ROPA Harvester Tiger 5 2014-2017 Spare Parts Catalog

Description

Contents:
ROPA Tiger 5 2014-2017
ROPA Tiger 5 2014-2017
0 Cover ROPA Tiger 5 2014-2017
01 – Topper
01 – Topper PASOh-45_50 from year of construction 2011
01.01 – E906199 Leaf sensor PSh
01.02.1 – E906198 Topper wheel – internal PSOh
01.02.2 – E906197 Topper wheel – external PSOh_RSO
01.03.1 – E906690 Topper housing – left PASOh
01.03.2 – E906691 Topper housing – right PASOh
01.04.1 – E906692 Adjustment tube for changeover flap PASOh
01.04.2 – E906693 Topper housing – front PASOh
01.04.3 – E906664 Topper housing – upper rear PASh
01.04.4 – E906673 Topper housing – lower rear PASh-45_50
01.05 – E906666 Topper shaft – to year of construction 2013 PASh
01.05.1 – E906677 Topper shaft – from year of construction 2014 PASh-45
01.05.2 – E906678 Topper shaft – from year of construction 2014 PASh-50
01.06 – E906667 Leaf auger PASh_PB2Sh
01.07.1.1 – E906177 Leaf spreader – standard PBSh_PASh
01.07.1.2 – E906182 Leaf spreader – stone ejector PBSh_PASh
01.07.2 – E906668 Holding device for leaf spreader PASh_PB2Sh
01.08 – E906674 Scalper bar PASh-45_50_PB2Sh-45_50
01.09 – E906675 Scalper holding frame PASh-45_50_PB2Sh-45_50
01.10.1 – E906183 Scalper – standard PBSh_PASh
01.10.2 – E906184 Scalper – Micro-Topper 2 PBSh_PASh
01.11 – E906689 Central lubrication and stickers PASOh
Hydraulic system – topper PASOh-45_50
01.20 – E906694 Drive topper shaft and leaf auger PASOh
01.21 – E906695 Leak oil topper shaft and leaf auger PASOh
01.22 – E906696 Topper wheel PASOh
01.23 – E906697 Cutting depth adjustment PASOh
01.24 – E906698 Leaf spreader PASOh
01.25 – E906699 Fold leaf spreader and changeover flap PASOh
01 – Topper PASWh-45_50 from year of construction 2011
01.01 – E906199 Leaf sensor PSh
01.02.1 – E905355 Topper wheel – wheel arm bracket PASWh_PBSWh_PISh_RASW_RIS
01.02.2 – E905377 Topper wheel – swivel guide PASWh_PBSWh_PISh
01.03.1 – E906660 Topper housing – left PASWh
01.03.2 – E906661 Topper housing – right PASWh
01.04.1 – E906662 Adjustment tube for changeover flap PASWh
01.04.2 – E906663 Topper housing – front PASWh
01.04.3 – E906664 Topper housing – upper rear PASh
01.04.4 – E906673 Topper housing – lower rear PASh-45_50
01.05 – E906666 Topper shaft – to year of construction 2013 PASh
01.05.1 – E906677 Topper shaft – from year of construction 2014 PASh-45
01.05.2 – E906678 Topper shaft – from year of construction 2014 PASh-50
01.06 – E906667 Leaf auger PASh_PB2Sh
01.07.1.1 – E906177 Leaf spreader – standard PBSh_PASh
01.07.1.2 – E906182 Leaf spreader – stone ejector PBSh_PASh
01.07.2 – E906668 Holding device for leaf spreader PASh_PB2Sh
01.08 – E906674 Scalper bar PASh-45_50_PB2Sh-45_50
01.09 – E906675 Scalper holding frame PASh-45_50_PB2Sh-45_50
01.10.1 – E906183 Scalper – standard PBSh_PASh
01.10.2 – E906184 Scalper – Micro-Topper 2 PBSh_PASh
01.11 – E906672 Central lubrication and stickers PASWh
Hydraulic system – topper PASWh-45_50
01.20 – E906680 Drive topper shaft and leaf auger PASWh
01.21 – E906681 Leak oil topper shaft and leaf auger PASWh
01.22 – E906682 Topper wheel PASWh
01.23 – E906683 Cutting depth adjustment PASWh
01.24 – E906684 Leaf spreader PASWh
01.25 – E906685 Fold leaf spreader and changeover flap PASWh
Model – leaf belt
01.30 – E906671 Leaf belt with accessories PASWh
01.31 – E906676 Hydraulic system_ leaf belt PASWh
01 – Topper PASWh-V from year of construction 2010
01.01 – E906199 Leaf sensor PSh
01.02.1 – E905355 Topper wheel – wheel arm bracket PASWh_PBSWh_PISh_RASW_RIS
01.02.2 – E905377 Topper wheel – swivel guide PASWh_PBSWh_PISh
01.03.1 – E906660 Topper housing – left PASWh
01.03.2 – E906661 Topper housing – right PASWh
01.04.1 – E906662 Adjustment tube for changeover flap PASWh
01.04.2 – E906663 Topper housing – front PASWh
01.04.3 – E906664 Topper housing – upper rear PASh
01.04.4 – E906665 Topper housing – lower rear PASWh
01.05 – E906666 Topper shaft – to year of construction 2013 PASh
01.05 – E906679 Topper shaft – from year of construction 2014 PASh-V
01.06 – E906667 Leaf auger PASh_PB2Sh
01.07.1.1 – E906177 Leaf spreader – standard PBSh_PASh
01.07.1.2 – E906182 Leaf spreader – stone ejector PBSh_PASh
01.07.2 – E906668 Holding device for leaf spreader PASh_PB2Sh
01.08 – E906669 Scalper bar PASWh-V_PB2SWh-V
01.09 – E906670 Scalper holding frame PASWh-V_PB2SWh-V
01.10.1 – E906183 Scalper – standard PBSh_PASh
01.10.2 – E906184 Scalper – Micro-Topper 2 PBSh_PASh
01.11 – E906672 Central lubrication and stickers PASWh
Hydraulic system – PASWh-V topper
01.20 – E906680 Drive topper shaft and leaf auger PASWh
01.21 – E906681 Leak oil topper shaft and leaf auger PASWh
01.22 – E906682 Topper wheel PASWh
01.23 – E906683 Cutting depth adjustment PASWh
01.24 – E906684 Leaf spreader PASWh
01.25 – E906685 Fold leaf spreader and changeover flap PASWh
01.26 – E906686 Scalper – displacement cylinder PASWh-V
01.27 – E906687 Scalper – clamping cylinder PASWh-V
Model – leaf belt
01.30 – E906671 Leaf belt with accessories PASWh
01.31 – E906676 Hydraulic system_ leaf belt PASWh
01 – Topper PB2SOh-45 from year of construction 2012
01.01 – E906199 Leaf sensor PSh
01.02.1 – E906198 Topper wheel – internal PSOh
01.02.2 – E906197 Topper wheel – external PSOh_RSO
01.03.1 – E906731 Topper housing – left PB2SOh
01.03.2 – E906733 Topper housing – right PB2SOh
01.04.1 – E906739 Topper housing – front – part 1 PB2SOh-45_RBSO-45
01.04.2 – E906741 Topper housing – front – part 2 PB2SOh-45_RBSO-45
01.04.3 – E906742 Topper housing – rear PB2Sh
01.05 – E906737 Topper shaft PB2SOh-45
01.06 – E906667 Leaf auger PASh_PB2Sh
01.07.1.1 – E906177 Leaf spreader – standard PBSh_PASh
01.07.1.2 – E906182 Leaf spreader – stone ejector PBSh_PASh
01.07.2 – E906668 Holding device for leaf spreader PASh_PB2Sh
01.08 – E906674 Scalper bar PASh-45_50_PB2Sh-45_50
01.09 – E906675 Scalper holding frame PASh-45_50_PB2Sh-45_50
01.10.1 – E906183 Scalper – standard PBSh_PASh
01.10.2 – E906184 Scalper – Micro-Topper 2 PBSh_PASh
01.11 – E906744 Central lubrication and stickers PB2SOh
Components and Details
01.40 – E9416136 Replace topper hood RBSO-45_PB2SOh-45
Hydraulic system – PB2SOh-45 topper
01.20 – E906760 Drive topper shaft and leaf auger PB2SOh-45
01.21 – E906761 Leak oil topper shaft and leaf auger PB2SOh-45
01.22 – E906762 Topper wheel PB2SOh-45
01.23 – E906763 Cutting depth adjustment PB2SOh-45
01.24 – E906764 Leaf spreader PB2SOh-45
01.25 – E906765 Fold leaf spreader and changeover flap PB2SOh-45
01 – Topper PB2SWh-45_50 from year of construction 2012
01.01 – E906199 Leaf sensor PSh
01.02.1 – E905355 Topper wheel – wheel arm bracket PASWh_PBSWh_PISh_RASW_RIS
01.02.2 – E905377 Topper wheel – swivel guide PASWh_PBSWh_PISh
01.03.1 – E906730 Topper housing – left PB2SWh
01.03.2 – E906732 Topper housing – right PB2SWh
01.04.1 – E906738 Topper housing – front – part 1 PB2SWh
01.04.2 – E906740 Topper housing – front – part 2 PB2SWh
01.04.3 – E906742 Topper housing – rear PB2Sh
01.05.1 – E906734 Topper shaft PB2SWh-45
01.05.2 – E906735 Topper shaft PB2SWh-50
01.06 – E906667 Leaf auger PASh_PB2Sh
01.07.1.1 – E906177 Leaf spreader – standard PBSh_PASh
01.07.1.2 – E906182 Leaf spreader – stone ejector PBSh_PASh
01.07.2 – E906668 Holding device for leaf spreader PASh_PB2Sh
01.08 – E906674 Scalper bar PASh-45_50_PB2Sh-45_50
01.09 – E906675 Scalper holding frame PASh-45_50_PB2Sh-45_50
01.10.1 – E906183 Scalper – standard PBSh_PASh
01.10.2 – E906184 Scalper – Micro-Topper 2 PBSh_PASh
01.11 – E906743 Central lubrication and stickers PB2SWh
Hydraulic system – topper PB2SWh-45_50
01.20 – E906750 Drive topper shaft and leaf auger PB2SWh
01.21 – E906751 Leak oil topper shaft and leaf auger PB2SWh
01.22 – E906752 Topper wheel PB2SWh
01.23 – E906753 Cutting depth adjustment PB2SWh
01.24 – E906754 Leaf spreader PB2SWh
01.25 – E906755 Fold leaf spreader PB2SWh
01 – Topper PB2SWh-V from year of construction 2012
01.01 – E906199 Leaf sensor PSh
01.02.1 – E905355 Topper wheel – wheel arm bracket PASWh_PBSWh_PISh_RASW_RIS
01.02.2 – E905377 Topper wheel – swivel guide PASWh_PBSWh_PISh
01.03.1 – E906730 Topper housing – left PB2SWh
01.03.2 – E906732 Topper housing – right PB2SWh
01.04.1 – E906738 Topper housing – front – part 1 PB2SWh
01.04.2 – E906740 Topper housing – front – part 2 PB2SWh
01.04.3 – E906742 Topper housing – rear PB2Sh
01.05 – E906736 Topper shaft PB2SWh-V
01.06 – E906667 Leaf auger PASh_PB2Sh
01.07.1.1 – E906177 Leaf spreader – standard PBSh_PASh
01.07.1.2 – E906182 Leaf spreader – stone ejector PBSh_PASh
01.07.2 – E906668 Holding device for leaf spreader PASh_PB2Sh
01.08 – E906669 Scalper bar PASWh-V_PB2SWh-V
01.09 – E906670 Scalper holding frame PASWh-V_PB2SWh-V
01.10.1 – E906183 Scalper – standard PBSh_PASh
01.10.2 – E906184 Scalper – Micro-Topper 2 PBSh_PASh
01.11 – E906743 Central lubrication and stickers PB2SWh
Hydraulic system – PB2SWh-V topper
01.20 – E906750 Drive topper shaft and leaf auger PB2SWh
01.21 – E906751 Leak oil topper shaft and leaf auger PB2SWh
01.22 – E906752 Topper wheel PB2SWh
01.23 – E906753 Cutting depth adjustment PB2SWh
01.24 – E906754 Leaf spreader PB2SWh
01.25 – E906755 Fold leaf spreader PB2SWh
01.26 – E906756 Scalper – displacement cylinder PB2SWh-V
01.27 – E906757 Scalper – clamping cylinder PB2SWh-V
01 – Topper PESh-45 from YOM 2015
01.01 – E906199 Leaf sensor PSh
01.02.1 – E906864 Topper wheel-wheel arm bracket – till year of constr. 2016 PESh
01.02.1 – E906865 Topper wheel-wheel arm bracket – from year of constr. 2017 PESh
01.02.2 – E906866 Topper wheel-swivel guide – till year of constr. 2016 PESh
01.02.2 – E906867 Topper wheel-swivel guide – from year of constr. 2017 PESh
01.03.1 – E906800 Topper housing – left PESh
01.03.2 – E906801 Topper housing – right PESh
01.03.3 – E906844 Topper housing – front PESh-45
01.03.4 – E906845 Topper housing – rear PESh-45
01.04 – E906804 Support arm PESh
01.05 – E906805 Lifting cylinder PESh
01.06.1 – E906846 Topper shaft – part 1 – to year of construction 2016 PESh-45
01.06.1 – E906860 Topper shaft – part 1 – from year of construction 2017 PESh-45
01.06.2 – E906847 Topper shaft – part 2 – to year of construction 2016 PESh-45
01.06.2 – E906861 Topper shaft – part 2 – from year of construction 2017 PESh-45
01.07 – E906850 Cleaner shaft PESh-45
01.08 – E906810 Central lubrication and sticker PESh
Hydraulic system – topper PESh-45
01.10 – E906852 Topper and cleaner shaft drive – left PESh-45
01.11 – E906853 Topper and cleaner shaft drive – right PESh-45
01.12 – E906854 Leak oil topper shaft and cleaner shaft PESh-45
01.13 – E906855 Lifting cylinder PESh-45
01.14 – E906857 Topper wheel PESh-45
01 – Topper PESh-V from YOM 2015
01.01 – E906199 Leaf sensor PSh
01.02.1 – E906864 Topper wheel-wheel arm bracket – till year of constr. 2016 PESh
01.02.1 – E906865 Topper wheel-wheel arm bracket – from year of constr. 2017 PESh
01.02.2 – E906866 Topper wheel-swivel guide – till year of constr. 2016 PESh
01.02.2 – E906867 Topper wheel-swivel guide – from year of constr. 2017 PESh
01.03.1 – E906800 Topper housing – left PESh
01.03.2 – E906801 Topper housing – right PESh
01.03.3 – E906838 Topper housing – front PESh-V
01.03.4 – E906839 Topper housing – rear PESh-V
01.04 – E906804 Support arm PESh
01.05 – E906805 Lifting cylinder PESh
01.06.1 – E906848 Topper shaft – part 1 – till year of construction 2016 PESh-V
01.06.1 – E906862 Topper shaft – part 1 – from year of construction 2017 PESh-V
01.06.2 – E906849 Topper shaft – part 2 – till year of construction 2016 PESh-V
01.06.2 – E906863 Topper shaft – part 2 – from year of construction 2017 PESh-V
01.07 – E906851 Cleaner shaft PESh-V
01.08 – E906810 Central lubrication and sticker PESh
Hydraulic system – topper PESh-V
01.10 – E906840 Topper and cleaner shaft drive – left PESh-V
01.11 – E906841 Topper and cleaner shaft drive – right PESh-V
01.12 – E906842 Leak oil topper shaft and cleaner shaft PESh-V
01.13 – E906856 Lifting cylinder PESh-V
01.14 – E906843 Topper wheel PESh-V
01 – Topper PIS-XL from year of construction 2014
01.01 – E906530 Leaf sensor PIS-XL
01.02.1 – E906531 Topper wheel – internal PIS-XL
01.02.2 – E906532 Topper wheel – external PIS-XL
01.03 – E906820 Topper housing – left and right PIS-XL
01.04 – E906539 Topper housing – front PIS-XL
01.05 – E906538 Topper housing – rear PIS-XL
01.06 – E906821 Topper shaft – with topper flails PIS-XL
01.06.1.1 – E906828 Topper shaft combined – with topper flails and cleaning rubber – part 1 – to year of construction 2014 PIS-XL 8×22”
01.06.1.1 – E906858 Topper shaft combined – with topper flails and cleaning rubber – part 1 – to year of construction 2015 PIS-XL 8×22”
01.06.1.2 – E906830 Topper shaft combined – with topper flails and cleaning rubber – part 2 – to year of construction 2014 PIS-XL 8×22”
01.06.1.2 – E906859 Topper shaft combined – with topper flails and cleaning rubber – part 2 – to year of construction 2015 PIS-XL 8×22”
01.06.2.1 – E906829 Topper shaft combined – with topper flails and cleaning rubber – part 1 PIS-XL 9×20”
01.06.2.2 – E906831 Topper shaft combined – with topper flails and cleaning rubber – part 2 PIS-XL 9×20”
01.07 – E906537 Scalper bar PIS-XL
01.08 – E906536 Adjustment tube for scalper with a height indicator PIS-XL
01.09 – E906533 Scalper holding frame PIS-XL
01.10.1 – E906534 Scalper – standard PIS-XL
01.10.2 – E906541 Scalper – Micro-Topper 2 PIS-XL
01.11.1 – E906822 Central lubrication and stickers PIS-XL
01.11.2 – E906543 Central lubrication and stickers – for USA_Canada PIS-XL
Hydraulic system – PIS-XL topper
01.20 – E906823 Topper shaft PIS-XL
01.21.1 – E906545 Topper wheel PIS-XL 8×45; 8×50; 8x22_; 9×45; 9×50; 9x20_
01.21.2 – E906824 Topper wheel PIS-XL 6x30_
01.22 – E906825 Scalper height adjustment PIS-XL
01 – Topper PISh-45_50 from year of construction 2006
01.01 – E906199 Leaf sensor PSh
01.02.1 – E905355 Topper wheel – wheel arm bracket PASWh_PBSWh_PISh_RASW_RIS
01.02.2 – E905377 Topper wheel – swivel guide PASWh_PBSWh_PISh
01.03 – E905350 Topper housing – left and right PISh-45_50_V
01.04.1 – E906173 Topper housing – front and rear PISh-45
01.04.2 – E906172 Topper housing – front and rear PISh-50
01.05 – E906170 Topper shaft – year of construction 2007 to 2009 PISh-45_50
01.05 – E906171 Topper shaft – to year of construction 2006 PISh-45_50
01.05 – E906175 Topper shaft – from year of construction 2010 PISh-45_50
01.06 – E905351 Scalper bar PISh-45_50
01.07 – E905349 Adjustment tube for scalper with a height indicator PISh-45_50_V
01.08 – E906174 Scalper holding frame PISh-45_50
01.09.1 – E906144 Scalper – standard PISh_RIS
01.09.2 – E906143 Scalper – Micro-Topper 2 PISh
01.10 – E906360 Central lubrication and sticker PISh
01.11 – E906362 Additional stickers for contour marking PISh
Hydraulic system – PISh-45_50 topper
01.20 – E905497 Topper shaft PISh-45_50_V
01.21 – E905499 Topper wheel and scalper height adjustment PISh-45_50_V
01 – Topper PISh-V from year of construction 2006
01.01 – E906199 Leaf sensor PSh
01.02.1 – E905355 Topper wheel – wheel arm bracket PASWh_PBSWh_PISh_RASW_RIS
01.02.2 – E905377 Topper wheel – swivel guide PASWh_PBSWh_PISh
01.03 – E905350 Topper housing – left and right PISh-45_50_V
01.04 – E906167 Topper housing – front and rear PISh-V
01.05 – E906168 Topper shaft – year of construction 2007 to 2009 PISh-V
01.05 – E906169 Topper shaft – to year of construction 2006 PISh-V
01.05 – E906176 Topper shaft – from year of construction 2010 PISh-V
01.06 – E905361 Scalper bar – till year of constr. 2009 PISh-V
01.06 – E906131 Scalper bar – till year of constr. 2010 PISh-V
01.07 – E905349 Adjustment tube for scalper with a height indicator PISh-45_50_V
01.08 – E905358 Scalper holding frame – up to year of construction 2009 PISh-V
01.08 – E906130 Scalper holding frame – from year of construction 2010 PISh-V
01.09.1 – E906144 Scalper – standard PISh_RIS
01.09.2 – E906143 Scalper – Micro-Topper 2 PISh
01.10 – E906360 Central lubrication and sticker PISh
01.11 – E906362 Additional stickers for contour marking PISh
Hydraulic system – PISh-V topper
01.20 – E905497 Topper shaft PISh-45_50_V
01.21 – E905499 Topper wheel and scalper height adjustment PISh-45_50_V
01.22 – E905498 Scalper – displacement cylinder – up to year of construction 2009 PISh-V
01.22 – E906129 Scalper – displacement cylinder – from year of construction 2010 PISh-V
01.23 – E905496 Scalper – clamping cylinder PISh-V
02 – Lifter
02 – Lifter PR2-XL from year of constr. 2015
02.01.1 – E9315020 Supporting frame with lifter depth hydraulic cylinder – centre PR2-XL 8×45; 8×50; 8x22_; 6x30_
02.01.2 – E9315021 Supporting frame with lifter depth hydraulic cylinder – centre PR2-XL 9×45; 9×50; 9x20_
02.02 – E9315022 Lifter side arm – left PR2-XL
02.03 – E9314004 Lifter side arm – right PR-XL
02.04 – E9314005 Lifter depth hydraulic cylinder and topper maintenance – left PR-XL
02.05 – E9314006 Lifter depth hydraulic cylinder and topper maintenance – right PR-XL
02.06 – E9315023 Cross tube for shaking share pickup PR2-XL
02.07 – E9314008 Shaking share clamping brackets – reinforced PR-XL
02.08.1 – E9314009 Shaking share PR-XL 8×50; 9×50
02.08.2 – E9314010 Shaking share PR-XL 8x22_
02.08.3 – E9314011 Shaking share PR-XL 8×45; 9×45
02.08.4 – E9314012 Shaking share PR-XL 9x20_
02.08.5 – E9314013 Shaking share PR-XL 6x30_
02.09 – E9314014 Shaking share gears – reinforced PR-XL
02.10.1 – E9315024 Cross tube for linear guide PR2-XL 8×45; 8×50; 8x22_; 6x30_
02.10.2 – E9315025 Cross tube for linear guide PR2-XL 9×45; 9×50; 9x20_
02.11 – E9314017 Linear guide clamping brackets PR-XL
02.12.1 – E9314018 Lifter steering PR-XL 8×45; 8×50
02.12.2 – E9314019 Lifter steering PR-XL 8x22_; 6x30_
02.12.3 – E9314020 Lifter steering PR-XL 9×45; 9×50
02.12.4 – E9314021 Lifter steering PR-XL 9x20_
02.13.1 – E9315035 Bracket for PA rods – linear guide PR2-XL 8×45; 8×50; 8x22_; 9×45; 9×50; 9x20_
02.13.2 – E9315036 Bracket for PA rods – linear guide PR2-XL 6x30_
02.14 – E9314024 Share body with step grids PR-XL
02.15.1 – E9315033 Share body with lifting shares PR2-XL
02.15.2 – E9315034 Share guide rods PR2-XL
02.16.1 – E9314027 Depth-control wheel PR-XL 8x22_; 6x30_
02.16.2 – E9314028 Depth-control wheel PR-XL 8×45; 8×50; 9×45; 9×50; 9x20_
02.17 – E9315026 Supporting roller drive – left and right – with Poclain MSE08 PR2-XL
02.18 – E9315027 Supporting arm for supporting roller – left and right – with Poclain MSE08 PR2-XL
02.19 – E9315028 Depth guide with automatic depth control – left and right PR2-XL
02.20 – E9314034 Topper guide parallelogram – left and right PR-XL
02.21.1 – E9314035 Lifting rollers PR-XL
02.21.2 – E9314076 Lifting rollers – bearing PR-XL
02.22 – E9314036 Short lifting rollers PR-XL
02.23 – E9314037 Complete lifter gears PR-XL
02.24.1 – E9314038 Paddle with drive PR-XL
02.24.2 – E9314039 Paddle gears PR-XL
02.25 – E9314040 Lifter side covers PR-XL
02.26.1 – E9315029 Central lubrication and stickers PR2-XL
02.26.2 – E9315030 Central lubrication and stickers – for USA_Canada PR2-XL
Hydraulic system – lifting unit PR2-XL Flange position – outside left and right
02.40 – E9314051 Lifter and topper drive – left PR-XL
02.41 – E9314052 Lifter and topper drive – right PR-XL
02.42 – E9314053 Lifter drive and short lifting roller leak oil – left PR-XL
02.43 – E9314054 Short lifting roller drive – left PR-XL
02.44 – E9314055 Short lifting roller drive – right PR-XL
02.45 – E9315031 Depth-control wheel drive and leak oil – left – with Poclain MSE08 PR2-XL
02.46 – E9315032 Depth-control wheel drive and leak oil – right – with Poclain MSE08 PR2-XL
02.47 – E9314061 Shaking share drive – reinforced PR-XL
02.48 – E9314062 Paddle drive PR-XL
02.49 – E9314063 Leak oil lines – rear PR-XL
02.50 – E9314064 Leak oil lines – depth-control shaft and topper drive PR-XL
02.51 – E9314065 Supply lines – rear – left and right PR-XL
02.52 – E9314066 Supply lines – left and right PR-XL
02.53 – E9314067 Supporting frame lifter depth – centre PR-XL
02.54 – E9314068 Topper relief cylinder PR-XL
02.55 – E9314069 Topper maintenance cylinder PR-XL
02.56 – E9314070 Supporting roller and lifting roller height adjustment PR-XL
02.57 – E9314071 Stone protection PR-XL
02.58.1 – E9314072 Multi-coupler with quick coupler – left PR-XL
02.58.2 – E9314073 Multi-coupler without quick coupler – left PR-XL
02.59.1 – E9314074 Distribution block with quick coupler – right PR-XL
02.59.2 – E9314075 Distribution block without quick coupler – right PR-XL
Special equipment
02.30.1 – E9314043 Model – transporter with accessories – part 1
02.30.2 – E9314044 Model – transporter with accessories – part 2
02.30.3 – E9314045 Model – transporter with accessories – part 3
02.30.4 – E9314046 Model – transporter with accessories – part 4
02.31.1 – E9314047 Model – transporter – brake system – part 1
02.31.2 – E9314048 Model – transporter – brake system – part 2
02.32 – E9314049 Model – transporter warning sign
02.33 – E9314050 Model – stickers transporter
Components and Details
02 – Lifter PR2h-V
02.01 – E9314101 Cross tube for shaking share pickup PR2h-V
02.02 – E9314103 Shaking share clamping brackets – reinforced PR2h-V
02.03 – E9314099 Shaking share drive PR2h-V
02.04 – E9314105 Shaking share gears – reinforced PR2h-45_50_V
02.05 – E9314106 Linear guide cross tube PR2h-45_50_V
02.06 – E9314108 Linear guide PR2h-V
02.07 – E9314110 Bracket for linear guide PA rods – to year of construction 2014 PR2h-V
02.07 – E9314159 Bracket for linear guide PA rods – from year of construction 2015 PR2h-V
02.08 – E9314111 Share body with linear guide PR2h-45_50_V
02.09.1 – E9314112 Share body with lifter shares – to year of construction 2014 PR2h-45_50_V
02.09.1 – E9314160 Share body with lifter shares – from year of construction 2015 PR2h-45_50_V
02.09.2 – E9314113 Share guide rods – from year of construction 2014 PR2h-45_50_V
02.09.2 – E9314161 Share guide rods – from year of construction 2015 PR2h-45_50_V
02.10 – E9314114 Lifter steering PR2h-45_50_V
02.11 – E9314116 Depth-control wheel PR2h-V
02.12.1 – E9314118 Supporting roller gears – left PR2h-V
02.12.2 – E9314119 Supporting roller gears – right PR2h-V
02.13 – E9314121 Supporting roller supporting arm – left and right PR2h-V
02.14 – E9314123 Depth guide PR2h-V
02.15 – E9314125 Lifting rollers PR2h-V
02.16 – E9314127 Short lifting rollers PR2h-50_V
02.17.1 – E9314128 Paddle PR2h-45_50_V
02.17.2 – E9314129 Paddle gears PR2h-45_50_V
02.18 – E9314130 Complete lifter gears – left-rear PR2h-45_50_V
02.19 – E9314131 Complete lifter gears – right-rear PR2h-45_50_V
02.20 – E9314132 Complete lifter gears – left-front PR2h-45_50_V
02.21 – E9314134 Supporting frame and lifter side arm PR2h-V
02.22 – E9314135 Topper guide parallelogram – left and right PR2h-45_50_V
02.23 – E9314136 Supporting arm – centre PR2h-45_50_V
02.24 – E9314137 Lifting roller side shift – left PR2h-50_V
02.25 – E9314138 Lifting roller side shift – right PR2h-50_V
02.26 – E9314140 Lifter side covers PR2h-50_V
02.27 – E9314142 Supporting frame lifter covers – left PR2h-50_V
02.28 – E9314144 Supporting frame lifter covers – right PR2h-50_V
02.29 – E9314146 Central lubrication and stickers PR2h-50_V
02.30 – E9314157 Electrical control cabinet, working lights and accessories PR2h-50_V
Hydraulic system – lifting unit PR2h-V
02.50 – E9314170 Topper drive PR2h-45_50_V
02.51.1 – E9314171 Topper – supply line and leak oil PR2h-45_50_V
02.51.2 – E9314172 Topper – supply line and leak oil with shaking share fast speed – only till YOM 2013 PR2h-45_50_V
02.52 – E9314173 Return line – topper drive with PBSh_PASh PR2h-45_50_V
02.53 – E9314174 Return line – topper drive with PISh_PESh PR2h-45_50_V
02.54 – E9314175 Return line – lifting roller drive and leak oil PR2h-45_50_V
02.55 – E9314176 Short lifting roller drive PR2h-45_50_V
02.56 – E9314177 Shaking share drive – reinforced with PBSh_PASh PR2h-45_50_V
02.57 – E9314178 Shaking share drive – reinforced with PISh_PESh PR2h-45_50_V
02.58 – E9314179 Paddle drive and shift lifting unit PR2h-45_50_V
02.59 – E9314181 Supply lines – left and right PR2h-V
02.60 – E9314182 Topper relief cylinder PR2h-45_50_V
02.61 – E9314183 Topper maintenance cylinder PR2h-45_50_V
02.62 – E9314184 Stone protection PR2h-45_50_V
02.63 – E9314185 Supporting roller supply and return lines PR2h-45_50_V
02.64 – E9314187 Supporting roller drive – right PR2h-V
02.65 – E9314189 Supporting roller drive – left PR2h-V
02.66 – E9314190 Supporting roller and lifting roller height adjustment PR2h-45_50_V
02.67 – E9314191 Shift roller position PR2h-50_V
02.68 – E9314192 Shift supporting roller PR2h-V
02.69 – E9314193 Shift share body PR2h-V
02.70 – E9314194 Clamp share body – till year of construction 2014 PR2h-V
02.70 – E9314197 Clamp share body – from year of construction 2015 PR2h-V
02.71 – E9314195 Shift shaking share PR2h-V
02.72 – E9314196 Clamp shaking share PR2h-V
Special equipment
02.40 – E9314147 Variant – additional chassis – frame with components PR2h-45_50_V
02.41 – E9314148 Variant – additional chassis – support foot PR2h-45_50_V
02.42 – E9314149 Variant – additional chassis – wheel suspension PR2h-45_50_V
02 – Lifting unit PR2h-45
02.01 – E9314100 Cross tube for shaking share pickup PR2h-45
02.02 – E9314102 Shaking share clamping brackets – reinforced PR2h-45
02.03 – E9314104 Shaking share drive PR2h-45
02.04 – E9314105 Shaking share gears – reinforced PR2h-45_50_V
02.05 – E9314106 Linear guide cross tube PR2h-45_50_V
02.06 – E9314107 Linear guide PR2h-45
02.07 – E9314109 Bracket for linear guide PA rods – to year of construction 2014 PR2h-45_50
02.07 – E9314158 Bracket for linear guide PA rods – from year of construction 2015 PR2h-45_50
02.08 – E9314111 Share body with linear guide PR2h-45_50_V
02.09.1 – E9314112 Share body with lifter shares – to year of construction 2014 PR2h-45_50_V
02.09.1 – E9314160 Share body with lifter shares – from year of construction 2015 PR2h-45_50_V
02.09.2 – E9314113 Share guide rods – from year of construction 2014 PR2h-45_50_V
02.09.2 – E9314161 Share guide rods – from year of construction 2015 PR2h-45_50_V
02.10 – E9314114 Lifter steering PR2h-45_50_V
02.11 – E9314115 Depth-control wheel PR2h-45_50
02.12 – E9314117 Supporting roller drive – left and right PR2h-45_50
02.13 – E9314120 Supporting roller supporting arm – left and right PR2h-45_50
02.14 – E9314122 Depth guide PR2h-45_50
02.15 – E9314124 Lifting rollers PR2h-45
02.16 – E9314126 Short lifting rollers PR2h-45
02.17.1 – E9314128 Paddle PR2h-45_50_V
02.17.2 – E9314129 Paddle gears PR2h-45_50_V
02.18 – E9314130 Complete lifter gears – left-rear PR2h-45_50_V
02.19 – E9314131 Complete lifter gears – right-rear PR2h-45_50_V
02.20 – E9314132 Complete lifter gears – left-front PR2h-45_50_V
02.21 – E9314133 Supporting frame and lifter side arm PR2h-45
02.22 – E9314135 Topper guide parallelogram – left and right PR2h-45_50_V
02.23 – E9314136 Supporting arm – centre PR2h-45_50_V
02.24 – E9314139 Lifter side covers PR2h-45
02.25 – E9314141 Supporting frame lifter covers – left PR2h-45
02.26 – E9314143 Supporting frame lifter covers – right PR2h-45
02.27 – E9314145 Central lubrication and stickers PR2h-45
02.28 – E9314156 Electrical control cabinet, working lights and accessories PR2h-45
Hydraulic system – lifting unit PR2h-45
02.50 – E9314170 Topper drive PR2h-45_50_V
02.51.1 – E9314171 Topper – supply line and leak oil PR2h-45_50_V
02.51.2 – E9314172 Topper – supply line and leak oil with shaking share fast speed – only till YOM 2013 PR2h-45_50_V
02.52 – E9314173 Return line – topper drive with PBSh_PASh PR2h-45_50_V
02.53 – E9314174 Return line – topper drive with PISh_PESh PR2h-45_50_V
02.54 – E9314175 Return line – lifting roller drive and leak oil PR2h-45_50_V
02.55 – E9314176 Short lifting roller drive PR2h-45_50_V
02.56 – E9314177 Shaking share drive – reinforced with PBSh_PASh PR2h-45_50_V
02.57 – E9314178 Shaking share drive – reinforced with PISh_PESh PR2h-45_50_V
02.58 – E9314179 Paddle drive and shift lifting unit PR2h-45_50_V
02.59 – E9314180 Supply lines – left and right PR2h-45_50
02.60 – E9314182 Topper relief cylinder PR2h-45_50_V
02.61 – E9314183 Topper maintenance cylinder PR2h-45_50_V
02.62 – E9314184 Stone protection PR2h-45_50_V
02.63 – E9314185 Supporting roller supply and return lines PR2h-45_50_V
02.64 – E9314186 Supporting roller drive – right PR2h-45_50
02.65 – E9314188 Supporting roller drive – left PR2h-45_50
02.66 – E9314190 Supporting roller and lifting roller height adjustment PR2h-45_50_V
Special equipment
02.40 – E9314147 Variant – additional chassis – frame with components PR2h-45_50_V
02.41 – E9314148 Variant – additional chassis – support foot PR2h-45_50_V
02.42 – E9314149 Variant – additional chassis – wheel suspension PR2h-45_50_V
02.43 – E9314150 Share body – divided
02.44.1 – E9314152 Share body – divided – attachments sugar beet
02.44.2 – E9314151 Share body – divided – attachments chicory
02.45 – E9314153 Tilting frame – linear guide for chicory
02.46.1 – E9314154 Row sensor for chicory – part 1
02.46.2 – E9314155 Row sensor for chicory – part 2
02 – Lifting unit PR2h-50
02.01 – E9314200 Cross tube for shaking share pickup PR2h-50
02.02 – E9314201 Shaking share clamping brackets – reinforced PR2h-50
02.03 – E9314202 Shaking share drive PR2h-50
02.04 – E9314105 Shaking share gears – reinforced PR2h-45_50_V
02.05 – E9314106 Linear guide cross tube PR2h-45_50_V
02.06 – E9314203 Linear guide PR2h-50
02.07 – E9314109 Bracket for linear guide PA rods – to year of construction 2014 PR2h-45_50
02.07 – E9314158 Bracket for linear guide PA rods – from year of construction 2015 PR2h-45_50
02.08 – E9314111 Share body with linear guide PR2h-45_50_V
02.09.1 – E9314112 Share body with lifter shares – to year of construction 2014 PR2h-45_50_V
02.09.1 – E9314160 Share body with lifter shares – from year of construction 2015 PR2h-45_50_V
02.09.2 – E9314113 Share guide rods – from year of construction 2014 PR2h-45_50_V
02.09.2 – E9314161 Share guide rods – from year of construction 2015 PR2h-45_50_V
02.10 – E9314114 Lifter steering PR2h-45_50_V
02.11 – E9314115 Depth-control wheel PR2h-45_50
02.12 – E9314117 Supporting roller drive – left and right PR2h-45_50
02.13 – E9314120 Supporting roller supporting arm – left and right PR2h-45_50
02.14 – E9314122 Depth guide PR2h-45_50
02.15 – E9314204 Lifting rollers PR2h-50
02.16 – E9314127 Short lifting rollers PR2h-50_V
02.17.1 – E9314128 Paddle PR2h-45_50_V
02.17.2 – E9314129 Paddle gears PR2h-45_50_V
02.18 – E9314130 Complete lifter gears – left-rear PR2h-45_50_V
02.19 – E9314131 Complete lifter gears – right-rear PR2h-45_50_V
02.20 – E9314132 Complete lifter gears – left-front PR2h-45_50_V
02.21 – E9314205 Supporting frame and lifter side arm PR2h-50
02.22 – E9314135 Topper guide parallelogram – left and right PR2h-45_50_V
02.23 – E9314136 Supporting arm – centre PR2h-45_50_V
02.24 – E9314137 Lifting roller side shift – left PR2h-50_V
02.25 – E9314138 Lifting roller side shift – right PR2h-50_V
02.26 – E9314140 Lifter side covers PR2h-50_V
02.27 – E9314142 Supporting frame lifter covers – left PR2h-50_V
02.28 – E9314144 Supporting frame lifter covers – right PR2h-50_V
02.29 – E9314146 Central lubrication and stickers PR2h-50_V
02.30 – E9314157 Electrical control cabinet, working lights and accessories PR2h-50_V
Hydraulic system – lifting unit PR2h-50
02.50 – E9314170 Topper drive PR2h-45_50_V
02.51.1 – E9314171 Topper – supply line and leak oil PR2h-45_50_V
02.51.2 – E9314172 Topper – supply line and leak oil with shaking share fast speed – only till YOM 2013 PR2h-45_50_V
02.52 – E9314173 Return line – topper drive with PBSh_PASh PR2h-45_50_V
02.53 – E9314174 Return line – topper drive with PISh_PESh PR2h-45_50_V
02.54 – E9314175 Return line – lifting roller drive and leak oil PR2h-45_50_V
02.55 – E9314176 Short lifting roller drive PR2h-45_50_V
02.56 – E9314177 Shaking share drive – reinforced with PBSh_PASh PR2h-45_50_V
02.57 – E9314178 Shaking share drive – reinforced with PISh_PESh PR2h-45_50_V
02.58 – E9314179 Paddle drive and shift lifting unit PR2h-45_50_V
02.59 – E9314180 Supply lines – left and right PR2h-45_50
02.60 – E9314182 Topper relief cylinder PR2h-45_50_V
02.61 – E9314183 Topper maintenance cylinder PR2h-45_50_V
02.62 – E9314184 Stone protection PR2h-45_50_V
02.63 – E9314185 Supporting roller supply and return lines PR2h-45_50_V
02.64 – E9314186 Supporting roller drive – right PR2h-45_50
02.65 – E9314188 Supporting roller drive – left PR2h-45_50
02.66 – E9314190 Supporting roller and lifting roller height adjustment PR2h-45_50_V
02.67 – E9314191 Shift roller position PR2h-50_V
Special equipment
02.40 – E9314147 Variant – additional chassis – frame with components PR2h-45_50_V
02.41 – E9314148 Variant – additional chassis – support foot PR2h-45_50_V
02.42 – E9314149 Variant – additional chassis – wheel suspension PR2h-45_50_V
03 – Intermediate belt
03.01 – E9014001 Intermediate belt frame and accessories – PR2h
03.02 – E9014002 Intermediate belt transfer pipe and supporting rollers – PR2h
03.03 – E9014003 Intermediate belt suspension – PR2h
03.04 – E9014004 Sieve conveyor for intermediate belt – PR2h
04 – Strainer wheel
04.01 – E9014011 Strainer wheel 1
04.02 – E9014012 Strainer wheel 2 to year of construction 2014
04.02 – E9014020 Strainer wheel 2 from year of construction 2015
04.03 – E9014013 Strainer wheel 3
04.04 – E9014014 Bearing arm guide grids 1
04.05 – E9014015 Bearing arm guide grids 2
04.06 – E9014016 Bearing arm guide grids 3
04.07.1 – E9014017 Strainer wheel guide grids without spring tines till year of constr. 2014
04.07.1 – E9014021 Strainer wheel guide grids without spring tines year of construction 2015
04.07.1 – E9014023 Strainer wheel guide grids without spring tines from year of constr. 2016
04.07.2 – E9014018 Strainer wheel guide grids with spring tines till year of construction 2014
04.07.2 – E9014022 Strainer wheel guide grids with spring tines year of constr. 2015
04.07.2 – E9014024 Strainer wheel guide grids with spring tines from YOM 2016
Special equipment
04.10 – E9014019 Model – 1st strainer wheel agitator
04.30 – E906287 Strainer wheel tines, round – chicory
04.32 – E9014025 Sliding plates – chicory from year of constr. 2016
04.32 – E9014026 Sliding plates – chicory till year of constr. 2015
05 – Elevator
05.01 – E9014031 Elevator drive
05.02 – E9014032 Elevator arm – right
05.03 – E9014033 Elevator arm – left
05.04 – E9014034 Elevator duct – right top
05.05 – E9014035 Elevator duct – right bottom
05.06 – E9014036 Elevator duct – left
05.07 – E9014037 Elevator – left bottom
05.08 – E9014038 Elevator bottom
05.09 – E9014039 Angular gear
05.10 – E9014040 Sieve conveyor for elevator
05.10 – E9014041 Sieve conveyor for elevator from ch. no. 6G1483
05.10 – E9014042 Modification of sieve conveyor for elevator
06 – Bunker
– E9800498 Frame tubes on conveyor drive
06.01 – E9014051 Bunker auger
06.02 – E9014052 Bunker bar
06.03 – E9014053 Longitudinal conveyor – sheet metal and rubber till year of construction 2015
06.03 – E9014065 Longitudinal conveyor – sheet metal and rubber from year of constr. 2016
06.04 – E9014054 Longitudinal conveyor – guide bars
06.05 – E9014055 Longitudinal conveyor – drive
06.06 – E9014056 Cross conveyor – sheet metal and rubber till year of construction 2015
06.06 – E9014066 Cross conveyor – sheet metal and rubber from year of constr. 2016
06.07 – E9014057 Cross conveyor – guide bars
06.08 – E9014058 Cross conveyor – drive
06.09 – E9014059 Cleaning roller
06.10 – E9014060 Movable walls – left and right
06.11 – E9014061 Movable walls – front and rear, ultrasound
06.12 – E9014062 Storage compartment, belt limiter
06.13 – E9014063 Bunker rear wall and door
06.14 – E9014064 Bunker panels bolted from year of constr. 2016
07 – Unload conveyor
07.01 – E9014081 Unload conveyor frame
07.02 – E9014082 Articulated unloading conveyor frame 1
07.03 – E9014083 Articulated unload conveyor frame 2 with drive
07.04 – E9014084 Unload conveyor support rollers
07.05 – E9014085 Potentiometer unload conveyor
07.06 – E9014086 Sieve conveyor for unloading conveyor
08 – Chassis
– E9800487 Overview of lacquers and paints
08.01 – E9014091 Three-point suspension
08.02 – E9014092 Hydraulic cylinders – 1st axle and articulation
08.03 – E9014093 1st axle – axle mounting_potentiometer
08.04.1 – E9014094 Articulated joint – suspension_potentiometer
08.04.2 – E9014124 Chassis
08.05 – E9014095 2nd axle with gears
08.06 – E9014096 Suspension axle 2
08.07 – E9014097 Suspension axle 3
08.08 – E9014098 Cardan shafts
08.09 – E9014099 Traction drive
08.10 – E9014100 Tyres
08.11 – E9014101 Forward frame component – attachments
08.12 – E9014102 Cabin ladder
08.13 – E9014103 Bunker ladder
08.14 – E9014104 Covers under the cross conveyor
08.15 – E9014105 Cover for axle 2
08.16 – E9014106 Cover for axle 3
08.17 – E9014107 Cover for splash guard
08.18 – E9014108 Operator protection safety bar
08.19 – E9014109 Protective cover and components on the bunker – left
08.20 – E9014110 Protective cover and components on the bunker – front
08.21 – E9014111 Protective cover and components on the bunker – right middle
08.22 – E9014112 Protective cover and components on the bunker – right rear
08.23 – E9014113 Engine compartment underride guard
08.24 – E9014114 Engine compartment – frame
08.25 – E9014115 Engine compartment – rear cover
08.26 – E9014116 Engine compartment – side cover
08.27 – E9014117 Engine cover – top left
08.28 – E9014118 Engine compartment – radiator grill
08.29.1 – E9014119 Stickers – front and left
08.29.2 – E9014121 Stickers – front and left – for USA_Canada
08.30.1 – E9014120 Stickers – rear and right
08.30.2 – E9014122 Stickers – rear and right – for USA_Canada
08.31 – E9014123 Vehicle tools and accessories
Special equipment
08.40 – E9014125 Model – platform extension
09 – Cabin
09.01 – E9014131 Cabin mounting
09.02 – E9014132 Accelerator and brake pedals and cleaning flap
09.03 – E9014133 Cabin roof and accessories
09.04 – E9014134 Fresh air filter, air jets and covers till year of construction 2015
09.04 – E9014149 Fresh air filter and air jets from YOM 2016
09.05 – E9014135 Air conditioner with accessories till year of constr. 2015
09.05 – E9014150 Air conditioner with accessories from year of constr. 2016
09.06 – E9014136 Driver’s seat and passenger’s seat and accessories till year of construction 2015
09.06 – E9014151 Driver’s seat and passenger’s seat and accessories from model year 2016
09.07 – E9014137 Steering column
09.08 – E9014138 Roof console – front till year of construction 2015
09.08 – E9014152 Roof console – front from year of construction 2016
09.09 – E9014139 Roof console – right
09.10.1 – E9014140 Terminal console – part 1
09.10.2 – E9014141 Terminal console – part 2 till year of construction 2015
09.10.2 – E9014153 Terminal console – part 2 from 2016 YOM
09.10.3 – E9014142 Terminal console – part 3
09.11 – E9014143 Mirror bracket and working floodlight
09.12 – E9014144 Front window, side window and cabin door
09.13 – E9014145 Window wipers
09.14 – E9014146 Windscreen washer system
09.15 – E9014147 Cabin linings till year of construction 2015
09.15.1 – E9014154 Cabin cover – part 1 from 2016 YOM
09.15.2 – E9014155 Cabin cover – part 2 from 2016 YOM
09.16 – E9014148 Stickers – cabin and central electrical system
Components and Details
– E9800483 352044400 – driver’s seat
10 – Engine
10.01 – E9014161 Diesel tank
10.02.1 – E9014162 Pump distributor gears with pumps – part 1
10.02.2 – E9014163 Pump distributor gears with pumps – part 2
10.03.1 – E9014164 Diesel engine radiator – part 1
10.03.2 – E9014165 Diesel engine radiator – part 2
10.03.3 – E9014166 Diesel engine radiator – part 3
10.04 – E9014167 Air filter and charge air cooler
10.05 – E9014172 Exhaust system – version 1
10.05 – E9014173 Exhaust system – version 2
10.06 – E9014174 Diesel engine with engine bracket from year of construction 2015
10.06 – E9014175 Diesel engine with engine bracket till year of construction 2014
10.07 – E9014168 Oil cooler
10.08 – E9014169 Fuel system with filter
10.09 – E9014170 AdBlue® tank
10.10 – E9014171 AdBlue system
10.11 – E9014176 Connecting battery, starter and generator
10.12 – E9014177 Diesel engine OM473
10.13 – E9014178 Heating system
10.14 – E9014179 Air conditioning system
Components and Details
– E9800486 303026800 – Fuel filter with water separator and e-pump
11 – Hydraulic system
11.01.1 – E9014201 Three-point suspension with lifting unit lift cylinder
11.01.2 – E9014199 Three-point suspension – relief with additional chassis
11.02 – E9014202 Operating hydraulics – articulation front part supply line
11.03 – E9014203 Operating hydraulics – supply to articulation front part
11.04 – E9014204 Operating hydraulics – pressure line and return
11.05 – E9014205 Pressure lines – steering working hydraulics
11.06 – E9014206 Pressure line – pump steering
11.07 – E9014207 Operating hydraulics – Load Sensing
11.08 – E9014208 Pressure line – steering, shaking share and paddle
11.09 – E9014209 Pressure line – shaking share and front axle steering
11.10 – E9014210 Steering front axle – Load Sensing
11.11 – E9014211 Steering – steering wheel connection
11.12 – E9014212 Steering – axle 1 front axle
11.13 – E9014213 Steering – articulation cylinder
11.14 – E9014214 Steering – synchronized steering
11.15 – E9014215 Steering – axle 2
11.16 – E9014216 Steering – axle 3 – part 1
11.17 – E9014217 Steering – axle 3 – part 2
11.18 – E9014218 Steering – emergency steering pump
11.19 – E9014219 Chassis – axle support 1st axle – part 1
11.20 – E9014220 Chassis – axle support 1st axle – part 2
11.21 – E9014221 Chassis – axle support 2nd + 3rd axle
11.22 – E9014222 Chassis – inclination
11.23 – E9014223 Chassis – prestress
11.24 – E9014224 Sieving conveyor – drive and tension
11.25 – E9014225 Strainer wheel – pressure line
11.26 – E9014226 Strainer wheel – return
11.27 – E9014227 Strainer wheel 1 – drive; feed for strainer wheel 2 + 3
11.28 – E9014228 Strainer wheel 2 + 3 – drive
11.29 – E9014229 Strainer wheel 1 – guide grid height adjustment
11.30 – E9014230 Strainer wheel 2 + 3 – guide grid height adjustment
11.31 – E9014231 Elevator – drive left
11.32.1 – E9014232 Elevator – drive right
11.32.2 – E9014233 Elevator – drive roller bottom
11.33 – E9014234 Elevator – support cylinders
11.34 – E9014235 Elevator up_down – left
11.35 – E9014236 Elevator up_down – right
11.36 – E9014237 Bunker auger – drive
11.37 – E9014238 Bunker auger up_down – front
11.38 – E9014239 Bunker auger up_down – rear
11.39 – E9014240 Bunker bar folding
11.40 – E9014241 Fold partition – front
11.41 – E9014242 Fold partition – rear
11.42 – E9014243 Longitudinal conveyor – drive
11.43 – E9014244 Cross conveyor – drive
11.44 – E9014245 Cross conveyor – pressure sender
11.45 – E9014246 Unload conveyor – drive
11.46 – E9014247 Unloading conveyor up_down – supply
11.47 – E9014248 Unload conveyor up_down – front
11.48 – E9014249 Unloading conveyor up_down – rear
11.49 – E9014250 Unloading conveyor – supply articulation
11.50 – E9014251 Unload conveyor – articulation 1
11.51 – E9014252 Unload conveyor – articulation 2
11.52.1 – E9014253 Lifter drive – pressure line and return
11.52.2 – E9014273 Lifting unit drive – additional pump at PR2-XL
11.53 – E9014254 Traction drive – pressure line
11.54 – E9014255 Traction drive – CVR transmission lubrication – part 1
11.55 – E9014256 Traction drive – CVR transmission lubrication – part 2
11.56 – E9014257 Traction drive – CVR gear shift
11.57 – E9014258 Traction drive – transmission lubrication axle 2
11.58 – E9014259 Brake – pressure line, return and Load Sensing
11.59 – E9014260 Brake – 1st axle front axle
11.60 – E9014261 Brake – axle 2
11.61 – E9014262 Fan drive for water cooler charge air
11.62 – E9014263 Oil cooler
11.63 – E9014264 PDG lubrication – part 1
11.64 – E9014200 PDG lubrication – part 2
11.65 – E9014265 Collective return pipe on the frame – left
11.66 – E9014266 Collective return pipe on the frame – right
11.67 – E9014267 Accumulative return unit
11.68 – E9014268 Intake lines – part 1
11.69 – E9014269 Intake lines – part 2
11.70 – E9014270 Intake lines – part 3
11.71 – E9014271 Hydraulic oil tank
11.72 – E9014272 Hydraulic return filter
Special equipment
11.81 – E9014274 Model – three-point suspension with lifting unit lift cylinder only PR2-XL lifter with quick coupler
11.82 – E9014275 Model – PR2-XL lifting unit with quick coupler – right
11.83 – E9014276 Model – PR2-XL lifting unit with quick coupler – left – part 1
11.84 – E9014277 Model – PR2-XL lifting unit with quick coupler – left – part 2
11.85 – E9014278 Model – PR2-XL lifting unit with quick coupler – left – part 3
12 – Central electrical system
– E9800477 Übersicht Stecker – Teil 2
– E9800478 018079700 – Electrical assortment box
– E9800499 Overview of plugs
12.01 – E9014301 Switching cabinet for central electrics and diesel engine till year of construction 2015
12.01 – E9014306 Switching cabinet for central electrical system and diesel engine from year of constr. 2016
12.02 – E9014302 Video system – distance control to 2015 YOM
12.02 – E9014304 Video system – distance control from year of construction 2016
12.03 – E9014303 Video system – R-View till year of construction 2015
12.03 – E9014305 Video system – R-View from year of construction 2016
12.04.1 – E9014307 Wiring harness overview – part 1
12.04.2 – E9014308 Wiring harness overview – part 2
13 – Gears & axles
299026601 – CVR gearbox traction drive
13.34 – E9014364 O-11730002 Housing
13.36 – E9014366 O-11730002 Intermediate shaft
13.38 – E9014368 O-11730002 Output drive shaft
13.39 – E9014369 O-11730002 Filter
299026701 – pump distributor gears
13.01 – E9014311 O-10620043 Pump distributor gears compartment
13.02 – E9014312 O-10620043 Pump drive shaft
13.03 – E9014313 O-10620043 Pump distributor gears drive shaft
13.04 – E9014314 O-10620043 Pump distributor gears side shaft
13.05 – E9014315 O-10620043 Pump distributor gears intermediate shaft above
13.06 – E9014316 O-10620043 Pump distributor gears side shaft
13.07 – E9014317 O-10620043 Pump distributor gears intermediate shaft central
13.08 – E9014318 O-10620043 Pump distributor gears intermediate shaft below
13.09 – E9014319 O-10620043 Pump distributor gears drive shaft below
13.10 – E9014320 O-10620043 Pump distributor gears filter
299026801 – front axle
13.11 – E9014331 O-11340030 Differential housing
13.12 – E9014332 O-11340030 Brake
13.13 – E9014333 O-11340030 Planetary axle carrier
13.14 – E9014334 O-11340030 Front axle wheel hub
13.15 – E9014335 O-11340030 Steering group
13.16 – E9014336 O-11340030 Front axle steering cylinder
299026901 – rear axle 1
13.17 – E9014340 O-11350045 Differential housing
13.18 – E9014341 O-11350045 rear axle
13.19 – E9014342 O-11350045 Brake
13.20 – E9014343 O-11350045 Steering group
13.21 – E9014344 O-11350045 Wheel hub
13.22 – E9014345 O-11350045 Housing
13.23 – E9014346 O-11350045 Output drive shaft
13.24 – E9014347 O-11350045 Intermediate shaft
13.25 – E9014348 O-11350045 Drive shaft
13.26 – E9014349 O-11350045 Lubrication oil pump
299027001 – rear axle 2
13.27 – E9014355 O-11350046 Differential housing
13.28 – E9014356 O-11350046 rear axle
13.29 – E9014357 O-11350046 Steering group
13.30 – E9014358 O-11350046 Wheel hub
299027601 – cardan shaft
13.33 – E9014362 O-10730007 Articulated intermed. shaft
630030101 – intermediate belt gears
13.31 – E9014360 O-10630028 Intermediate belt gears for PRh lifter
14 – Pneumatic system
14.01 – E9014370 Pneumatic lines – right – air chamber
14.02 – E9014371 Connection for operator protection deflector bracket
14.03 – E9014372 Differential lock connection and all-wheel switching
14.04 – E9014373 Mirror adjustment connection with blow-out gun
Special equipment
14.10 – E9014374 Model – pneumatic system – blow-out gun for lifting unit PR2-XL with quick coupler
15 – Hydraulic screw connections
15.01 – E9800500 Hydraulic screw connection – type_ G
15.02 – E9800501 Hydraulic screw connection – type_ W
15.03 – E9800502 Hydraulic screw connection – type_ T
15.04 – E9800503 Hydraulic screw connection – type_ K
15.05 – E9800504 Hydraulic screw connection – type_ EVW
15.06 – E9800505 Hydraulic screw connection – type_ EVT
15.07 – E9800506 Hydraulic screw connection – type_ EVL
15.08.1 – E9800507 Hydraulic screw connection – type_ EVGE – part 1 metric
15.08.2 – E9800508 Hydraulic screw connection – type_ EVGE – part 2 inch
15.09.1 – E9800509 Hydraulic screw connection – type_ GE – part 1 metric
15.09.2 – E9800510 Hydraulic screw connection – type_ GE – part 2 metric
15.09.3 – E9800511 Hydraulic screw connection – type_ GE – part 3 metric
15.09.4 – E9800512 Hydraulic screw connection – type_ GE – part 4 inch
15.09.5 – E9800513 Hydraulic screw connection – type_ GE – part 5 inch
15.09.6 – E9800514 Hydraulic screw connection – type_ GE – part 6 inch
15.10 – E9800515 Hydraulic screw connection – type_ GR
15.11 – E9800516 Hydraulic screw connection – type_ GVO
15.12.1 – E9800517 Hydraulic screw connection – type_ KOR – part 1
15.12.2 – E9800518 Hydraulic screw connection – type_ KOR – part 2
15.13 – E9800519 Hydraulic screw connection – type_ SWVE
15.14.1 – E9800520 Hydraulic screw connection – type_ VSTI – part 1 metric
15.14.2 – E9800521 Hydraulic screw connection – type_ VSTI – part 2 inch
15.15 – E9800522 Hydraulic screw connection – type_ ROV
15.16.1 – E9800523 Hydraulic screw connection – type_ RED – part 1 metric
15.16.2 – E9800524 Hydraulic screw connection – type_ RED – part 2 inch
15.17 – E9800525 Hydraulic screw connection – type_ GAI
15.18 – E9800526 Hydraulic screw connection – type_ MAV
15.19 – E9800527 Hydraulic screw connection – type_ MAV-EV
15.20 – E9800528 Hydraulic screw connection – type_ Measuring screw connection
15.21 – E9800529 Hydraulic screw connection – type_ measuring port
15.22 – E9800530 Hydraulic screw connection – type_ gauge connection
15.23 – E9800531 Hydraulic screw connection – type_ pressure gauge
15.24 – E9800532 Hydraulic screw connection – type_ pressure gauge connection
15.25 – E9800533 Hydraulic screw connection – type_ hose for pressure gauge
15.26 – E9800534 Hydraulic screw connection – type_ Bulkhead screw connection
15.27 – E9800535 Hydraulic screw connection – type_ Bulkhead union elbow
15.28 – E9800536 Hydraulic screw connection – type_ Flat nut for bulkhead screw connections
15.29 – E9800537 Hydraulic screw connection – type_ screw cap
15.30 – E9800538 Hydraulic screw connection – type_ BUZ
15.31 – E9800539 Hydraulic screw connection – type_ cutting ring
15.32 – E9800540 Hydraulic screw connection – type_ reinforcing sleeve
16 – Central lubrication
– E9800491 Central lubricating pump
– E9800493 Distributor – components
– E9800494 Hose connections
– E9800495 Screw connections – central lubrication
16.01 – E9014400 Central lubricating system
16.02 – E9014401 Central lubricating pump with grease bucket
21 – Lubricants and filter lists
21.01 – E9016500 Lubricants
21.02 – E9014420 Filter for diesel engine
21.03 – E9016502 Filter for hydraulic system and gears
21.04 – E9016503 Filter for cabin
22 – Control blocks and seat valves
– E9800001 270043100 – seat valves 4-part
– E9800002 270044400 – control unit – articulation coupling
– E9800003 270044500 – control unit – elevator
– E9800004 270047000 – seat valves 1-part
– E9800006 270050600 – control unit – strainer wheel
– E9800007 270050700 – control unit – steering FA
– E9800008 270051100 – control unit – infeed conveyor PR
– E9800009 270051400 – control unit
– E9800010 270051500 – control unit – lifting rollers
– E9800011 270051600 – control unit – lifter gears and depth-control shaft
– E9800012 270051700 – control unit – elevator tightening
– E9800013 270052100 – control unit – short lifting roller and paddle
– E9800014 270053700 – control unit – shaking share and leaf-spreader
– E9800016 270066600 – check valve unit
– E9800018 270066900 – compact brake unit – 2-circuit _Safim_
– E9800020 270069200 – control unit conveyor 1
– E9800022 270043200 – seat valves 2-part
– E9800034 270063700 – control unit – operating hydraulics 1
– E9800035 270072300 – control unit – operating hydraulics 2
– E9800036 270072400 – control unit – steering RA & articulation
– E9800037 270076800 – seat valves 1-part
– E9800038 270074100 – Control unit – chassis
– E9800039 270076000 – Control unit – bunker auger
– E9800040 270072500 – control unit conveyor 2
– E9800041 270071100 – control unit coupling CVR
– E9800042 270076810 – seat valves 1-part
– E9800043 270044600 – seat valves 1-part
– E9800044 270054400 – control unit – leaf auger
– E9800051 2700546_ – Suction unit
– E9800073 270064000 – Leaf auger control unit
– E9800074 270068800 – control unit rubber topper
23 – Hydraulic motors and cylinders
– E9800032 272015400 – gear motor
– E9800033 2720132_ – hydraulic motor OMV 400 tapered shaft
– E9800061 272015410 – gear motor
– E9800084 272016100 – gear motor fan drive
– E9800090 272016310 – hydraulic motor wheel motor MSE05
– E9800091 272016900 – hydraulic motor wheel motor MSE08
– E9800093 272012701 – axial piston motor A2 FE 80 _ BR 61
– E9800094 272012801 – axial piston motor A2 FE 90 _ BR 61
– E9800095 272013601 – axial piston motor A2 FE 107 _ BR 61
– E9800096 272013701 – axial piston motor A2 FE 125 _ BR 61
– E9800103 2720177_ – axial piston motor A6 VM 215 EP
– E9800105 272017103 – axial piston motor A10 VER 37 EZ7
– E9800107 2720135_ – hydraulic motor TMT 250 tapered shaft
– E9800110 Hydraulic motor OMV
– E9800111 Hydraulic motor OMT
– E9800112 Hydraulic motor OMS
– E9800113 Hydraulic motor OMR
– E9800116 276014901 – hydraulic cylinders ø25mm x 120mm
