Name: Nichiyu Forklift RFTL-60 Parts Manual
SKU: 494334
Price: 10.00 USD
Availability: InStock

✓

Expert Support

✓

Full Speed

✓

100% Working

Nichiyu Forklift RFTL-60 Parts Manual

Size: 6.35 MB

Format: PDF

Language: English

Brand: Nichiyu

Type of Machine: Forklift

Type of Manual: Parts Manual

Model: RFTL-60

Number of Pages: 138 Pages

10 USD

Tag: Nichiyu Forklift Truck Manual

Description

Description

Contents:
Fig.1010 FRAME
Fig.1011 SIDE COVER
Fig.1012 TOP COVER
Fig.1013 BATTERY PARTS
Fig.1014 PAD & FLOOR PLATE
Fig.1050 BATTERY TABLE
Fig.1060 OVERHEAD GUARD
Fig.1080 GUIDE ROLLER(REAR)
Fig.1093A NAME PLATE
Fig.1093B NAME PLATE
Fig.1100 DRIVE 1
Fig.1101 DRIVE 2
Fig.1102 DRIVE 3
Fig.1110 DRIVE WHEEL
Fig.1200 CONTROL LINKAGE 1
Fig.1201 CONTROL LINKAGE 2
Fig.1205 CASTER WHEEL
Fig.1206 LUBRICATION SYSTEM
Fig.1230 LOAD WHEEL & GUIDE ROLLER
Fig.1300 STEERING
Fig.1320 BRAKE LINKAGE 1
Fig.1321A BRAKE LINKAGE 2
Fig.1321B BRAKE LINKAGE 2
Fig.1325 DISK BRAKE
Fig.1340 VALVE LINKAGE
Fig.1500 OIL TANK
Fig.1510 OIL PUMP
Fig.1515 OIL POWER UNIT
Fig.1520 CONTROL VALVE
Fig.1551 FRAME PIPING 1
Fig.1552A FRAME PIPING 2
Fig.1552B FRAME PIPING 2
Fig.2053A LIFT CYLINDER [P]
Fig.2059 MAST PIPING [P]
Fig.2061A OUTER MAST [P]
Fig.2063A INNER MAST [P]
Fig.2064 CHAIN WHEEL [P]
Fig.2075 LIFT LIMIT [P]
Fig.2076 LIFT HIGHT DETECTOR [P]
Fig.2152A LIFT CYLINDER(1st) [M]
Fig.2152B LIFT CYLINDER(1st) [M]
Fig.2159A MAST PIPING [M]
Fig.2159B MAST PIPING [M]
Fig.2161A OUTER MAST [M]
Fig.2162A MIDDLE MAST [M]
Fig.2163A INNER MAST [M]
Fig.2163B INNER MAST [M]
Fig.2164A CHAIN WHEEL(MAST) [M]
Fig.2164B CHAIN WHEEL(MAST) [M]
Fig.2165A CHAIN WHEEL(LIFT) [M]
Fig.2165B CHAIN WHEEL(LIFT) [M]
Fig.2175A LIFT LIMIT [M]
Fig.2175B LIFT LIMIT [M]
Fig.2175C LIFT LIMIT [M]
Fig.2176A LIFT HIGHT DETECTOR [M]
Fig.2176B LIFT HIGHT DETECTOR [M]
Fig.3620A LIFT BRACKET
Fig.3620B LIFT BRACKET
Fig.3620C LIFT BRACKET
Fig.3620D LIFT BRACKET
Fig.3800A L HEAD PIPING
Fig.3800B L HEAD PIPING
Fig.3830A SHIFT CARRIAGE 1
Fig.3831 SHIFT CARRIAGE 2
Fig.3832A SHIFT CARRIAGE 3
Fig.3832B SHIFT CARRIAGE 3
Fig.3833 SHIFT CARRIAGE 4
Fig.3850 FINGER BAR
Fig.3860 FORK
Fig.3870 GUIDE ROLLER(MAST)
Fig.4071A TRACTION MOTOR
Fig.4071B TRACTION MOTOR
Fig.40721 HYDRAULIC MOTOR
Fig.40722 HYDRAULIC MOTOR
Fig.4073 EPS MOTOR
Fig.4400 CONTROL UNIT 1
Fig.4401 CONTROL UNIT 2
Fig.4402 CONTROL UNIT 3
Fig.4403 CONTROL UNIT 4
Fig.4420 ACCELERATOR
Fig.4435 SEQUENCER BOX
Fig.4521 STACK PANEL
Fig.4600 CONTROL PANEL 1
Fig.4601 CONTROL PANEL 2
Fig.4800 BATTERY
Fig.4810A CHARGER(BC)
Fig.4810B CHARGER(BC)
Fig.4851 WIRE HARNESS(BODY)
Fig.4852 WIRE HARNESS(MAIN)
Fig.4853A WIRE HARNESS(MAST)
Fig.4853B WIRE HARNESS(MAST)
Fig.4854 WIRE HARNESS
Fig.4860 ELECTRIC PARTS 1
Fig.4861 ELECTRIC PARTS 2
Fig.4862 ELECTRIC PARTS 3
Fig.4863A ELECTRIC PARTS 4
Fig.4863B ELECTRIC PARTS 4
Fig.4863C ELECTRIC PARTS 4
Fig.4864 ELECTRIC PARTS 5
Fig.5000A ACCESSORY
Fig.5000B ACCESSORY
Fig.5000C ACCESSORY
Fig.5000D ACCESSORY
Fig.5000E ACCESSORY
Fig.5210 BATTERY CARRIAR
