Name: New Holland Mini Excavator E35BSR E39BSR Operators Manual 84372391 2011
SKU: 611511
Availability: InStock

New Holland Mini Excavator E35BSR E39BSR Operators Manual 84372391 2011 (1)

New Holland Mini Excavator E35BSR E39BSR Operators Manual 84372391 2011 (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

New Holland Mini Excavator E35BSR E39BSR Operators Manual 84372391 2011

Size: 19.37 MB

Format: PDF

Language: English

Brand: New Holland

Type of Machine: Mini Excavator

Type of Manual: Operators Manual

Model: New Holland E35BSR E39BSR Mini Excavator

Engine: Yanmar 3TNV88 – PYB Engine

Part Number: 84372391

Publication Date: 2011

Number of Pages: 269 Pages

10 USD

Tags: E35BSR, E39BSR, New Holland Mini Excavator Manual, New Holland Operators Manual

Description

Description

Contents:
Foreword
Designated Use
General Information
Periodic Inspections
Note
Remarks Relevant To Orders
Noise Levels (2000/14/Ec)
Sound Power Level
Sound Pressure Level At The Operatorâ€™s Seat
Level Of Vibrations Transmitted To The Operator
Operator Protective Structure.
1safety Precautions
1.1 General Safety Information
1.2 Safety Precautions.
1.3 Inspection Before Travelling With The Machine.
1.4 Safety During Operation
1.5 Inspection And Maintenance Safety
1.6 Precautions During Battery Use.
1.7 Warning Labels And Safety Decals.
1.7.1 Notes For Warning Labels And Safety Decals.
1.8 Forbidden Use
1.9 Precautions At The End Of Daily Work
1.10 Transportation.
1.11 Towing The Machine
2machine Familiarization
2.1 Machine Familiarization
2.2 General Nomenclature
2.2.1 Front, Rear, Right And Left
2.2.2 Main Components
2.3 Operatorâ€™s Cab Nomenclature.
2.4 Instrument And Control Nomenclature
2.4.1 Instrument Panel
2.4.2 Switches.
2.4.3 Levers And Pedals
2.4.4 Seat Belt
2.4.5 Cab
2.4.6 Hoods.
2.4.7 Escape Routes
2.4.8 Seat Adjustment
2.4.9 Electrical Equipment
2.4.10storage Box And Others.
3machine Operation
3.1 Machine Operation
3.1.1 Daily Inspection
3.1.2 Checks Before Engine Start-Up
3.1.3 Machine Warm Up.
3.1.4 Starting The Engine.
3.1.5 Checks After Engine Start-Up
3.1.6 Stopping The Engine
3.1.7 Machine Operation
3.1.8 Machine Parking
3.1.9 Checks And Verification After Work
3.1.10precautions After Operation.
3.1.11measures After An Emergency Stop Of Engine
3.1.12emergency Measures For Sudden Failure Of Machine.
3.1.13caution While Using Rubber Crawlers
3.1.14machine Operation With Adverse Weather Conditions
3.1.15precautions When Storing The Machine For A Long Period.
4maintenance
4.1 General Safety Information
4.2 General Rules And Safety Precautions
4.3 Lubricant, Fuel And Coolant Specifications
4.4 Maintenance General Table
4.5 Tag Maintenance In Progress
4.6 Torque Specifications For Capscrews And Nuts
4.7 Torque Specifications For Joints And Hydraulic Hoses
4.8 Installing Fittings, Hydraulic Hoses And Tubes
4.9 Releasing Internal Pressure From The Hydraulic System
4.10 Bleeding Air From Fuel System
4.11 Replacement Of Rubber Crawler
4.11.1removing Of Rubber Crawler
4.11.2installing Rubber Crawlers
4.11.3check And Adjustment Of Tension On Rubber Crawler
4.12 Inspection And Maintenance Table
4.13 When Necessary
4.14 Pre-Start (Every 8 Hours) Inspection And Maintenance
4.15 50-Hour (Weekly) Inspection And Maintenance
4.16 250-Hour (3-Month) Inspection And Maintenance
4.17 500-Hour (6-Month) Inspection And Maintenance
4.18 1000-Hour (12-Month) Inspection And Maintenance
4.19 2000-Hour Service Inspection And Maintenance.
4.20 Inspection And Maintenance Table
4.21 Biodegradable Hydraulic Oil.
5transportation
5.1 When Preparing Transportation Plans
5.2 Lifting Procedures Of Complete Machine (E35b Sr)
5.3 Lifting Procedures Of Complete Machine (E39b Sr)
5.4 Load Specifications
6specifications
6.1 Maintenance Operations Summary Decal.
6.2 Dimensions
6.2.1 Machine Dimensions (E35b Sr)
6.2.2 Machine Dimensions (E39b Sr)
6.3 General Specifications
6.3.1 General Specifications (E35b Sr)
6.3.2 General Specifications (E39b Sr)
6.3.3 Crawler Type (E35b Sr)
6.3.4 Crawler Type (E39b Sr)
6.3.5 Standard Bucket (E35b Sr)
6.3.6 Standard Bucket (E39b Sr)
6.4 Digging Performance
6.4.1 Digging Performance (E35b Sr).
6.4.2 Digging Performance (E39b Sr).
6.5 Machine Weights
7optional Attachment
7.1 Hydraulic Breaker And Nibbler Attachment
7.1.1 Selection Of Hydraulic Breaker And Nibbler
7.1.2 Before Operating Hydraulic Breaker And Nibbler
7.1.3 Prevention Of Hydraulic Oil Contamination.
7.1.4 Attachment Operation.
7.1.5 Setting Selector Valve
7.1.6 Setting The Stop Valve.
7.2 Safety Instructions
7.3 Handling Of Hanging Loads
7.3.1 Liftable Loads Table Located In The Cab
7.4 Air Conditioner
7.5 Regular Inspection And Maintenance
8troubleshooting
8.1 General Troubleshooting
9electrical System
9.1 Generalities
9.2 Batteries
9.3 Fuse Box
Attachment 1 – â€œEcâ€ Declaration Of Conformity
