Name: Jacobsen Rotary Mower AR-3 1.7m Width Of Cut Field Kit Fitting Instructions 24772G-R1-GB 2005
SKU: 646688
Availability: InStock

Jacobsen Rotary Mower AR 3 1.7m Width Of Cut Field Kit Fitting Instructions 24772G R1 GB 2005 (1)

Jacobsen Rotary Mower AR 3 1.7m Width Of Cut Field Kit Fitting Instructions 24772G R1 GB 2005 (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

Jacobsen Rotary Mower AR-3 1.7m Width Of Cut Field Kit Fitting Instructions 24772G-R1-GB 2005

Size: 0.82 MB

Format: PDF

Language: English

Brand: Jacobsen

Type of Machine: Rotary Mower

Type of Manual: Fitting Instructions

Model: Jacobsen AR3 – Narrow Width 1.7m (67in) of Cut Field Kit LMAC199 Rotary Mower

Series: FZ – Engine Kubota D1105-T

Product Code: AR30002 – 72″ Width of Cut

Part Number: 24772G-R1-GB

Publication Date: 2005

Number of Pages: 20 Pages

10 USD

Tags: AR-3, Jacobsen Fitting Instruction, Jacobsen Rotary Mower Manual

Description

Description

Contents:
2 SAFETY INSTRUCTIONS
2.1 OPERATING INSTRUCTIONS
2.2 SAFETY SIGNS
2.3 STARTING THE ENGINE
2.4 DRIVING THE MACHINE
2.5 TRANSPORTING
2.6 LEAVING THE DRIVING POSITION
2.7 SLOPES
2.8 BLOCKED CUTTING CYLINDERS
2.9 ADJUSTMENTS, LUBRICATION AND MAINTENANCE
3 PREPARATION
3.1 PREPARATION
3.2 IMPORTANT NOTE
4 FRONT LH LIFT ARM
4.1 REMOVE CUTTING UNIT FROM LIFT ARM
4.2 DISCONNECT LIFT RAM FROM LIFT ARM
4.3 REMOVE LIFT ARM FROM FRONT AXLE
4.4 ASSEMBLE NEW LIFT ARM TO FRONT AXLE
4.5 RECONNECT LIFT RAM TO LIFT ARM
4.6 ASSEMBLE CUTTING UNIT TO LIFT ARM
5 CENTRE LIFT ARM
5.1 REMOVE CUTTING UNIT FROM LIFT ARM
5.2 DISCONNECT LIFT RAM FROM LIFT ARM
5.3 REMOVE LIFT ARM FROM MAINFRAME
5.4 ASSEMBLE NEW LIFT ARM TO MAINFRAME
5.5 RECONNECT LIFT RAM TO LIFT ARM
5.6 ASSEMBLE CUTTING UNIT TO LIFT ARM
5.7 REPOSITION YOKE BUFFER
6 PARTS LIST
7 NOTES
