Name: Takeuchi Track Loader TL12R2 Parts Manual P-TL12R_ER-XJ
SKU: 597535
Availability: InStock

✓

Expert Support

✓

Full Speed

✓

100% Working

Takeuchi Track Loader TL12R2 Parts Manual P-TL12R_ER-XJ

Size: 156.27 MB

Format: PDF

Language: English

Brand: Takeuchi

Type of Machine: Track Loader

Type of Manual: Parts Manual

Model: Takeuchi TL12R2 Track Loader

Serial Number: 412100002~

Part Number: BR1Z001-3-2 [P-TL12R_ER-XJ]

Number of Pages: 775 Pages

15 USD

Tags: Takeuchi Parts Manual, Takeuchi Track Loader Manual, TL12R2

Description

Description

Contents:
UNDERCARRIAGE
TRACK ROLLER (for U.S) (412100002-412100624)
TRACK ROLLER (for U.S) (412100625-)
FRONT IDLER (for U.S) (412100002-)
TRACK ADJUSTER
TRAVEL DEVICE
CRAWLER BELT
MAIN FRAME & CONTROL LEVER
FRAME
VALVE BRACKET
PIPING; OPERATION LEVER (412100002-412100701) 1
PIPING; OPERATION LEVER (412100002-412100701) 2
PIPING; OPERATION LEVER (A-H pattern) (412100002-412100701) 1
PIPING; OPERATION LEVER (A-H pattern) (412100002-412100701) 2
PIPING; OPERATION LEVER (A-H pattern) (412100002-412100701) 3
PIPING; OPERATION LEVER (412100702-) 1
PIPING; OPERATION LEVER (412100702-) 2
PIPING; OPERATION LEVER (A-H pattern) (412100702-) 1
PIPING; OPERATION LEVER (A-H pattern) (412100702-) 2
PIPING; OPERATION LEVER (A-H pattern) (412100702-) 3
ENGINE & ELECTRICAL SYSTEM
ENGINE & ACCESSORIES (1/3) 1
ENGINE & ACCESSORIES (1/3) 2
ENGINE & ACCESSORIES (1/3) 3
ENGINE & ACCESSORIES (2/3)
ENGINE & ACCESSORIES (3/3)
FOOT ACCELERATOR
ELECTRICAL (1/2) 1
ELECTRICAL (1/2) 2
ELECTRICAL (1/2) 3
ELECTRICAL (1/2) 4
ELECTRICAL (1/2) 5
ELECTRICAL (2/2)
ELECTRICAL (canopy)
ELECTRICAL (cab)
GPS DEVICE (412100002-412100809)
GPS DEVICE (412100810-)
BATTERY
WINDOW WASHER (for U.S)
RADIO
REAR VIEW CAMERA (412100002-412101079)
REAR VIEW CAMERA (412101080-)
HYDRAULIC PIPING & TANK
VALVE & ACCESSORIES (1/2) (412100002-412100701) 1
VALVE & ACCESSORIES (1/2) (412100002-412100701) 2
VALVE & ACCESSORIES (1/2) (412100002-412100701) 3
VALVE & ACCESSORIES (1/2) (with ride control) (412100002-412100701) 1
VALVE & ACCESSORIES (1/2) (with ride control) (412100002-412100701) 2
VALVE & ACCESSORIES (1/2) (with ride control) (412100002-412100701) 3
VALVE & ACCESSORIES (1/2) (with ride control) (412100002-412100701) 4
VALVE & ACCESSORIES (2/2) (412100002-412100701)
VALVE & ACCESSORIES (1/2) (high flow) (412100002-412100701) 1
VALVE & ACCESSORIES (1/2) (high flow) (412100002-412100701) 2
VALVE & ACCESSORIES (1/2) (high flow) (412100002-412100701) 3
VALVE & ACCESSORIES (2/2) (high flow) (412100002-412100701)
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line) (412100002-412100701) 1
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line) (412100002-412100701) 2
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line) (412100002-412100701) 3
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 1
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 2
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 3
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 4
VALVE & ACCESSORIES (2/2) (high flow) (with 2nd aux. line) (412100002-412100701)
VALVE & ACCESSORIES (1/2) (412100702-) 1
VALVE & ACCESSORIES (1/2) (412100702-) 2
VALVE & ACCESSORIES (1/2) (412100702-) 3
VALVE & ACCESSORIES (1/2) (with ride control) (412100702-) 1
VALVE & ACCESSORIES (1/2) (with ride control) (412100702-) 2
VALVE & ACCESSORIES (1/2) (with ride control) (412100702-) 3
VALVE & ACCESSORIES (1/2) (with ride control) (412100702-) 4
VALVE & ACCESSORIES (2/2) (412100702-)
VALVE & ACCESSORIES (1/2) (high flow) (412100702-) 1
VALVE & ACCESSORIES (1/2) (high flow) (412100702-) 2
VALVE & ACCESSORIES (1/2) (high flow) (412100702-) 3
VALVE & ACCESSORIES (2/2) (high flow) (412100702-)
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line) (412100702-) 1
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line) (412100702-) 2
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line) (412100702-) 3
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100702-) 1
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100702-) 2
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100702-) 3
VALVE & ACCESSORIES (1/2) (high flow) (with 2nd aux. line & ride control) (412100702-) 4
VALVE & ACCESSORIES (2/2) (high flow) (with 2nd aux. line) (412100702-)
PIPING (412100002-412100701) 1
PIPING (412100002-412100701) 2
PIPING (412100002-412100701) 3
PIPING (with ride control) (412100002-412100701) 1
PIPING (with ride control) (412100002-412100701) 2
PIPING (with ride control) (412100002-412100701) 3
PIPING (high flow) (412100002-412100701) 1
PIPING (high flow) (412100002-412100701) 2
PIPING (high flow) (412100002-412100701) 3
PIPING (high flow) (with 2nd aux. line) (412100002-412100701) 1
PIPING (high flow) (with 2nd aux. line) (412100002-412100701) 2
PIPING (high flow) (with 2nd aux. line) (412100002-412100701) 3
PIPING (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 1
PIPING (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 2
PIPING (high flow) (with 2nd aux. line & ride control) (412100002-412100701) 3
PIPING (412100702-) 1
PIPING (412100702-) 2
PIPING (412100702-) 3
PIPING (with ride control) (412100702-) 1
PIPING (with ride control) (412100702-) 2
PIPING (with ride control) (412100702-) 3
PIPING (high flow) (412100702-) 1
PIPING (high flow) (412100702-) 2
PIPING (high flow) (412100702-) 3
PIPING (high flow) (with 2nd aux. line) (412100702-) 1
PIPING (high flow) (with 2nd aux. line) (412100702-) 2
PIPING (high flow) (with 2nd aux. line) (412100702-) 3
PIPING (high flow) (with 2nd aux. line & ride control) (412100702-) 1
PIPING (high flow) (with 2nd aux. line & ride control) (412100702-) 2
PIPING (high flow) (with 2nd aux. line & ride control) (412100702-) 3
PUMP DRIVE
PUMP DRIVE (high flow)
HYDRAULIC TANK
FUEL TANK & FUEL PIPING (1/2) 1
FUEL TANK & FUEL PIPING (1/2) 2
FUEL TANK & FUEL PIPING (2/2)
COVER & CAB
COVER (1/4) (canopy)
COVER (1/4) (cab)
COVER (2/4) (center cover)
COVER (3/4) (rear door)
COVER (4/4) (engine hood)
FLOOR FRAME
SEAT (1/2)
SEAT (2/2) (412100002-412100008)
SEAT (2/2) (412100009-)
SEAT BELT
SAFETY BAR
CANOPY MOUNT (for U.S.)
CANOPY (for U.S.) 1
CANOPY (for U.S) 2
CANOPY (for U.S) 3
CANOPY INTERIOR (for U.S)
CAB MOUNT
CAB (1/3) 1
CAB (1/3) 2
CAB (1/3) 3
CAB (1/3) 4
CAB (2/3) (front door) 1
CAB (2/3) (front door) 2
CAB (3/3) (side sash)
CAB INTERIOR
SWITCH (canopy)
SWITCH (canopy) (with ride control)
SWITCH (cab)
SWITCH (cab) (with ride control)
SWITCH (cab) (high flow) (with ride control)
SWITCH (cab) (high flow) (without ride control)
ROOF GUARD
REAR VIEW MIRROR
AIR CONDITIONER (1/4) (compressor)
AIR CONDITIONER (2/4) (condenser)
AIR CONDITIONER (3/4) (air conditioner unit)
AIR CONDITIONER (4/4)
ATTACHMENT
ARM 1
ARM 2
QUICK HITCH
QUICK HITCH (hydraulic type) 1
QUICK HITCH (hydraulic type) 2
QUICK HITCH (hydraulic type) (high flow) 1
QUICK HITCH (hydraulic type) (high flow) 2
PIPING; ARM (1/2) 1
PIPING; ARM (1/2) 2
PIPING; ARM (1/2) 3
PIPING; ARM (1/2) (with ride control) 1
PIPING; ARM (1/2) (with ride control) 2
PIPING; ARM (1/2) (with ride control) 3
PIPING; ARM (2/2)
PIPING; ARM (1/2) (hydraulic quick hitch type) 1
PIPING; ARM (1/2) (hydraulic quick hitch type) 2
PIPING; ARM (1/2) (hydraulic quick hitch type) 3
PIPING; ARM (1/2) (hydraulic quick hitch type) (with ride control) 1
PIPING; ARM (1/2) (hydraulic quick hitch type) (with ride control) 2
PIPING; ARM (1/2) (hydraulic quick hitch type) (with ride control) 3
PIPING; ARM (2/2) (hydraulic quick hitch type)
PIPING; ARM (1/2) (high flow) (412100002-412100701) 1
PIPING; ARM (1/2) (high flow) (412100002-412100701) 2
PIPING; ARM (1/2) (high flow) (412100002-412100701) 3
PIPING; ARM (1/2) (high flow) (with ride control) (412100002-412100701) 1
PIPING; ARM (1/2) (high flow) (with ride control) (412100002-412100701) 2
PIPING; ARM (1/2) (high flow) (with ride control) (412100002-412100701) 3
PIPING; ARM (1/2) (high flow) (with coupler & 2nd aux. line) (412100702-) 1
PIPING; ARM (1/2) (high flow) (with coupler & 2nd aux. line) (412100702-) 2
PIPING; ARM (1/2) (high flow) (with coupler & 2nd aux. line) (412100702-) 3
PIPING; ARM (1/2) (high flow) (with coupler & ride control) (412100702-) 1
PIPING; ARM (1/2) (high flow) (with coupler & ride control) (412100702-) 2
PIPING; ARM (1/2) (high flow) (with coupler & ride control) (412100702-) 3
PIPING; ARM (2/2) (high flow)
PIPING; ARM (1/2) (high flow) (with coupler) 1
PIPING; ARM (1/2) (high flow) (with coupler) 2
PIPING; ARM (1/2) (high flow) (with coupler) 3
PIPING; ARM (2/2) (high flow) (with coupler)
DECAL & TOOL
DECAL (canopy) (English) 1
DECAL (canopy) (English) 2
DECAL (canopy) (Spanish) 1
DECAL (canopy) (Spanish) 2
DECAL (cab) (English) 1
DECAL (cab) (English) 2
DECAL (cab) (Spanish) 1
DECAL (cab) (Spanish) 2
DECAL (foot accelerator)
DECAL (lever operation)
DECAL (pattern change)
DECAL (hydraulic quick hitch type)
DECAL (high flow)
PAINTED COLOR
SERVICE TOOL
HYDRAULIC DEVICE
CONTROL VALVE (412100002-412100701) 1
CONTROL VALVE (412100002-412100701) 2
CONTROL VALVE (high flow) (with 2nd aux. line) (412100002-412100701) 1
CONTROL VALVE (high flow) (with 2nd aux. line) (412100002-412100701) 2
BLOCK ASSY (high flow)
PILOT VALVE (R.H.)
PILOT VALVE (L.H.)
HANDLE (with slide switch)
HANDLE (with 5 switch)
SUB VALVE
SOLENOID VALVE; 1 BLOCK
SOLENOID VALVE; 1 BLOCK
SOLENOID VALVE; 1 BLOCK
ELECTRICAL PROPORTION VALVE; 1 BLOCK
ELECTRICAL PROPORTION VALVE; 2 BLOCKS
SELECTOR VALVE (ISO-H pattern)
SHUTTLE VALVE
LIFT ARM CYLINDER
BUCKET CYLINDER (L.H.)
BUCKET CYLINDER (R.H.)
QUICK HITCH CYLINDER
TRAVEL MOTOR 1
TRAVEL MOTOR 2
TRAVEL MOTOR 3
HYDRAULIC PUMP 1
HYDRAULIC PUMP 2
HYDRAULIC PUMP 3
HYDRAULIC PUMP 4
HYDRAULIC PUMP 5
GEAR PUMP
GEAR PUMP (high flow)
ENGINE – KUBOTA V3800-TIEF4B-TLTU-1 SN 412100006-
Fig.1 CRANK CASE
Fig.2 OIL PAN
Fig.3 DIPSTICK AND GUIDE
Fig.4 CYLINDER HEAD
Fig.5 INLET VALVE AND EXHAUST VALVE
Fig.6 ROCKER ARM SHAFT
Fig.7 HEAD COVER
Fig.8 GEAR CASE
Fig.9 PISTON AND CRANKSHAFT
Fig.10 CAMSHAFT AND IDLE GEAR SHAFT
Fig.11 BEARING CASE COVER
Fig.12 FLYWHEEL
Fig.13 SUPPLY PUMP
Fig.14 FUEL FILTER
Fig.15 FUEL FILTER
Fig.16 FUEL TUBE
Fig.17 SEPARATOR
Fig.18 INJECTION PIPE
Fig.19 COMMON RAIL
Fig.20 ALTERNATOR AND PULLEY
Fig.21 ALTERNATOR [COMPONENT PARTS]
Fig.22 STARTER
Fig.23 STARTER [COMPONENT PARTS]
Fig.24 SWITCH/SENSOR
Fig.25 INJECTOR HARNESS
Fig.26 ELECTRICAL WIRING
Fig.27 WIRE HARNESS BRACKET
Fig.28 WATER FLANGE AND THERMOSTAT
Fig.29 WATER PUMP
Fig.30 RESERVE TANK
Fig.31 FAN AND PULLEY
Fig.32 INLET MANIFOLD
Fig.33 AIR CLEANER FLANGE AND THROTTLE VALVE
Fig.34 EXHAUST MANIFOLD
Fig.35 EGR VALVE
Fig.36 EGR COOLER
Fig.37 TURBO CHARGER
Fig.38 DIESEL PARTICULATE FILTER MUFFLER
Fig.39 DIESEL PARTICULATE FILTER MUFFLER [COMPONENT PARTS]
DPF CLEANING PROGRAM REV 021418
DPF CLEANING ORDER FORM – REV 021418
Fig.40 MUFFLER SENSOR
Fig.41 PRESSURE PIPE
Fig.42 SELECTIVE CATALYTIC REDUCTION MUFFLER
Fig.43 SELECTIVE CATALYTIC REDUCTION MUFFLER BASE
Fig.44 BREATHER PIPE/SEPARATOR PIPE
Fig.45 OIL SEPARATOR
Fig.46 OIL PIPE(TURBO CHARGER)
Fig.47 OIL COOLER
Fig.48 OIL FILTER
Fig.49 ECU
Fig.50 ACCESSORIES AND SERVICE PARTS
Fig.51 ACCESSORIES AND SERVICE PARTS
Fig.52 ACCESSORIES AND SERVICE PARTS
Fig.54 PISTON KIT [OPTION]
Fig.55 DIAGMASTER [OPTION]
KITS, ATTACHMENTS & QUICK REFERENCE
BLOCK HEATERS
BUCKETS-BLADES-ATTACHMENTS
TAKEUCHI FLEET MANAGEMENT COMPONENT GUIDE
TEETH
TFM-FUSE DETAIL 11-18-16
RECOMMENDED STOCK LIST (TL12R-2)
Appendix A:pages Index
Appendix B:parts Index
