Name: Nichiyu Forklift FBRO15-63 Parts Manual
SKU: 494287
Availability: InStock

Nichiyu Forklift FBRO15 63 Parts Manual 1

Nichiyu Forklift FBRO15 63 Parts Manual 2

✓

Expert Support

✓

Full Speed

✓

100% Working

Nichiyu Forklift FBRO15-63 Parts Manual

Size: 3.89 MB

Format: PDF

Language: English

Brand: Nichiyu

Type of Machine: Forklift

Type of Manual: Parts Manual

Model: FBRO15-63

Number of Pages: 80 Pages

10 USD

Tag: Nichiyu Forklift Truck Manual

Description

Description

Contents:
Fig.1010A FRAME
Fig.1011A SIDE COVER
Fig.1012A TOP COVER
Fig.1012B TOP COVER
Fig.1013A BATTERY PARTS
Fig.1014A PAD & FLOOR PLATE
Fig.1017A COVER & CONTROLLER BRACKET
Fig.1093A NAME PLATE [J apanese]
Fig.1093B NAME PLATE [English]
Fig.1100 DRIVE 1
Fig.1101 DRIVE 2
Fig.1102 DRIVE 3
Fig.1103 DRIVE 4
Fig.1220 LOAD WHEEL
Fig.1301 STEERING 1
Fig.1302 STEERING 2
Fig.1303 STEERING 3
Fig.1304 STEERING 4
Fig.3620A LIFT BRACKET [Pm]
Fig.3620B LIFT BRACKET [Pm]
Fig.3620C LIFT BRACKET [Mm]
Fig.3620D LIFT BRACKET [Mm]
Fig.3621A TILT BAR [Std]
Fig.3621B TILT BAR [WB(Opt)]
Fig.3621E TILT BAR
Fig.3630A FORK [Std]
Fig.3630B FORK [WB(Opt)]
Fig.3640A BACKREST [Std]
Fig.3640B BACKREST [WB(Opt)]
Fig.4400A CONTROL UNIT 1
Fig.4400B CONTROL UNIT 1
Fig.4401A CONTROL UNIT 2
Fig.4401B CONTROL UNIT 2
Fig.4402A CONTROL UNIT 3
Fig.4402B CONTROL UNIT 3
Fig.4405A WIRE HARNESS(CONTROL)
Fig.4405B WIRE HARNESS(CONTROL)
Fig.4600A CONTROL PANEL
Fig.4600B CONTROL PANEL
Fig.4851 WIRE HARNESS(BODY)
Fig.4866 STEERING PARTS 1
Fig.4867 STEERING PARTS 2
Fig.6000A ICHIGIMEKUN 1
Fig.6000B ICHIGIMEKUN 1(Old- type)
Fig.6000C ICHIGIMEKUN 1(New- type)
Fig.6000D ICHIGIMEKUN 1
Fig.6010A ICHIGIMEKUN 2(Old- type)
Fig.6010B ICHIGIMEKUN 2(New- type)
Fig.6011A ICHIGIMEKUN 3(Old- type)
Fig.6011B ICHIGIMEKUN 3(New- type)
Fig.6011C ICHIGIMEKUN 3(Old- type)
Fig.6011D ICHIGIMEKUN 3(New- type)
