Name: Jacobsen Mower Greens King IV Trueset Reels Instruction Sheet 4258373-P2 2012
SKU: 646517
Availability: InStock

Jacobsen Mower Greens King IV Trueset Reels Instruction Sheet 4258373 P2 2012 (1)

Jacobsen Mower Greens King IV Trueset Reels Instruction Sheet 4258373 P2 2012 (2)

Jacobsen Mower Greens King IV Trueset Reels Instruction Sheet 4258373 P2 2012 (3)

✓

Expert Support

✓

Full Speed

✓

100% Working

Jacobsen Mower Greens King IV Trueset Reels Instruction Sheet 4258373-P2 2012

Size: 1.39 MB

Format: PDF

Language: English

Brand: Jacobsen

Type of Machine: Mower

Type of Manual: Instruction Sheet, Parts List

Model: Jacobsen Greens King IV Trueset Reels Mower

62841 – 22 in. Left Hand 7 Blade TrueSet Reel

62842 – 22 in. Right Hand 7 Blade TrueSet Reel

62843 – 22 in. Left Hand 9 Blade TrueSet Reel

62844 – 22 in. Right Hand 9 Blade TrueSet Reel

62845 – 22 in. Left Hand 11 Blade TrueSet Reel

62846 – 22 in. Right Hand 11 Blade TrueSet Reel

62847 – 22 in. Left Hand 15 Blade TrueSet Reel

62848 – 22 in. Right Hand 15 Blade TrueSet Reel

Part Number: 4258373-P2

Publication Date: 2012

Number of Pages: 27 Pages

10 USD

Tags: Greens King IV Trueset Reels, Jacobsen Instruction Sheet, Jacobsen Mower Manual

Description

Description

Contents:
1 Safety
1.1 Operating Safety
1.2 Important Safety Notes
2 Specifications
2.1 Product Identification
2.2 Cutting Units
2.3 Accessories & Support Literature
2.4 Declaration of Incorporation
3 Setup
3.1 Front Roller and Accessories
3.2 Reel Motor
3.3 Torsion Springs
3.4 Anti-Sway Springs
4 Adjustments
4.1 General
4.2 Bedknife-To-Reel
4.3 Bedknife Adjustment
4.4 Cutting Height
4.5 Reel Bearing
4.6 Bedknife Adjuster Spring
4.7 Bedknife Adjuster Tension
4.8 Grinding Bedknife
4.9 Antisway Spring
4.10 Leveling Procedure
4.11 Torque Specification
5 Notes
