Nissan PATHFINDER NAM 2022 – JUNE 2025 Electrical Wiring Diagrams

Size: 25.87 MB

Format: PDF

Language: English

Brand: Nissan

Type of Machine: Automotive

Type of Manual: Electrical Wiring Diagrams

Model: Nissan PATHFINDER NAM 2022

Update: JUNE 2025

Number of Pages: 364 Pages

50 USD

Tags: Nissan Service Manual, Nissan Wiring Diagram

Description

Description

Contents:
POWER
BATTERY POWER SUPPLY
ACCESSORY POWER SUPPLY
IGNITION POWER SUPPLY
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK AND RELAY BOX
FUSIBLE LINK BOX (BATTERY)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
GROUNDS
GROUND
WIRING DIAGRAMS
A GENERAL INFORMATION
B ENGINE
D TRANSMISSION & DRIVELINE
E SUSPENSION
F BRAKES
G STEERING
H RESTRAINTS
I VENTILATION, HEATER & AIR CONDITIONER
J BODY INTERIOR
K BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
L DRIVER CONTROLS
M ELECTRICAL & POWER CONTROL
N DRIVER INFORMATION & MULTIMEDIA
O CRUISE CONTROL & DRIVER ASSISTANCE
CONNECTOR VIEWS
CONNECTOR VIEWS
HARNESS LAYOUT
Outline
BODY HARNESS – FRONT VIEW
BODY HARNESS – LOWER VIEW
BODY HARNESS – REAR VIEW
BODY NO. 2 HARNESS – FRONT VIEW
BODY NO. 2 HARNESS – LOWER VIEW
BODY NO. 2 HARNESS – REAR VIEW
BODY NO. 3 HARNESS
FRONT SEAT LH HARNESS
FRONT SEAT RH HARNESS
REAR SONAR SUB-HARNESS
SECOND ROW HARNESS
FRONT DOOR LH HARNESS
FRONT DOOR RH HARNESS
REAR DOOR LH HARNESS
REAR DOOR RH HARNESS
BACK DOOR HARNESS
ENGINE ROOM HARNESS – BATTERY VIEW
ENGINE ROOM HARNESS – CABIN VIEW
ENGINE ROOM HARNESS – POWER STEERING SUB-HARNESS VIEW
ENGINE ROOM HARNESS – RH VIEW
FRONT END MODULE HARNESS
FRONT SONAR SUB-HARNESS
BATTERY CABLE
ENGINE CONTROL HARNESS – BATTERY VIEW
ENGINE CONTROL HARNESS – FRONT VIEW
ENGINE CONTROL HARNESS – REAR VIEW
ENGINE CONTROL HARNESS – SUB-HARNESS VIEW
HVAC SUB-HARNESS
MAIN HARNESS – CONSOLE VIEW
MAIN HARNESS – INSTRUMENT PANEL LH VIEW
MAIN HARNESS – INSTRUMENT PANEL RH VIEW
MAIN HARNESS – INSTRUMENT SUB-HARNESS VIEW
MAIN HARNESS – RADIO VIEW
ROOM LAMP HARNESS – FRONT VIEW
ROOM LAMP HARNESS – REAR VIEW
