Name: Macdon A30-D Unloading and Assembly Instructions 169001 Revision F
SKU: 528733
Availability: InStock

Macdon A30 D Unloading and Assembly Instructions 169001 Revision F (1)

Macdon A30 D Unloading and Assembly Instructions 169001 Revision F (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

Macdon A30-D Unloading and Assembly Instructions 169001 Revision F

Size: 10.75 MB

Format: PDF

Language: English

Brand: Macdon

Type of Machine: Pull-Type Mower Conditioner

Type of Manual: Unloading and Assembly Instructions

Model: Macdon A30-D Pull-Type Mower Conditioner

Publication Date: 2013

Parts Number: 169001 Revision F

Number Of Pages: 51 Pages

10 USD

Tags: A30-D, Macdon Manual, Macdon Unloading and Assembly Instructions

Description

Description

Contents:
Introduction
General Safety
Recommended Torques
A. General
B. Sae Bolts
C. Metric Bolts
D. Hydraulic Fittings
Conversion Table
Definitions
Step 1. Unload Articulating Power Tongue (Apt)
A. Truck Flatbed
B. Container
Step 2. Unload Header
A. Truck Flatbed
B. Container
Step 3. Remove Side Deflectors
Step 4. Install Gauge Rollers (Optional)
Step 5. Install Additional Skid Shoes (Optional)
Step 6. Lower Mower Conditioner
Step 7. Install Wheels
Step 8. Remove Shipping Channels And Blocking
Step 9. Unpack Articulating Power Tongue (Apt)
Step 10. Attach Articulating Power Tongue (Apt)
Step 11. Connect Hoses
Step 12. Attach Mower Conditioner To Tractor
A. Drawbar Type Hitch
B. Three-Point Hitch (Cat Ii, Iii, Iiin)
Step 13. Attach Hydraulics And Electrical
Step 14. Install Steering Cylinder
Step 15. Install Roll Opener Links
Step 16. Install Forming Shield Cover
Step 17. Install Side Deflectors
Step 18. Adjust Center-Link
A. Mechanical Link
B. Hydraulic Link
Step 19. Adjust Float Springs
Step 20. Reposition Knife Drive Box Breather
Step 21. Adjust Lean Bar
Step 22. Adjust Transport Lights
Step 23. Install Options
A. Gauge Rollers
B. Skid Shoes
C. Stub Guards
D. Hydraulic Header Angle
E. Tall Crop Divider Kit
Step 24. Lubricate Mower Conditioner
A. Header Drive: A30-D
B. Header Drive: A30-D
C. Hay Conditioner: A30-D
D. Carrier
E. Articulating Power Tongue (Apt)
Step 25. Perform Predelivery Checks
A. Drive Belts And Chains
B. Auger Stripper Bar Clearance
C. Reel Tine To Header Pan Clearance
D. Header Flotation
E. Conditioner Rolls
F. Skid Shoes/Gauge Rollers
G. Lights
H. Run-Up Mower Conditioner
I. Knife
J. Manuals
