Name: Kubota Compact Trencher AP-CTR1030 AP-CTR1036 AP-CTR1048 Operation Manual 350-418MK
SKU: 561940
Price: 10.00 USD
Availability: InStock

Kubota Compact Trencher AP CTR1030 AP CTR1036 AP CTR1048 Operation Manual 350 418MK (1)

Kubota Compact Trencher AP CTR1030 AP CTR1036 AP CTR1048 Operation Manual 350 418MK (2)

✓

Expert Support

✓

Full Speed

✓

100% Working

Kubota Compact Trencher AP-CTR1030 AP-CTR1036 AP-CTR1048 Operation Manual 350-418MK

Size: 10.26 MB

Format: PDF

Language: English

Brand: Kubota

Type of Machine: Trencher

Type of Manual: Operation Manual

Model: Kubota AP-CTR1030, AP-CTR1036, AP-CTR1048 Trencher

Part Number: 350-418MK

Publication Date: 2023

Number of Pages: 58 Pages

10 USD

Tags: AP-CTR1030, AP-CTR1036, AP-CTR1048, Kubota Operation Manual, Kubota Trencher Manual

Description

Description

Contents:
Important Safety Information
Safety at All Times
Look for the Safety Alert Symbol
Safety Labels
Introduction
Application
Using This Manual
Owner Assistance
Section 1: Assembly & Set-up
Compact Utility Loader Requirements
Torque Requirements
Before You Start
Compact Loader Shutdown Procedure
Lift / Transport Anchor Points
Dealer Preparation and Set-up
Check Chain Overall Width
Check Auger Offset
Check Crumber Shoe Size
Check Chain Tension
Check Crumber Arm Clearance
Attach Depth Indicator
Hook-Up Trencher
Hook-Up Trencher
Hook-Up Hydraulics
Check Equipment Clearances
Section 2: Adjustments
Adjust Chain Tension
Adjust Auger Position
Section 3: Operating Procedures
Operating Checklist
Safety Information
Equipment Inspection
Transporting
Operating Guidelines
General Operating Instructions
Unhook Compact Trencher
Section 4: Options
Crumber Shoe Option
Trencher Chain Selection Options
Standard Cups, 2 Pitch Spacing
Standard Cups, 4 Pitch Spacing
Scorpion and Cup Teeth
Motor (Option)
Section 5: Maintenance & Lubrication
Maintenance
General Inspection
Chain Service in Harsh Conditions
Auger Removal
Auger Installation
Crumber Shoe Maintenance
Check Chain Tension
Check Chain and Sprocket Wear
Chain Removal and Replacement
Remove & Install Single Chain Strand
Chain Removal
Chain Installation
Remove & Install Continuous Chain Loop
Chain Removal
Chain Installation
Sprocket Replacement
General Tooth Maintenance
Cup Teeth
Scorpion Teeth
Remove & Install Front Roller
Remove Front Roller
Install Front Roller
Replace Bearing in Front Roller
Remove Old Bearing From Front Roller
Install New Bearing in Front Roller
Long-Term Storage
Lubrication Points
Section 6: Specifications & Capacities
Section 7: Features & Benefits
Section 8: Troubleshooting
Section 9: Torque Values Chart
Section 10: Warranty & Legal Disclaimer
