Grove Crane RT630B 69604 Parts Manual 2020

Description

Contents:
Boom Assembly – 32′-80′
Cylinder Assembly – 6.50”Telescope
Sheave Installation -Boom Nose
Sheave Wheel Assembly (Not Available As Assembly)
Shaft Installation – Boom Pivot And Upper Lift
Nose Installation – Boom Auxiliary
Ball Assembly – 150# Headache
Hook Block Assembly
Boom Extension Installation
Nose Assembly – Boom Extension
Sheave Assembly – Complete
Roller Assembly – Cable
Sheave Wheel Assembly
Alignment Device – Boom Extension
Carrier Installation -Boom Extension
Stop Installation – Boom Extension
Tie Down Installation -Hook Block
Indicator Installation -Boom Elevation
Indicator Assembly -Lh Boom Elevation
Hydraulic Lines Installation -Telescope
A2b Panel And Cable Reel Installation
Panel Assembly – Indicator
Panel Assembly
Cable Assembly – Electric
Cable Reel Assembly -(Anti-Two Block)
Reel Assembly – Cable
Receptacle Assembly -6 Pin
Plug Assembly – 6 Pin
Switch And Roller Guides Installation – Main Boom
Switch Assy,Anti-Two Block
Anti-Two Block Weight W/Chain
Guide Assembly – Roller
Anti-Two Block Installation – Sheave
Anti-Two Block Installation – Swing Away
Cord Assembly – Extension
Control Valve And Linkage Installation
Valve Bank Assembly -1 Section
Valve Assembly – Outlet
Valve Section – Inlet(A-35 Series)
Valve Assembly – Relief2250 Psi
Cartridge Assembly
Valve Bank Assembly -2 Section (A-20 Series)
Valve Assembly – Section Inlet (A-20 Series)
Valve Bank Assembly -4 Section (A-35 Series)
Cartridge Assembly -Relief Valve
Valve Assembly – Relief1000 Psi
Hydraulic Lines Installation -Hydraulic Test Panel
Hoist Installation -Main And Auxiliary
Hoist Assembly
Valve Assembly – Motor Control
Brake Assembly
Tubing Installation
Gear Reduction Assembly
Motor Assembly – Hydraulic Vane Type
Rotation Indicator Installation
Driver Assembly driver Assembly
Indicator Assembly
Transmitter Assembly
Panel Installation -Hydraulic Test
Idler Drum And Cable Follower Installation
Idler And Cable Follower Installation
Hydraulic Schematic – Main And Auxiliary Hoist
Turntable Drive Installation
Swing Box Assembly -Complete
Swing Box And Brake Assembly
Brake Assembly – Swing
Motor Assembly – Orbit
Counterweight Installation
Cylinder Installation -Lift
Cylinder Assembly – 8 1/4″Lift
Electric Air & Hydraulic Swivel Installation
Swivel Assembly -Hydraulic
Swivel Assembly -Air/Hydraulic
Slip Ring Assembly – 35conductor
Bearing Bolt Installation
Lock Installation -Turntable
Valve Installation -Reducing/Relief (Swing)
Valve Assembly -Pressure And Sequence
Guard Installation -Pinion
Hydraulic Lines Installation -Supply, Pressure And Return
Valve Assembly – Check
Manifold Installation -Hydraulic
Hydraulic Lines Installation -Swing
Hydraulic Lines Installation – Lift
Switch Installation -Remote Cranking Pump
Cab Installation
Cab Assembly
Latch Kit – Door
Valve Assembly – Transmission Shift Control
Pedal And Valve Assembly -Accelerator
Valve Assembly – Control
Valve Assembly – Dual Brake
Valve Assembly -Selector
Instruments And Lights Installation
Harness, Wiring
Rear View Mirror Installation
Extinguisher Installation – Fire
Valve Installation -Steer Control
Control Assembly -(W/O Return To Center Steering)
Weatherstrip Installation – Cab
Valve And Pedal Installation – Swing Brake
Valve Assembly -Power Brake
Heater And Defroster Installation
Heater Assembly – Propane
Seat Installation
Seat Assembly
Fan Installation – Cab Circulating
Fan Assembly – 12 Volt Cab(Complete Assembly)
Acoustical Installation
Wiper Installation -Skylight
Wiper And Washer Installation – Windshield
Brake Valve And Air Tank Installation – Parking
Grab Rail Installation
Decal Installation
Electrical System Installation – S/S
Panel Assembly – Fuse And Connector
Harness Assembly -Fuse And Connector Panel
Air Lines Installation –
Mounting Kit Installation – Propane Tank
Engine Installation -Dda 8.2l
Filter Assembly – Oil
Fuel/Water Separater Assembly
Pump Assembly – Steer
Cylinder Assembly – Throttle
Compressor Assembly – Air
Exhaust And Air Cleaner Installation
Cleaner Assembly – Air
Torque Converter Installation
Torque Converter Assembly
Pump Installation -3 Stage
Pump Assembly – 3 Stage Tandem
Electrical System Installation
Wiring Harness Assembly (Engine)
Link Assembly – Fusible
Battery Installation
Radiator Installation
Quick Start Installation
Heater Installation -Engine Block
Transmission Installation
Transmission Assembly
Transmission Assembly front Cover And Case Assembly
Transmission Assembly clutch And Gear Group
Transmission Assembly axle Disconnect Assembly
Transmission Assembly low Clutch Assembly
Transmission Assembly forward Clutch Assembly
Transmission Assembly reverse And Second Shift
Transmission Assembly control Valve Assembly
Cylinder Assembly – Air Lockout
Valve Assembly transmission
Driveline Installation
Driveline Assembly
Transmission And Converter Lines Installation
Transmission Shift Lines Installation
Frame Section
Axle Installation – Front
Axle Assembly – Front
Axle Assembly – Front Differential Carrier Assembly
Axle Assembly – Front Planet Carrier Assembly
Axle Assembly – Front Brake Head Assembly
Axle Assembly – Front Parking Brake Assembly
Cylinder Assembly – Steer
Cylinder Assembly – 2 1/2″Steer
Axle Installation – Rear
Axle Assembly
Axle Assembly differential Carrier Assembly
Axle Assembly planet Carrier Assembly
Axle Assembly brake Head Assembly
Axle Assembly no Spin Differential Assembly
Axle Assembly – No-Spin Rear
Cylinder Assembly – 5″Lockout
Brake Lines Installation -Hydraulic
Front Steer Installation
Valve Assembly – Relief(2500 Psi)
Parking Brake Installation
Brake Chamber Assembly
Valve Installation -Rear Axle Lockout
Valve Assembly – Lockout
Indicator Installation -Rear Steer
Switch Assembly – Limit
Hydraulic Lines Installation -Front Steer
Hydraulic Schematic – Rear Axle
Hydraulic Schematic – Rear Steer
Hydraulic Lines Installation -Rear Steer
Tire And Wheel Assembly
Outrigger Beam Installation
Cylinder Assembly – 4 1/2″Outrigger Jack
Cylinder Assembly -Extension Outrigger
Valve Installation -Outrigger
Valve Assembly
Valve Assembly – 4 Stack Outrigger Solenoid
Stowage Installation -Outrigger Float
Float Assembly – Outrigger
Hydraulic Lines Installation -Outrigger
Hood Installation – Engine
Reservoir Installation -Hydraulic
Fuel Tank Installation
Air Dryer Installation
Dryer Assembly – Air
Air Tank And Valve Installation
Actuator Assembly -Air Hydraulic
Lights Installation -Exterior
Battery Box Installation
Cover Installation – Pump
Tool Box And Decking Installation
Fender Installation
Alarm Installation -Back-Up
Pintle Hook Installation
Pintle Hook
