LS Tractor MT4 Series MT458 MT468 Parts Catalog

Description

Contents:
01. ENGINE
G010S01-03 ENGINE LONG BLOCK ASSY
Q110S01-02 CRANKCASE ASSY
Q110S02-03 CRANKCASE
Q115S01-01 ROCKER COVER & CAMSHAFT
Q115S02-02 AIR BREATHER
Q116S01-02 CYLINDER HEAD
Q120S01-04 MAIN MOVING PARTS
Q121S01-01 VALVE MECHANISM
Q125S01-03 FUEL SYSTEM
Q125S02-05 FUEL PRE FILTER
Q125S02-06 FUEL MAIN FILTER
Q125S04-01 INJECTION PUMP
Q130S01-04 TIMING GEAR & CASE
Q135S01-02 COOLING SYSTEM
Q140S01-03 OIL SYSTEM
Q145S01-01 OIL PAN
Q146S01-02 BALANCER
Q160S01-01 INLET & OUTLET MANIFOLD
Q166S01-02 EGR
Q166S02-04 EGR VV SVC KIT (ERAE to KAMTEC)
Q167S01-01 DOC&DPF
Q167S01-03 DPF SUPPORT (F)
Q180S01-02 ELECTRIC PARTS
Q180S01-07 ELECTRIC HARNESS
Q180S02-01 MAF SENSOR
Q185S01-03 TURBOCHARGER
02. ENGINE APPLICATION
G040S01-02 FUEL TANK (80L)
G100S01-02 THROTTLE PEDAL (MEC)
G100S01-03 THROTTLE LEVER
G100S01-04 THROTTLE PEDAL (PST)
G130S01-01 FUEL COOLER
G150S01-03 MUFFLER (C)
G150S01-04 MUFFLER (F)
G170S01-02 RADIATOR
G190S01-02 AIR CLEANER
G210S01-02 ENGINE FRAME
G210S02-01 ENGINE SAFETY COVER
G215S10-01 FRONT BALLAST DIA KIT (8-BALLAST,DIA KIT)
03. TRANSMISSION
G250S01-02 CLUTCH (MEC)
G250S02-03 CLUTCH HOUSING (MEC)
G250S02-04 CLUTCH HOUSING (PST)
G260S01-01 CLUTCH PEDAL (MEC)
G260S01-02 CLUTCH PEDAL (PST)
G280S01-03 TRANSMISSION CASE (MEC,H-RANGE)
G280S01-04 TRANSMISSION CASE (PST,H-RANGE)
G281S01-02 MAIN SHAFT (PST)
G281S01-03 MAIN SHAFT (MEC,CRP)
G281S02-01 MAIN GEAR SHAFT (MEC)
G281S02-02 MAIN GEAR SHAFT (PST)
G285S01-01 RANGE GEAR SHAFT (NO-Q-T,NO-GSP)
G310S01-01 REAR DIFFERENTIAL
04. PTO DRIVE
G280S02-01 PTO SHIELD (DO,LSTA)
G283S01-04 PTO CLUTCH & SHAFT (PST,NO-GSP)
G283S01-05 PTO CLUTCH & SHAFT (MEC,NO-GSP)
G287S01-02 PTO GEAR & DRIVE SHAFT (PTO1,NEUTRAL)
05. FOUR WHEEL DRIVE (4WD)
G288S01-02 4WD SHAFT & COVER (NO-Q-T)
06. FRONT AXLE & STEERING LINKAGE
G400S01-01 FRONT AXLE ASSY
G400S02-01 FRONT AXLE CASE
G400S02-06 FRONT AXLE CASE(LH) (STD,NO-Q-T)
G400S02-07 FRONT AXLE CASE(RH)
G400S03-01 FRONT DIFFERENTIAL
G400S04-02 FRONT DRIVE
G610S01-01 TIE-ROD
G630S01-02 STEERING CYLINDER
07. REAR AXLE & BRAKE
G480S01-06 REAR AXLE(LH) (58,63,68HP)
G480S01-07 REAR AXLE(RH) (58,63,68HP)
G650S01-01 BRAKE
G670S01-01 BRAKE PEDALS (WO-SWITCH)
G670S02-02 PARKING BRAKE LEVER (W-SWITCH)
08. SHIFT FORK & LINKAGE
G290S01-02 LEVER&FORK(CREEPER) (MEC,CRP)
G290S02-01 LEVER&FORK(MAIN GEAR)
G290S03-02 LEVER&FORK(F-R GEAR) (PST)
G290S03-03 LEVER&FORK(F-R GEAR) (MEC,MHL,w-switch)
G291S01-01 SHIFT LEVER & FORK(RANGE GEAR) (H-RANGE)
G291S01-02 COVER RANGE SHIFT (H-RANGE)
G291S02-01 SHIFT LEVER&FORK(4WD) (NO-Q-T)
G291S03-04 RAIL&FORK(PTO) (PTO1+N)
G291S03-05 PTO LEVER (PTO1+N)
G291S04-01 SHIFT LEVER & FORK(GSP) (NO-GSP)
G320S01-01 DIFF-LOCK
09. HYDRAULIC & PNEUMATIC CONTROLS
G630S01-03 STEERING LINES
G640S01-04 T-M OIL COOLER (58,63,68HP,PST)
G640S01-07 LUB. PIPE ASSY (C,PST)
G640S01-08 LUB. PIPE ASSY (MEC,WO Q-T)
G822S02-01 INDP PTO VALVE (WO Q-T)
G822S02-06 POWER SHUTTLE VALVE (C,PST,WO Q-T)
G822S03-01 LOADER VALVE (F,2SP)
G822S03-02 LOADER VALVE (C,2SP)
G822S03-06 LOADER VALVE DIA KIT (3SP,Complete valve)
G822S03-07 LOADER VALVE DIA KIT (3SP,Section only)
G823S01-04 HYD. SUCTION LINES
G823S01-05 HYD. PRESSURE LINES (C,L-V)
G823S01-06 HYD. PRESSURE LINES (F,L-V)
G827S01-07 REMOTE CONTROL LEVER (F,SD5-2)
G827S01-08 REMOTE CONTROL VALVE (F,SD5-2)
G827S01-16 REMOTE CONTROL VALVE (C,SD5-3)
G827S01-17 REMOTE CONTROL LEVER (C,SD5-3)
G827S02-06 REMOTE CONTROL VALVE (C,SD5-3,2-SPR,1-DTN)
G829S01-07 AUTO LEVELING HYD. LINE (C,MHL,NO-LEVEL,SD5-3,STD T-Link)
10. ELECTRIC & ELECTRONIC PARTS
G730S01-03 ELECTRICAL WIRING (C)
G730S01-10 ELECTRICAL WIRING (F)
G730S02-01 7 POLE CONNECTOR
G730S04-02 MAIN FUSE
G740S01-03 BATTERY
G750S01-03 ECU BRACKET
G750S01-06 RELAY & ELEC.Parts
G750S01-07 RH PILLAR SWITCH (C)
G750S01-08 DIAGNOSIS CONNECTOR
G750S01-13 CHASSIS FUSE BOX
G750S01-17 ESC RESISTER (C)
G750S01-18 METER PANEL
G750S01-20 RH CONSOLE SWITCH (F)
G750S02-13 POWER SHTTLE CTRL PARTS (PST,H-RANGE)
G750S05-01 AUTO PTO ON-OFF (MHL,W-SWITCH)
G750S06-01 E-PTO PLUG (NO-EPTO)
G760S01-01 REAR LAMP (C,BLUB TYPE)
G760S01-02 HEAD LAMP
G760S01-04 WORK LAMP & BEACON SOCKET (F,Optional)
G760S01-05 REAR LAMP (F)
G760S03-01 BEACON LAMP SOCKET (C)
11. HYDRAULIC LIFT UNIT
G820S01-01 HYD. HOUSING ASSY-SVC OFF (MHL)
G820S02-01 HYDRAULIC HOUSING (MHL)
G822S01-01 LIFT CTRL. VALVE & LINK (MHL)
G824S01-01 POSITION & DRAFT LINK (MHL)
G825S01-01 HYD. CONTROL LEVER (C,MHL)
G825S01-03 HYD. CONTROL LEVER (F,MHL)
G825S02-01 AUTO LIFT & EXTERNAL CTRL. (F,MHL)
G825S02-02 AUTO LIFT & EXTERNAL CTRL. (C,MHL)
G825S02-03 EXTERNAL CONTROL (C,MHL)
G825S02-04 EXTERNAL CONTROL (F,MHL,optional)
G826S01-01 HYDRAULIC CYLINDER (MHL)
G828S01-01 UPPER LINK BRACKET
12. 3-POINT LINKAGE & HITCH
G891S01-01 DRAWBAR & HITCH (TELESCOPIC DRAWBAR)
G896S01-01 UPPER & LOWER LINK (TELESCOPIC,CAT2)
G896S02-01 LIFT ROD (NO LEVEL)
G896S03-01 CHECK LINK (F,C-LINK)
G896S03-02 CHECK LINK (C,C-LINK)
13. SHEET METALS & MOUNTS
G830S01-02 GRILLE ASSY (S-BLUE)
G830S01-07 HOOD (S-BLUE,LSTA)
G830S01-08 HOOD UNDER COVER (DARK GRAY,LSTA)
G830S02-03 HOOD SUPPORT
G840S01-01 MOUNT RUBBER (F)
G840S01-02 WIND SHIELD (F)
G840S01-03 MOUNT RUBBER (C)
G840S01-06 STEP (F,S-BLUE)
G840S01-08 SUB STEP (C,FUEL80L)
G840S01-11 SUB STEP (F,FUEL80L,LH-ONLY,LSTA)
14. DRIVER’S STATION
G630S02-01 STEERING COLUMN (C,NO-AD)
G630S02-02 STEERING WHEEL (LS-CAP,NO-AD)
G630S02-03 STEERING COLUMN (F)
G825S01-02 HYD. CONTROL COVER (C,MHL)
G825S01-05 HYD. CONTROL COVER (F,MHL)
G835S01-03 PEDAL FRAME (F)
G835S01-04 PEDAL FRAME (C)
G850S01-01 SEAT (F,WOOCHANG,W08SSS)
G850S01-05 SEAT (C,GRMMER,LS-GRAY)
G861S01-02 FRAME (C,GRAMMER)
G862S01-03 DOOR(RH) (C)
G862S01-04 DOOR(LH) (C)
G862S02-01 DOOR HANDLE ASSY (C(XP))
G863S01-01 FRONT WINDOW (C)
G863S01-02 SIDE WINDOW (C)
G863S02-01 REAR WINDOW (C)
G864S01-01 INTERIOR(FRONT) (C,NO-AD)
G864S01-03 INTERIOR(LH) (C)
G864S01-04 INTERIOR(TOP) (C)
G864S01-05 INTERIOR(FRONT) (F,MEC)
G864S01-07 INTERIOR(RH) (C,NO-AD)
G864S01-10 MAT (F)
G865S01-04 AIR-CON BLOWER (C)
G865S01-05 AIR-CON LINE (C)
G865S01-06 AIR-CON COMPRESSOR (C)
G865S02-01 AIR-CON UNIT (C,HVAC-40351207)
G866S01-02 ELECTRICAL WIRING (C)
G866S02-02 WINDOW WIPER(REAR) (C)
G866S02-04 WINDOW WIPER(FRONT) (C)
G866S03-01 AUDIO SYSTEM (C)
G867S01-01 ROOF (C,S-BLUE)
G868S01-01 EXTERIOR (C,S-BLUE)
G869S01-01 BACK & ROOM MIRROR (C)
G869S01-03 MISCELLANY (C)
G869S01-05 MISCELLANY (C)
G869S01-07 MISCELLANY (F)
G869S01-08 GROMMET(FENDER) (C)
G870S01-02 FENDER (F,H-RANGE,S-BLUE)
G870S03-02 LH LEVER GUIDE (F,H-RANGE)
G880S01-01 SAFETY FRAME (F,Foldable ROPS)
15. TIRES, WHEELS & REAR BALLAST
G490S01-01 WHEEL BOLTS & NUTS
16. ACCESSORY & ETC
G868S02-01 SLOW MOVING VEHICLES
G920S02-01 TOOL BOX (F)
G920S02-02 TOOL BOX (C)
G920S05-01 BOLT CAP
G920S07-01 CUP HOLDER (F,optional)
17. DECALS
G980S01-11 MODEL DECAL
G980S01-12 SAFETY DECAL (C)
G980S01-13 SAFETY DECAL (F)
18. DIA KIT & SVC KIT
G215S10-01 FRONT BALLAST DIA KIT (8-BALLAST,DIA KIT)
G730S02-01 7 POLE CONNECTOR
G760S01-04 WORK LAMP & BEACON SOCKET (F,Optional)
G822S03-06 LOADER VALVE DIA KIT (3SP,Complete valve)
G822S03-07 LOADER VALVE DIA KIT (3SP,Section only)
G990S01-02 DIA KIT LIST (LSTA)
