Jacobsen Utility Vehicle Core Harvester Accessory Manual 4347186-B 2018

Size: 3.68 MB

Format: PDF

Language: English

Brand: Jacobsen

Type of Machine: Utility Vehicle

Type of Manual: Accessory Manual

Model: Jacobsen Core Harvester 4347127 Utility Vehicle

Part Number: 4347186-B

Publication Date: 2018

Number of Pages: 36 Pages

10 USD

Tags: Core Harvester, Jacobsen Accessory Manual, Jacobsen Utility Vehicle Manual

Description

Description

Contents:
Preface
1.1 Identification
Setup
2.1 Unpacking
2.2 Install Core Harvester Mounts
2.3 Conveyor Mounts
2.4 Elevator Assembly
2.5 Install Pipe Nipples
2.6 Install Caster Wheel
2.7 Tension Springs
2.8 Install Lift Handle
2.9 Conveyor Mounting
2.10 Routing Hydraulic Hoses
2.11 Shoe Assembly
2.12 Core Windrow Installation
Hydraulic System
Adjustments
4.1 General
4.2 Leveling Vehicle
4.3 Adjusting Conveyor Belt
4.4 Tension Spring Adjustment
4.5 Elevator Chain Adjustment
4.6 Torque Specification
Operation
5.1 General Operation
5.2 Lubrication
1.1 Core Harvestor
2.1 Main Frame
3.1 Elevator
4.1 Chain Assembly
5.1 Conveyor
6.1 Push Tube and Windrow Blade
7.1 Caster Pivot and Air Shock
8.1 Hydraulic Connections
