Name: Macdon Precision Header 1300 1500 Series IV Parts Catalog
SKU: 528935
Availability: InStock

Macdon Precision Header 1300 1500 Series IV Parts Catalog (1)

Macdon Precision Header 1300 1500 Series IV Parts Catalog (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

Macdon Precision Header 1300 1500 Series IV Parts Catalog

Size: 3.02 MB

Format: PDF

Language: English

Brand: Macdon

Type of Machine: Precision Header

Type of Manual: Parts Manual

Model: Macdon Precision Header

1300 13J ; 1300 13J2 ; 1500 15J ; 1500 15J2

With Pickup Series IV Attachments:

Rake Up: 12S4 12M4 14M4 16M4

Swath Master: 12B4 12BG4 14B4 16B4

Release Date: 2005

Parts Number: 53-10057-05

Number Of Pages: 93 Pages

10 USD

Tags: 1300, 1500 Series IV, Macdon Parts Catalog, Macdon Precision Header Manual

Description

Description

Contents:
Introduction
Section A – Rake Up
Hold down Assembly
Draper And Gear Box Drive
Drive End Rotor
Idler End Rotor
Main Gear Box
Shield Assembly
Main Frame Mounting Assembly
Hydraulics
Section B – Swath master
Hold down Assembly
Drive Assembly
Roller, Tire, And Frame Assembly
Suspension Assembly
Shields
Hydraulics
16 Ft Roller Support
Section C – Rake Up/Swath master
Tire/Wheel Assembly
Hydraulic Cylinder
Section D – Lubricants, Service Tools, & Replacement Parts
Miscellaneous Lubricants, Service Tools, & Replacement Parts
Section E – John Deere Compatible Header
Header Table
Auger Drive & Support (Lh)
Auger Support (Rh)
Auger Assembly
Header Hydraulics
Electrical / Lighting
Drive Shaft
Shield Assembly
Decal Locations
Section F – Cnh Compatible Header
Header Table
Lh Assembly
Rh Assembly
Auger Assembly
Header Hydraulics
Electrical / Lighting
Drive Shaft
Decal Locations
Section G – Options
Automatic Height Control / Dial-A-Speed (Jd Models)
Active Header Height Control (Case Afx)
Active Header Height Control (Nh Cr/Cx)
Notes
