Name: New Holland Crawler Excavator E135B ROPS Tier III Operators Manual 84268535 2010
SKU: 609780
Availability: InStock

New Holland Crawler Excavator E135B ROPS Tier III Operators Manual 84268535 2010 (1)

New Holland Crawler Excavator E135B ROPS Tier III Operators Manual 84268535 2010 (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

New Holland Crawler Excavator E135B ROPS Tier III Operators Manual 84268535 2010

Size: 42.20 MB

Format: PDF

Language: English

Brand: New Holland

Type of Machine: Crawler Excavator

Type of Manual: Operators Manual

Model: New Holland E135B ROPS Tier III Crawler Excavator

Part Number: 84268535

Publication Date: 2010

Number of Pages: 262 Pages

10 USD

Tags: E135B, New Holland Crawler Excavator Manual, New Holland Operators Manual, tie

Description

Description

Contents:
1 – Introduction And Safety Precautions
General Information
Introduction
Intended Use
Identification Data E135b
Main Machine Components E135b
Vibration To The Operator
Noise Level E135b
Rops/Fops Cab Protection Structure
Safety Precautions
Safety Plates
2- Machine Familiarization
Instrument And Controls
Safety Lever
Starter Switch
Engine Speed Throttle
Hourmeter
Monitor
Location Of The Switches
Control Levers
Horn
Travel Control Pedals
Cigarette Lighter
12 V Socket
Internal Ceiling Light
Radio
Climate Conditioner System
Cab
Door
Front Windscreens And Windows
Emergency Exit
Operator’s Compartment
Adjusting The Seat
Heated Seat (Pneumatic Type)
Seat Belt
3 – Operating Instructions
Operating The Machine
Hood And Access Covers
External Visual Inspection
Inspections Prior To Starting The Engine
Engine Oil
Engine Cooling System
Engine Belts
Hydraulic System Oil
Fuel Tank
Windscreen Washer Tank
Fuel Filter
Adjusting The Operator’s Seat
Adjusting The Rear Mirrors
Starting The Engine
Starting The Engine In Normal Conditions
Starting The Engine In Cold Climates
Starting The Engine Using Booster Batteries
Stopping The Engine
Inspection After Starting The Engine
Warming Up The Machine
Operating The Machine
Operational Precautions
Machine Controls Plate
Travelling The Machine
Steering The Machine
Counter Rotating The Machine (Spin Turn)
Travel Stop
Shifting The Travel Speed (1st, 2nd Speed)
Attachment Controls
Swinging The Turret
Blade Controls
Practices To Improve Efficiency
Operating In Mud Or Water
Towing The Machine
Manual Signals
Parking The Machine
Objects Handling Operation
Emergency Boom Lowering Procedure
Machine Operation In Adverse Weather Conditions
Desmantling Of The Machine
4 – Maintenance
Generalities
Break-In
Machine Lubrication And Maintenance Chart
After 100 Hours Of Operation
After 250 Hours Of Operation
After 500 Hours Of Operation
After 1000 Hours Of Operation
After 2000 Hours Of Operation
After 5000 Hours Of Operation
Maintenance To Be Performed When Required
Filling Chart
5 – Troubleshooting
Engine
Hydraulic System
6 – Transportation
Road Transport
Loading/Unloading The Machine
Securing The Machine
Lifting Machine
7 – Options And Variants
Hydraulic Breaker
Crusher
Hydraulic Oil And Filter Element Service Interval
Equipment Rotation System
8 – Specifications
Technical Specifications
Digging Data (Monoblock Version)
Digging Data (Triple Articulation Version)
Digging Data (Monobloc Version With Undercarriage Equipped With Blade)
Digging Data (Triple Articulation Version With Undercarriage Equipped With Blade)
Transporting Dimensions (Monoblock Version)
Transporting Dimensions (Triple Articulation Version)
Transporting Dimensions (Monobloc Version With Undercarriage Equipped With Blade)
Transporting Dimensions (Triple Articulation Version With Undercarriage Equipped With Blade)
Bucket Applications As A Function Of The Arms
9 – Electrical System
Electrical System
Batteries
Fuses – Relay
