Jacobsen Mower TR-3 Front Lift Arm Field Kit LMAC187 Fitting Instructions 24764G-GB 2005

Size: 1.04 MB

Format: PDF

Language: English

Brand: Jacobsen

Type of Machine: Mower

Type of Manual: Fitting Instructions

Model: Jacobsen TR-3 Front Lift Arm Field Kit LMAC187 Mower

Product Code: TR30001

Series: EJ

Engine: Kubota D1105-E

Part Number: 24764G-GB

Publication Date: 2005

Number of Pages: 14 Pages

10 USD

Tags: Jacobsen Fitting Instruction, Jacobsen Mower Manual, LMAC187, TR-3

Description

Description

Contents:
2 SAFETY INSTRUCTIONS
2.1 OPERATING INSTRUCTIONS
2.2 SAFETY SIGNS
2.3 STARTING THE ENGINE
2.4 DRIVING THE MACHINE
2.5 TRANSPORTING
2.6 LEAVING THE DRIVING POSITION
2.7 SLOPES
2.8 BLOCKED CUTTING CYLINDERS
2.9 ADJUSTMENTS, LUBRICATION AND MAINTENANCE
3 PREPARATION
3.1 PREPARATION
4 FRONT LH LIFT ARM
4.1 REMOVE CUTTING UNIT FROM LIFT ARM
4.2 DISCONNECT LIFT RAM FROM LIFT ARM
4.3 REMOVE LIFT ARM FROM FRONT AXLE
4.4 ASSEMBLE NEW LIFT ARM TO FRONT AXLE
4.5 RECONNECT LIFT RAM TO LIFT ARM
4.6 ASSEMBLE CUTTING UNIT TO LIFT ARM
5 FRONT RH LIFT ARM
5.1 UPDATE RH LIFT ARM
5.2 FRONT RUBBER BUMP STOPS
6 PARTS LIST
