Name: Nichiyu Forklift FB10P-DC70 to FB30P-DC70 Workshop Manual 02W-2202
SKU: 494211
Availability: InStock

Nichiyu Forklift FB10P DC70 to FB30P DC70 Workshop Manual 02W 2202 1

Nichiyu Forklift FB10P DC70 to FB30P DC70 Workshop Manual 02W 2202 2

✓

Expert Support

✓

Full Speed

✓

100% Working

Nichiyu Forklift FB10P-DC70 to FB30P-DC70 Workshop Manual 02W-2202

Size: 6.30 MB

Format: PDF

Language: English

Brand: Nichiyu

Type of Machine: Forklift

Type of Manual: Workshop Manual

Model: FB10P-DC70 FB15P-DC70 FB18P-DC70 FB20P-DC70 FB25P-DC70 FB30P-DC70

Part Number: 02W-2202

Number of Pages: 185 Pages

20 USD

Tag: Nichiyu Forklift Truck Manual

Description

Description

Contents:
INTRODUCTION
Using this “WORKSHOP MANUAL”
CONTENTS
SAFETY WORK
1. Precautions for safe inspection and maintenance work
2. Safety labels
3. Model name and serial numbers
4. Cautions for maintenance
5. Tightening torque for bolts
1. GENERAL
1-1. Appearance
1-2. Specifications
2. FRONT AXLE (DRIVE)
2-1. Location and name
2-2. Disassembly and reassembly
2-3. Inspection and adjustment
2-4. Troubleshooting
3. REAR AXLE (STEERING)
3-1. Location and name
3-2. Disassembly and reassembly
3-3. Inspection and adjustment
3-4. Troubleshooting
4. TYRE
4-1. Location, name and tyre size
4-2. Inspection and adjustment
4-3. Troubleshooting
5. STEERING
5-1. Location and name
5-2. Disassembly and reassembly
5-3. Inspection and adjustment
5-4. Troubleshooting
6. BRAKE
6-1. Location and name
6-2. Disassembly and reassembly
6-3. Inspection and adjustment
6-4. Troubleshooting
7. HYDRAULIC SYSTEM
7-1. Oil piping circuit
7a. HYDRAULIC PUMP
7a-1. Location and name
7a-2. Disassembly and reassembly
7a-3. Inspection and adjustment
7a-4. Troubleshooting
7b. OIL TANK AND OIL PIPING
7b-1. Location and name
7b-2. Disassembly and reassembly
7b-3. Inspection and adjustment
7b-4. Troubleshooting
7c. CONTROL VALVE
7c-1. Location and name
7c-2. Disassembly and reassembly
7c-3. Inspection and adjustment
7c-4. Troubleshooting
7d. CYLINDER
7d-1. Location and name
7d-2. Disassembly and reassembly
7d-3. Inspection and adjustment
7d-4. Troubleshooting
8. MAST
8-1. Location and name
8-2. Disassembly and reassembly
8-3. Inspection and adjustment
8-4. Troubleshooting
9. MOTOR
9-1. Location and name
9-2. Disassembly and reassembly
9-3. Inspection and adjustment
9-4. Troubleshooting
10. ELECTRIC PARTS
10-1. Location and name
10a. CONTROL UNIT
10a-1. Location and name
10a-2. Disassembly and reassembly
10a-3. Check and replacement
10b. DISPLAY PANEL AND DIRECTIONAL SWITCH
10b-1. Disassembly and reassembly
10c. ACCELERATOR
10c-1. Disassembly and reassembly
10d. CHARGER (BUILT-IN TYPE)
10d-1. Disassembly and reassembly
10d-2. Inspection and replacement
10d-3. Inspection After Assembly
10d-4. Charging procedure
10d-5. Voltage tap
10e. BATTERY
10e-1. Disassembly and reassembly
10e-2. Inspection and adjustment
10f. MPU BOARD
10f-1. Location and name
11. LASER POINTER (OPTIONAL)
11-1. Adjustment
12. SERVICE DATA
12-1. Annual Inspection Service Data
12-2. Standard work hours
