Name: Waratah Harvester Head HTH622B SIII Component Technical Manual CTM10110
SKU: 612301
Availability: InStock

Waratah Harvester Head HTH622B SIII Component Technical Manual CTM10110 (1)

Waratah Harvester Head HTH622B SIII Component Technical Manual CTM10110 (2)

Waratah Harvester Head HTH622B SIII Component Technical Manual CTM10110 (3)

✓

Expert Support

✓

Full Speed

✓

100% Working

Waratah Harvester Head HTH622B SIII Component Technical Manual CTM10110

Size: 22.49 MB

Format: PDF

Language: English

Brand: Waratah

Type of Machine: Harvester Head

Type of Manual: Component Technical Manual

Model: Waratah HTH622B SIII Harvester Head

Part Number: CTM10110

Publication Date: 2022

Number of Pages: 272 Pages

20 USD

Tags: HTH622B SIII, Waratah Component Technical Manual, Waratah Harvester Head Manual

Description

Description

Contents:
General Information
Safety: General Precautions
Safety: Maintenance Precautions
Safety: Operation Precautions
Safety: Safety Signs and Labels
General maintenance
Miscellaneous machine
Tests and adjustments
Test points
Cartridge control
Settings
Hydraulic schematics
TimberRite™ H-16 control system: electrical schematic
Saw chain and saw bar
Repair and replacement
Rotator
Tilt unit
Front knife and delimb edges
Top saw
Upper delimb arm
Measuring arm components
Accumulator
Fixed feed
Feed arms
Find end
3/4″ Main saw
SuperCut 100 Main saw
Control valve
Diagnostics and troubleshooting
Electrical Components
Controller module diagnostics
