ROPA Harvester potato loader Kartoffelmaus 5 RKM5 2020- Spare Parts Catalog

Description

Contents:
Ropa potato loader Kartoffelmaus 5 RKM5 2020-
0 Cover Ropa potato loader Kartoffelmaus 5 RKM5 2020-
01 – Pickup
01.01 – E5720001 Central pickup part – support rollers and accessories
01.02 – E5720002 Central pickup part – attached parts
01.03 – E5720003 Central pickup part – side plates
01.04 – E5720004 Central pickup part – hydraulic cylinders
01.05 – E5720005 Central pickup part – bearing and angle sensor
01.06 – E5720006 Central pickup part – support wheel left
01.07 – E5720007 Central pickup part – support wheel right
01.08 – E5720008 Central pickup part – support wheel hydraulic cylinders – left and right
01.09 – E5720009 Pickup side section left – fold plate
01.10 – E5720010 Pickup side section right – fold plate
01.11 – E5720011 Pickup side section left – side plate
01.12 – E5720012 Pickup side section right – side plate
01.13 – E5720013 Pickup side section left – frame rear
01.14 – E5720014 Pickup side section right – frame rear
01.15 – E5720015 Pickup side section left – frame front
01.16 – E5720016 Pickup side section right – frame front
01.17 – E5720017 Pickup side section left – clearing shield and support foot
01.18 – E5720018 Pickup side section right – clearing shield and support foot
01.19 – E5720019 Pickup side section left – frame with angle sensor and push switch
01.20 – E5720020 Pickup side section right – frame with angle sensor and push switch
01.21 – E5720021 Pickup side section left – frame with gears and counter bearing
01.22 – E5720022 Pickup side section right – frame with gears and counter bearing
01.23 – E5720023 Pickup side section left – drive rear till year of constr. 2021
01.23 – E5720041 Pickup side section left – drive rear from year of constr. 2022
01.24 – E5720024 Pickup side section right – drive rear till year of constr. 2021
01.24 – E5720042 Pickup side section right – drive rear from year of constr. 2022
01.25 – E5720025 Pickup side section left – drive front
01.26 – E5720026 Pickup side section right – drive front
01.27 – E5720027 Pickup side section left – rollers
01.28 – E5720028 Pickup side section right – rollers
01.29.1 – E5720029 Pickup gears left – part 1
01.29.2 – E5720030 Pickup gears left – part 2
01.29.3 – E5720031 Pickup gears left – part 3
01.30.1 – E5720032 Pickup gears right – part 1
01.30.2 – E5720033 Pickup gears right – part 2
01.30.3 – E5720034 Pickup gears right – part 3
01.31 – E5720035 Pickup chains – left and right
01.32 – E5720036 Central mark – attached parts
01.33 – E5720037 Central mark – hydraulic cylinders, camera and LED light
01.34.1 – E5720038 Central mark – covers – part 1
01.34.2 – E5720039 Central mark – covers – part 2
02 – Pile pickup
02.01 – E5720051 Pile pickup – mounting
02.02 – E5720052 Pile pickup – hydraulic cylinders
02.03 – E5720053 Residual potato pickup
02.04 – E5720054 Warning sign bracket with illumination
03 – Infeed conveyor and roller cleaning
03.01 – E5720061 Infeed conveyor duct with supporting rollers
03.02 – E5720062 Infeed conveyor channel with PE plates and wiper rubbers
03.03 – E5720063 Infeed conveyor ejector with drive
03.04 – E5720064 Retract infeed conveyor
03.05 – E5720065 Sieve conveyor for infeed conveyor
03.06 – E5720066 Energy chain for roller cleaner
03.07.1 – E5720067 Frame roller cleaner with attachments – part 1
03.07.2 – E5720068 Frame roller cleaner with attachments – part 2
03.08 – E5720069 Suspension – roller cleaner – front-bottom
03.09.1 – E5720070 Suspension – roller cleaner – rear_top – part 1
03.09.2 – E5720071 Suspension – roller cleaner – rear_top – part 2
03.10 – E5720072 Bearing – roller cleaner
03.11.1 – E5720073 Gears – roller cleaner – part 1
03.11.2 – E5720076 Gears – roller cleaner – part 2
03.12 – E5720074 Gears – roller cleaner – inflow sheet
03.13 – E5720075 Potato brake for roller cleaner
04 – Truck conveyor
04.01 – E5720081 Swivel arm
04.02 – E5720082 Swivel arm – bearing and lock
04.03 – E5720083 Swivel arm – chain guide with hydraulic cylinders
04.04 – E5720084 Hydraulic cylinder – swivel arm – truck conveyor
04.05 – E5720085 Swivel support
04.06 – E5720086 Swivel frame – side parts with support rollers
04.07 – E5720087 Swivel frame – side parts with rubber aprons
04.08 – E5720088 Swivel frame – side parts with wiper rubbers
04.09 – E5720089 Truck conveyor with support rollers and accessories
04.10 – E5720090 Truck conveyor with wear plates and hydraulic cylinder
04.11 – E5720091 Truck conveyor with wiper rubbers
04.12 – E5720092 Truck conveyor articulation part with supporting rollers
04.13 – E5720093 Truck conveyor articulation with wear plates with rubber apron
04.14 – E5720094 Truck conveyor articulation part with wiper rubbers
04.15 – E5720095 Truck conveyor drive
04.16 – E5720096 Sieve conveyor for truck conveyor
Special equipment
04.20 – E5720097 Model – CAN weighing machine – 1 pair of weighing cells HBM
04.21 – E5720098 Model – CAN weighing machine – 3 pair of weighing cells HBM
04.22 – E5720099 Model – CAN weighing machine – 1 pair of weighing cells Flintec
05 – Chassis
05.01 – E9115091 Chassis with attached parts
05.02.1 – E9115092 Transfer gear with drive – part 1
05.02.2 – E9115090 Transfer gear with drive – part 2
05.03.1 – E9115093 Front and rear axles with accessories – part 1
05.03.2 – E9115118 Front and rear axles with accessories – part 2
05.04 – E9115094 Axle 3 additional axle
05.05 – E5720120 4th axle additional axle
05.06 – E9115096 Raise cabin
05.07 – E9115097 Cabin platform with treads
05.08 – E9115098 Cabin platform with safety barrier
05.09 – E9115099 Pneumatic ladder adjustment
05.10 – E9115100 Folding grill platform
05.11 – E9115101 Counterweight arm bearing
05.12 – E9115102 Counterweight arm toggle lever
05.13 – E9115103 Counterweight arm lock
05.14 – E9115104 Diesel tank swivel fastening
05.15 – E9115105 Diesel tank tail lamps and attachments
05.16 – E9115106 Diesel tank underride guard
05.17 – E9115107 Diesel tank ladder
05.18 – E9115108 Engine and gear covers – inside
05.19 – E9115109 Pump cover
05.20 – E9115110 Engine compartment cover
05.21 – E9115111 Engine compartment doors with accessories
05.22 – E9115112 Storage compartment – engine compartment
05.23 – E9115113 Battery compartment and tool box – left
05.24 – E9115114 Exhaust cover
05.25 – E5720111 Stickers – front and left
05.26 – E5720112 Stickers – rear and right
05.27 – E9115124 Vehicle tools and accessories
Komponenten und Details
– E9800479 Additional axle wheel bearing
Special equipment
05.30.1 – E9115115 Model – tool box – right
05.30.2 – E9115116 Cover for tool box
05.31 – E9115117 Model – tool box – rear
05.32.1 – E5720113 Water spray system – water tank
05.32.2 – E5720114 Water spray system – cover for water tank
05.33 – E5720115 Water spray system – fittings
05.34 – E5720116 Water spray system – pickup
05.35 – E5720117 Water spray system – rollers cleaner from below
06 – Cabin
06.01 – E9115135 Glass panels and accessories
06.02 – E9115136 Cabin doors
06.03 – E9115137 Cabin mounting, cabin roof and accessories
06.04 – E9115138 Fresh air filter and air jets
06.05 – E9115139 Roof console – front
06.06 – E9115140 Roof console – right
06.07.1 – E9115141 Terminal console – part 1
06.07.2 – E9115142 Terminal console – part 2
06.07.3 – E9115143 Terminal console – part 3
06.08.1 – E9115156 Rotating seat – lock from year of construction 2018
06.08.2 – E9115145 Rotating seat – bearing
06.09 – E9115146 Steering column
06.10 – E9115147 Window wiper – front window
06.11 – E9115148 Window wipers – side and rear
06.12 – E9115149 Windscreen washer system
06.13 – E5720121 Mirror bracket – left and right
06.14 – E9115151 Working floodlights
06.15 – E9115152 Accelerator and brake pedals
06.16 – E9115153 Cabin cover
06.17.1 – E9115154 Stickers – cabin and central electrical system
06.17.2 – E9115155 Stickers – cabin and central electrical system – for USA_CANADA
Special equipment
06.20 – E9115157 Holders for further systems
07 – Engine
07.01.1 – E9115161 Fuel system – part 1
07.01.2 – E9115162 Fuel system – part 2
07.01.3 – E9115163 Fuel system – part 3
07.01.4 – E9115181 Fuel system – part 4
07.02 – E9115164 AdBlue system
07.03 – E9115165 Diesel engine with mounting
07.04 – E9115166 Pump distributor gears
07.05 – E9115167 Exhaust system
07.06 – E9115168 Air filter system
07.07.1 – E9115169 Radiator
07.07.2 – E9115170 Charge air cooler
07.08.1 – E9115171 Radiator bonnet with accessories – part 1
07.08.2 – E9115172 Radiator bonnet with accessories – part 2
07.09 – E9115173 Fan drive with accessories
07.10.1 – E9115174 Heating system – part 1
07.10.2 – E9115175 Heating system – part 2
07.10.3 – E9115176 Heating system with grease bucket heating – part 3
07.11 – E9115177 Air conditioning system
07.12 – E9115178 Diesel engine OM 936
07.13 – E9115179 Connecting battery, starter and generator
Components and Details
– E9800486 303026800 – Fuel filter with water separator and e-pump
08 – Pneumatic system
08.01 – E9115200 Air compressor – air dryer connection
08.02 – E9115201 Air chamber fixing
08.03 – E9115202 Air chamber connection
08.04.1 – E9115203 Brake connection – part 1
08.04.2 – E9115204 Brake connection – part 2
08.04.3 – E9115205 Brake connection – part 3
08.05 – E9115206 Switch and differential lock connection
08.06 – E9115207 Connection fold ladder and warning sign
08.07 – E9115208 Mirror adjustment, seat brake and air gun connection
08.08 – E5720150 Connection brake axle 4 additional axle
Special equipment
08.10 – E9115209 Model – all-wheel switching
09 – Hydraulic system
Pickup central section
09.01.1 – E5720122 Connection central mark – part 1
09.01.2 – E5720123 Connection central mark – part 2
09.02 – E5720124 Connection support wheel hydraulic cylinders – left
09.03 – E5720125 Connection support wheel hydraulic cylinders – right
09.04 – E5720126 Pickup central part – flow line left
09.05 – E5720127 Pickup central part – flow line right
09.06 – E5720128 Pickup central part – flow line front left & right
09.07 – E5720129 Pickup central part – leak oil
09.08 – E5720130 Pickup central part – pickup chains & conveyor rollers – right
09.09 – E5720131 Pickup central part – pickup chains & conveyor rollers – left
Pickup side section
09.10.1 – E5720132 Pickup side section left rear – part 1
09.10.2 – E5720133 Pickup side section left rear – part 2
09.11.1 – E5720134 Pickup side section right rear – part 1
09.11.2 – E5720135 Pickup side section right rear – part 2
09.12 – E5720136 Pickup side section left – pickup chains, cleaning roller & conveyor rollers
09.13 – E5720137 Pickup side section right – pickup chains, cleaning roller & conveyor rollers
09.14 – E5720138 Pickup side section left – retract pickup and fold plate
09.15 – E5720139 Pickup side section right – retract pickup and fold plate
09.16 – E5720140 Pickup side section left – clearing shield and support foot
09.17 – E5720141 Pickup side section right – clearing shield and support foot
Pile pickup
09.02 – E9115222 Lines – pile pickup – up_down and in_out
09.03 – E9115223 Lines pile pickup – left_right
09.04 – E9115224 Lines – residual beet pickup – turn
09.11 – E9115231 Feed – connection of frame to pickup
09.12 – E9115232 Drive – connection of frame to pickup
09.13 – E9115233 Lines – lift pickup
09.14.1 – E9115234 Lines – fold pickup – part 1
09.14.2 – E9115235 Lines – fold pickup – part 2
09.15.1 – E9115236 Connection – orbit steering unit – part 1
09.15.2 – E9115237 Connection – orbit steering unit – part 2
09.16 – E9115238 Connection – front axle steering
09.17.1 – E9115239 Connection – rear axle steering – part 1
09.17.2 – E9115240 Connection – rear axle steering – part 2
09.18 – E9115241 Connection – lifting the cabin
09.19 – E9115242 Connection – high-pressure filter
09.20.1 – E9115243 Lines – feed additional axle and axle support – part 1
09.20.2 – E9115244 Lines – feed additional axle and axle support – part 2
09.21 – E9115245 Connection – pressure reservoir additional axle
09.22.1 – E5720146 Connection – axle 3 and pickup support wheel – part 1
09.22.2 – E5720147 Connection – axle 3 and pickup support wheel – part 2
09.22.3 – E5720148 Connection – axle 3 and pickup support wheel – part 3
09.23 – E9115247 Connection – axle 4
09.24 – E9115248 Hydraulic cylinder – axle support
09.25 – E9115249 LS and operating hydraulics supply line
09.26 – E9115250 Lines – control blocks operating hydraulics 1 to operating hydraulics 2
09.27 – E9115251 Lines – control unit for operating hydraulics 2
Roller cleaner
09.20 – E5720142 Energy chain for roller cleaner
09.21 – E5720143 Roller cleaner drive
09.22 – E5720144 Hydraulic cylinder for locking roller cleaner
09.23 – E5720145 Potato brake hydraulic cylinders
09.60 – E9115256 Connection – swinging the cleaner
09.61.1 – E9115258 Drive – loader and articulating the loader
09.61.2 – E9115260 Drive – infeed conveyor-truck conveyor from year of constr. 2017
09.62 – E9115261 Connection – raise truck conveyor
09.63.1 – E9115262 Connection – turning the swivel arm – part 1
09.63.2 – E9115263 Connection – turning the swivel arm – part 2
09.64 – E9115264 Connection – locking the swivel arm
09.65 – E9115265 Feed – swivel arm
09.66 – E9115266 Feed – counterweight arm
09.67 – E9115267 Connection – swinging the counterweight arm
09.68 – E9115268 Connection – locking the counterweight arm
09.69 – E9115269 Connection – lifting the counterweight arm fuel oil tank
09.70 – E9115270 Connection – oil cooler
09.71 – E9115271 Connection – traction drive at PDG with 1 traction drive engine
09.72.1 – E9115272 Connection – traction drive at PDG with 2 traction drive engines – part 1
09.72.2 – E9115273 Connection – traction drive at PDG with 2 traction drive engines – part 2
09.73 – E9115274 Lubrication lines at PDG
09.74.1 – E9115275 Suction hoses at PDG – part 1
09.74.2 – E9115276 Suction hoses at PDG – part 2
09.74.3 – E9115277 Suction hoses at PDG – part 3
09.74.4 – E9115278 Suction hoses at PDG – part 4
09.74.5 – E9115279 Suction hoses at PDG – part 5
09.74.6 – E5720149 Suction hoses at PDG – part 6
09.75 – E9115281 Hydraulic oil tank
09.76 – E9115282 Hydraulic return filter
09.77 – E9115283 Hydraulic brake rear axle
10 – Central electrical system
– E9800477 Übersicht Stecker – Teil 2
– E9800478 018079700 – Electrical assortment box
– E9800499 Overview of plugs
10.01 – E9115311 Switching cabinet for the central electrical system
10.02 – E9115312 Electric parts for the central electrical system
10.03 – E9115313 R-Connect TC3G – till ch. no. 8L_
10.03 – E9115314 R-Connect TCG4 – from ch. no. 8M_
10.04 – E9115315 Video cameras
11 – Gears & axles
299023501 – pump distributor gears
11.08 – E5720157 O-10620040 Pump distributor gears – housing
11.09 – E5720158 O-10620040 Pump distributor gears – drive shaft
11.10 – E5720159 O-10620040 Pump distributor gears – intermediate shaft
11.11 – E5720160 O-10620040 Pump distributor gears – coupling shaft
11.12 – E5720161 O-10620040 Pump distributor gears – coupling shaft
11.13 – E5720162 O-10620040 Pump distributor gears – output drive shaft
299025901 – Transmission with 1 traction drive motor
11.22 – E9115350 O-10560137 Housing for manual transmission
11.23 – E9115351 O-10560137 Manual transmission drive shaft
11.24 – E9115352 O-10560137 Manual transmission output drive shaft
11.25 – E9115353 O-10560137 Gearshift – gear 1-2
11.26 – E9115354 O-10560137 All-wheel switching
11.27 – E9115355 O-10560137 Reduction gearing
299025911 – Transmission with 1 traction drive motor
11.22 – E9122430 O-10560165 Housing for manual transmission
11.23 – E9122432 O-10560165 Manual transmission drive shaft
11.24 – E9122433 O-10560165 Manual transmission output drive shaft
11.25 – E9122434 O-10560165 Gearshift – gear 1-2
11.26 – E9122435 O-10560165 All-wheel switching
11.27 – E9122436 O-10560165 Reduction gearing
299028601 – front axle
11.14 – E9115330 O-11220098 Front axle
11.15 – E9115331 O-11220098 Front axle – differential housing
11.16 – E9115332 O-11220098 Front axle – wheel hub
11.17 – E9115333 O-11220098 Front axle – drum brake
299028701 – rear axle
11.18 – E9115340 O-11220099 rear axle
11.19 – E9115341 O-11220099 Rear axle – differential housing
11.20 – E9115342 O-11220099 Rear axle – wheel hub
11.21 – E9115343 O-11220099 Rear axle – drum brake
299029801 – Transmission with 2 traction drive motors
– E9800488 Overview of sealants and aid materials
11.28 – E9115360 O-10560151 Housing for manual transmission
11.29 – E9115361 O-10560151 Manual transmission drive shaft
11.30 – E9115362 O-10560151 Manual transmission output drive shaft
11.31 – E9115363 O-10560151 Gearshift – gear 1-2
11.32 – E9115364 O-10560151 All-wheel switching
11.33 – E9115365 O-10560151 Reduction gearing
11.34 – E9115366 O-10560151 2nd traction motor drive
570001000 – roller cleaner gears
11.07 – E5720077 181015400 Gears – roller cleaner
570001500 _ 570001600 – Pickup gears
11.01 – E5720151 Pickup gears left – part 1
11.02 – E5720152 Pickup gears left – part 2
11.03 – E5720153 Pickup gears left – part 3
11.04 – E5720154 Pickup gears right – part 1
11.05 – E5720155 Pickup gears right – part 2
11.06 – E5720156 Pickup gears right – part 3
13 – Central lubrication
13.01 – E5720100 Central lubricating system
13.02 – E5720101 Central lubricating pump with grease bucket
13.03 – E5720102 Central lubricating pump
13.04 – E5720103 Distributor – components
13.05 – E5720104 Hose connections
13.06 – E5720105 Screw connections – central lubrication
14 – Park heating
– E9800618 320084400 – park heating Thermo Pro 90
15 – Hydraulic screw connections
15.01 – E9800500 Hydraulic screw connection – type_ G
15.02 – E9800501 Hydraulic screw connection – type_ W
15.03 – E9800502 Hydraulic screw connection – type_ T
15.04 – E9800503 Hydraulic screw connection – type_ K
15.05 – E9800504 Hydraulic screw connection – type_ EVW
15.06 – E9800505 Hydraulic screw connection – type_ EVT
15.07 – E9800506 Hydraulic screw connection – type_ EVL
15.08.1 – E9800507 Hydraulic screw connection – type_ EVGE – part 1 metric
15.08.2 – E9800508 Hydraulic screw connection – type_ EVGE – part 2 inch
15.09.1 – E9800509 Hydraulic screw connection – type_ GE – part 1 metric
15.09.2 – E9800510 Hydraulic screw connection – type_ GE – part 2 metric
15.09.3 – E9800511 Hydraulic screw connection – type_ GE – part 3 metric
15.09.4 – E9800512 Hydraulic screw connection – type_ GE – part 4 inch
15.09.5 – E9800513 Hydraulic screw connection – type_ GE – part 5 inch
15.09.6 – E9800514 Hydraulic screw connection – type_ GE – part 6 inch
15.10 – E9800515 Hydraulic screw connection – type_ GR
15.11 – E9800516 Hydraulic screw connection – type_ GVO
15.12.1 – E9800517 Hydraulic screw connection – type_ KOR – part 1
15.12.2 – E9800518 Hydraulic screw connection – type_ KOR – part 2
15.13 – E9800519 Hydraulic screw connection – type_ SWVE
15.14.1 – E9800520 Hydraulic screw connection – type_ VSTI – part 1 metric
15.14.2 – E9800521 Hydraulic screw connection – type_ VSTI – part 2 inch
15.15 – E9800522 Hydraulic screw connection – type_ ROV
15.16.1 – E9800523 Hydraulic screw connection – type_ RED – part 1 metric
15.16.2 – E9800524 Hydraulic screw connection – type_ RED – part 2 inch
15.17 – E9800525 Hydraulic screw connection – type_ GAI
15.18 – E9800526 Hydraulic screw connection – type_ MAV
15.19 – E9800527 Hydraulic screw connection – type_ MAV-EV
15.20 – E9800528 Hydraulic screw connection – type_ Measuring screw connection
15.21 – E9800529 Hydraulic screw connection – type_ measuring port
15.22 – E9800530 Hydraulic screw connection – type_ gauge connection
15.23 – E9800531 Hydraulic screw connection – type_ pressure gauge
15.24 – E9800532 Hydraulic screw connection – type_ pressure gauge connection
15.25 – E9800533 Hydraulic screw connection – type_ hose for pressure gauge
15.26 – E9800534 Hydraulic screw connection – type_ Bulkhead screw connection
15.27 – E9800535 Hydraulic screw connection – type_ Bulkhead union elbow
15.28 – E9800536 Hydraulic screw connection – type_ Flat nut for bulkhead screw connections
15.29 – E9800537 Hydraulic screw connection – type_ screw cap
15.30 – E9800538 Hydraulic screw connection – type_ BUZ
15.31 – E9800539 Hydraulic screw connection – type_ cutting ring
15.32 – E9800540 Hydraulic screw connection – type_ reinforcing sleeve
21 – Lubricants and filter lists
21.01 – E9016500 Lubricants
21.02 – E9115450 Filter for diesel engine
21.03 – E9115451 Filter for hydraulic system and gears
21.04 – E9115452 Filter for cabin
21.05 – E9115453 Further filters
22 – Control blocks and seat valves
– E9800001 270043100 – seat valves 4-part
– E9800004 270047000 – seat valves 1-part
– E9800009 270051400 – control unit
– E9800015 270064200 – control unit – additional axle
– E9800022 270043200 – seat valves 2-part
– E9800024 270060000 – control unit – coupling
– E9800025 270061400 – Control unit – operating hydraulics 1
– E9800026 270061500 – Control unit – operating hydraulics 2
– E9800027 270061800 – control unit – axle support
– E9800029 270063800 – Seat valve 2-part pilot
– E9800030 270079700 – control unit – infeed conveyor-truck conveyor and fast motion without backstop
– E9800053 270063810 – Seat valve 2-part pilot
– E9800128 270062200 – Steuerblock – Mietenabräumer
23 – Hydraulic motors and cylinders
– E9800032 272015400 – gear motor
– E9800117 276023601 – hydraulic cylinders ø50 x ø30 x 545mm
