SHIELD
G283S01-02 PTO SHAFT (S4QL,S4S)
G287S01-03 PTO DRIVE SHAFT (540,LSTA)
G287S04-01 PTO SHAFT CAP
05. FOUR WHEEL DRIVE (4WD)
G288S01-04 4WD DRIVE SHAFT (4WD,LSTA)
G288S01-05 4WD SHAFT COVER (4WD,LSTA)
06. FRONT AXLE & STEERING LINKAGE
G400S01-03 FRONT AXLE ASSY (4WD,KC,LSTA)
G400S02-01 FRONT AXLE CASE (4WD,KC)
G400S02-02 FRONT AXLE CASE (4WD,KC)
G400S02-03 FRONT AXLE CASE (4WD,KC)
G400S02-04 FRONT AXLE CASE (4WD,KC)
G400S02-05 FRONT AXLE CASE (4WD,KC)
G400S02-06 FRONT AXLE CASE (4WD,KC)
G400S03-01 FRONT DIFFERENTIAL (4WD,KC)
G610S01-01 TIE-ROD (4WD,KC)
G630S01-06 STEERING CYLINDER (4WD,KC)
07. REAR AXLE & BRAKE
G480S01-01 REAR AXLE
G650S01-01 BRAKE
G670S01-01 BRAKE PEDALS
G670S02-01 PARKING BRAKE LEVER
08. SHIFT FORK & LINKAGE
G290S02-01 LEVER&FORK(MAIN GEAR) (MEC)
G291S01-01 LEVER&FORK(RANGE GEAR)
G291S02-01 LEVER&FORK(4WD) (4WD)
G291S03-01 LEVER&FORK(PTO)
G320S01-01 DIFF-LOCK (MEC)
09. HYDRAULIC & PNEUMATIC CONTROLS
G630S01-04 STEERING LINES (S4QL,4WD)
G822S03-02 FRONT OUTLET VALVE (F-O)
G823S01-02 HYD. F-PRESSURE LINES (S4Q,F-O)
G823S01-07 HYD. SUCTION LINES (S4Q)
G823S01-12 HYD. M-PRESSURE LINES (F-O,W-O RCV)
G823S01-18 HYD. DRAIN LINES
G827S01-01 REMOTE CONTROL VALVE (DIA KIT,SD5-1)
G827S01-02 REMOTE CONTROL VALVE (DIA KIT,SD5-2)
10. ELECTRIC & ELECTRONIC PARTS
G730S01-02 ELECTRICAL WIRING (S4QL,S4S)
G740S01-02 BATTERY (S4QL,S4S)
G750S01-02 METER PANEL (S4QL,S4S)
G750S02-03 ELECTRIC COMPONENTS (S4QL,S4S)
G760S01-02 LAMP (S4QL,S4S)
G760S01-03 HEAD LAMP (Twin-lamp)
11. HYDRAULIC LIFT UNIT
G820S01-01 HYDRAULIC HOUSING ASSY
G820S02-02 HYDRAULIC HOUSING
G825S01-01 HYD. CONTROL LEVER
12. 3-POINT LINKAGE & HITCH
G891S01-02 DRAWBAR & HITCH (CAT1,DRAWBAR)
G896S01-02 UPPER & LOWER LINK (CAT1,DRAWBAR,LSTA)
G896S02-01 LIFT ROD
G896S03-01 CHECK LINK
13. SHEET METALS & MOUNTS
G830S01-02 HOOD (S-BLUE,LSTA)
G830S01-03 GRILLE ASSY (TWIN-LOOK,S-BLUE)
G830S01-04 HOOD UNDER COVER (BLACK)
G830S02-03 HOOD SUPPORT (S4QL,S4S)
G830S03-01 REAR VIEW MIRROR (DIA KIT)
G840S01-01 MOUNT RUBBER
G840S01-02 STEP
14. DRIVER’S STATION
G630S02-01 STEERING COLUMN (F)
G630S02-02 STEERING WHEEL (LS-CAP)
G835S01-01 PEDAL FRAME
G850S01-02 SEAT (NO ARM)
G863S01-01 FRONT & SIDE WINDOW
G864S01-02 INTERIOR(FRONT) (S4QL,S4S)
G864S01-03 MAT (S4QL,S4S)
G864S01-04 FLOOR PLATE KIT (DIA KIT)
G869S01-01 MISCELLANY
G870S01-02 FENDER (S-BLUE,LSTA)
G880S01-02 SAFETY FRAME (FOLDABLE ROPS)
G880S01-03 SAFETY FRAME (CANOPY,DIA KIT)
15. TIRES, WHEELS & REAR BALLAST
G490S01-11 WHEEL BOLTS & NUTS (4WD)
16. ACCESSORY & ETC
G868S02-01 SLOW MOVING VEHICLES (LSTA)
G869S04-01 TM AIR BREATHER
G920S03-01 NUMBER PLATE (Number plate)
G920S05-01 BOLT CAP
17. DECALS
G980S01-02 DECAL (LSTA)
18. DIA KIT & SVC KIT
G040S01-02 FUEL TANK (DIA KIT)
G827S01-01 REMOTE CONTROL VALVE (DIA KIT,SD5-1)
G827S01-02 REMOTE CONTROL VALVE (DIA KIT,SD5-2)
G830S03-01 REAR VIEW MIRROR (DIA KIT)
G864S01-04 FLOOR PLATE KIT (DIA KIT)
G880S01-03 SAFETY FRAME (CANOPY,DIA KIT)
G990S01-01 DIA KIT LIST (LSTA)
