Jacobsen Mower LF-3400 LF-3800 Parts Maintenance Manual 4179107-B 2011

Size: 5.44 MB

Format: PDF

Language: English

Brand: Jacobsen

Type of Machine: Lightweight Fairway Mower

Type of Manual: Parts Catalog, Maintenance Manual, Wiring Diagram, Hydraulic Diagram

Model: Jacobsen LF-3400 LF-3800 Lightweight Fairway Mower

67971 – LF 3400, Kubota V1505-E3B, 5 Gang, 2WD

67972 – LF 3400, Kubota V1505-E3B, 5 Gang, 4WD

67958 – LF 3800, Kubota V1505-E3B, 5 Gang, 2WD

67959 – LF 3800, Kubota V1505-E3B, 5 Gang, 4WD

67960 – LF 3400 Turbo, Kubota V1505-T-E3B, 5 Gang, 4WD

67961 – LF 3800 Turbo, Kubota V1505-T-E3B, 5 Gang, 4WD

Part Number: 4179107-B

Publication Date: 2011

Number of Pages: 122 Pages

10 USD

Tags: Jacobsen Mower Manual, Jacobsen Parts Maintenance Manual, LF-3400, LF-3800

Description

Description

Contents:
1 Safety
1.1 Operating Safety
1.2 Important Safety Notes
2 Specifications
2.1 Product Identification
2.2 V1505-E3B Engine
2.3 V1505-T-E3B Engine
2.4 mower
2.5 Weights and Dimensions
2.6 LF 3400, LF3400 Turbo Cutting Units
2.7 LF 3800, LF 3800 Turbo Cutting Units
2.8 Declaration of Conformity
2.9 Accessories
2.10 Support Literature
3 Adjustments
3.1 General
3.2 Bedknife-To-Reel
3.3 Bedknife Adjustment
3.4 Cutting Height
3.5 Flash Attach
3.6 Down Pressure
3.7 Mow Speed
3.8 Belt
3.9 Brakes
3.10 Neutral Adjustment
3.11 Forward / Reverse Speed
3.12 Front Reel Limit Switch
3.13 Steering Toe-In
3.14 Torque Specification
4 Maintenance
4.1 General
4.2 Engine
4.3 Engine Oil
4.4 Air filter
4.5 Fuel
4.6 Fuel System
4.7 Battery
4.8 Jump Starting
4.9 Charging Battery
4.10 Muffler and Exhaust
4.11 Hydraulic Hoses
4.12 Hydraulic Oil
4.13 Hydraulic Filters
4.14 Electrical System
4.15 Radiator
4.16 Roll Over Protective Structure (ROPS)
4.17 Tires
4.18 Wheel Mounting Procedure
4.19 Care and Cleaning
4.20 Reel Backlapping
4.21 Storage
5 Troubleshooting
5.1 General
5.2 Controller Lamps
5.3 Electrical Circuits
6 Maintenance & Lubrication charts
6.1 General
6.2 Maintenance Chart
6.3 Lubrication Chart
7 Parts Catalog
7.1 How To Use The Parts Catalog
7.2 To Order Parts
