Name: New Holland Mini Excavator E45BSR SRE50BSR Operators Manual 84372582 2011
SKU: 611659
Availability: InStock

New Holland Mini Excavator E45BSR SRE50BSR Operators Manual 84372582 2011 (1)

New Holland Mini Excavator E45BSR SRE50BSR Operators Manual 84372582 2011 (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

New Holland Mini Excavator E45BSR SRE50BSR Operators Manual 84372582 2011

Size: 20.67 MB

Format: PDF

Language: English

Brand: New Holland

Type of Machine: Mini Excavator

Type of Manual: Operators Manual

Model: New Holland E45B SR ; SRE50B SR Mini Excavator

Serial Number: Yanmar 4TNV88â€“XYB Engine

Part Number: 84372582

Publication Date: 2011

Number of Pages: 269 Pages

10 USD

Tags: E45BSR, New Holland Mini Excavator Manual, New Holland Operators Manual, SRE50BSR

Description

Description

Contents:
Foreword
Designated Use
General Information
Periodic Inspections
Note
Remarks Relevant To Orders.
Noise Levels (2000/14/Ec).
Sound Power Level
Sound Pressure Level At The Operatorâ€™s Seat
Level Of Vibrations Transmitted To The Operator
Operator Protective Structure
1. Safety Instructions
1.1 General Safety Information
1.2 Safety Instructions.
1.3 Inspection Before Travelling With The Machine
1.4 Safety During Operation
1.5 Inspection And Maintenance Safety
1.6 Precautions During Battery Use
1.7 Warning Labels And Safety Decals
1.7.1 Notes For Warning Labels And Safety Decals
1.8 Forbidden Use
1.9 Precautions At The End Of Daily Work.
1.10 Transportation
1.11 Towing The Machine
2. Machine Familiarization
2.1 Machine Familiarization
2.2 General Nomenclature
2.2.1 Front, Rear, Right And Left.
2.2.2 Main Components.
2.3 Operatorâ€™s Cab Nomenclature
2.4 Instrument And Control Nomenclature.
2.4.1 Instrument Panel
2.4.2 Switches
2.4.3 Levers And Pedals.
2.4.4 Seat Belt
2.4.5 Cab
2.4.6 Hoods
2.4.7 Escape Routes
2.4.8 Seat Adjustment
2.4.9 Electrical Equipment
2.4.10storage Box And Others
3. Machine Operation
3.1 Machine Operation
3.1.1 Daily Inspection
3.1.2 Checks Before Engine Start-Up
3.1.3 Machine Warm Up
3.1.4 Starting The Engine
3.1.5 Checks After Engine Start-Up
3.1.6 Stopping The Engine
3.1.7 Machine Operation
3.1.8 Machine Parking
3.1.9 Checks And Verification After Work
3.1.10precautions After Operation
3.1.11measures After An Emergency Stop Of Engine
3.1.12emergency Measures For Sudden Failure Of Machine
3.1.13caution While Using Rubber Crawlers.
3.1.14machine Operation With Adverse Weather Conditions
3.1.15precautions When Storing The Machine For A Long Period
4. Maintenance
4.1 General Safety Information.
4.2 General Rules And Safety Precautions
4.3 Lubricant, Fuel And Coolant Specifications
4.4 Maintenance General Table
4.5 Tag Maintenance In Progress
4.6 Torque Specifications For Capscrews And Nuts
4.7 Torque Specifications For Joints And Hydraulic Hoses
4.8 Installing Fittings, Hydraulic Hoses And Tubes.
4.9 Releasing Internal Pressure From The Hydraulic System
4.10 Bleeding Air From Fuel System
4.11 Replacement Of Rubber Crawler
4.11.1removing Of Rubber Crawler
4.11.2installing Rubber Crawlers.
4.11.3check And Adjustment Of Tension On Rubber Crawler
4.12 Inspection And Maintenance Table.
4.13 When Necessary.
4.14 Pre-Start (Every 8 Hours) Inspection And Maintenance
4.15 50-Hour (Weekly) Inspection And Maintenance
4.16 250-Hour (3-Month) Inspection And Maintenance.
4.17 500-Hour (6-Month) Inspection And Maintenance.
4.18 1000-Hour (12-Month) Inspection And Maintenance.
4.19 2000-Hour Service Inspection And Maintenance
4.20 Inspection And Maintenance Table.
4.21 Biodegradable Hydraulic Oil
5. Transportation
5.1 When Preparing Transportation Plans.
5.2 Lifting Procedures Of Complete Machine (E45b 2sr)
5.3 Lifting Procedures Of Complete Machine (E50b Sr)
5.4 Load Specifications
6. Specifications
6.1 Maintenance Operations Summary Decal
6.2 Dimensions
6.2.1 Machine Dimensions (E45b Sr)
6.2.2 Machine Dimensions (E50b Sr)
6.3 General Specifications.
6.3.1 General Specifications (E45b Sr).
6.3.2 General Specifications (E50b Sr).
6.3.3 Crawler Type (E45b Sr)
6.3.4 Crawler Type (E50b Sr)
6.3.5 Standard Bucket (E45b Sr)
6.3.6 Standard Bucket (E50b Sr)
6.4 Digging Performance
6.4.1 Digging Performance (E45b Sr).
6.4.2 Digging Performance (E50b Sr).
6.5 Machine Weights
7. Optional Attachment
7.1 Hydraulic Breaker And Nibbler Attachment
7.1.1 Selection Of Hydraulic Breaker And Nibbler
7.1.2 Before Operating Hydraulic Breaker And Nibbler
7.1.3 Prevention Of Hydraulic Oil Contamination.
7.1.4 Attachment Operation.
7.1.5 Setting Selector Valve
7.1.6 Setting The Stop Valve.
7.2 Safety Instructions
7.3 Handling Of Hanging Loads
7.3.1 Liftable Loads Table Located In The Cab
7.4 Air Conditioner
7.5 Regular Inspection And Maintenance
8. Troubleshooting
8.1 General Troubleshooting
9. Electrical System
9.1 Generalities
9.2 Batteries
9.3 Fuse Box
Attachment 1 – â€œEcâ€ Declaration Of Conformity
