Name: Jacobsen Mower Greens King 500 Series Technical Manual 4124342 2002
SKU: 646487
Availability: InStock

Jacobsen Mower Greens King 500 Series Technical Manual 4124342 2002 (1)

Jacobsen Mower Greens King 500 Series Technical Manual 4124342 2002 (2)

Jacobsen Mower Greens King 500 Series Technical Manual 4124342 2002 (3)

✓

Expert Support

✓

Full Speed

✓

100% Working

Jacobsen Mower Greens King 500 Series Technical Manual 4124342 2002

Size: 2.38 MB

Format: PDF

Language: English

Brand: Jacobsen

Type of Machine: Mower

Type of Manual: Technical Manual, Parts List

Model: Jacobsen Greens King 500 Series Mower

62281 – 18” 11 Blade Reel, D Handle

62282 – 22” 11 Blade Reel, D Handle

62283 – 22” 11 Blade Reel, T Handle

62284 – 26” 11 Blade Reel, D Handle

62285 – 26” 7 Blade Reel, D Handle

Engine: Honda GX-120 K1Q JG2 4-Cycle

Part Number: 4124342

Publication Date: 2002

Number of Pages: 56 Pages

10 USD

Tags: Greens King 500 Series, Jacobsen Mower Manual, Jacobsen Technical Manual

Description

Description

Contents:
Safety
1.1 Operating Safety
1.2 Important Safety Notes
Specifications
2.1 Product Identification
2.2 Engine
2.3 Mower
2.4 Traction and Differential
2.5 Weights
2.6 Accessories & Support Literature
Decals
3.1 Decals
Controls
4.1 Icons
4.2 Controls
Operation
5.1 Daily Inspection
5.2 Operator Presence Control (O.P.C.)
5.3 Operating Procedures
5.4 Starting/Stopping engine
5.5 Transport Wheels
5.6 Mowing
5.7 Grass Catcher
5.8 Weight Bars
Adjustments
6.1 General
6.2 Reel To Bedknife
6.3 Bedknife Adjuster
6.4 Bedknife
6.5 Clutch
6.6 Brake
6.7 Cutting Height
6.8 Belt Adjustment
6.9 OPC Lock-Out (T-Handle)
6.10 Handle
6.11 Torque Specification
Maintenance
7.1 General
7.2 Engine
7.3 Engine Oil
7.4 Tires
7.5 Wheel Bearing
7.6 Backlapping and Grinding
7.7 Daily Maintenance
7.8 Storage
Troubleshooting
8.1 General
Maintenance & Lubrication Charts
9.1 General
9.2 Maintenance Chart
9.3 Lubrication Chart
Parts Catalog
10.1 Table of Contents
1.1 Major Components
2.1 Handle Cover
3.1 Handle
4.1 T-Handle
5.1 Engine Base
6.1 Clutch
7.1 Reel
8.1 Lower Unit
9.1 Belts
10.1 Belt Cover
11.1 Weight Bars and Roller Brackets
12.1 Differential and Rollers
13.1 Parking Brake and Wheels
